AUSTRALIAN MONITOR AMIS23X Specifications

2 Way Crossover
The Australian Monitor Pro Series AMIS23X is a one rack unit, fourth
order Linkwitz-Riley electronic crossover. The AMIS23X can be confi-
gured as either a stereo two way or a mono three way crossover.
Featuring clip LED indication per band per channel, frequency range
selector switch, CD horn boost switch & polarity reverse switching,
the AMIS 23X is a professional price-performing crossover.
Compressor - Limiter
The Australian Monitor Pro Series AMIS CL2 is a 1 RU, dual channel
compressor limiter. Featuring an expander/gate, compression & limiting
per channel, the AMISCL2 utilizes a high quality VCA to give excellent
performance from a budget priced dynamics processor. With added
features like selectable Automatic attack & release times & EQ
enhancement which automatically compensates for high end loss when
heavy compression is taking place, the AMISCL2 has the features & the
performance of a compressor/limiter many times the price
AMIS 23x & CL2 AMIS 23x & CL2
AMIS 23x & CL2
AMIS 23x & CL2 AMIS 23x & CL2
SPECIFICATIONS
Frequency Range
Hum and Noise
Low Frequency Section
High Frequency Section
Signal-To-Noise Ratio
CONTROLS
Dimensions HxWxD
Weight
SPECIFICATIONS
Input
Maximum Input Level
CMR
Input detection
.
Output
Bandwidth
THD
IMD (SMPTE)
Noise & Hum
Crosstalk
X1 80Hz to 920 Hz
X2 800Hz to 9.2 kHz
>93dBu
Output @ 0dB <-106 dBu
Output @ 0 dB <-97d dBu
118 dB
Input Level Continuously
variable; Output Level
Low, High Cont. variable;
CD Boost Rear panel
switch; mute Front panel
switch; Channel link Rear
panel switch; Phase Rear
panel switch
1.75" x 19" x 8.5"
5.5 lbs
Type RF-filtered, Servo-
balances input stage
Impedance 60K balanced
Nominal Operating Level -
10dBu to 4dBu
+21dBu balanced and
unbalanced
@ 1kHz >40dB
Type DC de-coupled,
unbalanced input
Impedance >20K ohms
Maximum Input+21dBu
Type Electronically
buffered output stage
Impedance <40 ohms
5Hz to 50kHz, +0, -1dB
@ +4dBu 0.05%typ..
@ +10dBu 0.01% typ.
>93dBu
@ 20kHz >85dBu
