The ET 1500 E
SCALATE
level roll-on loading and roll-off unloading of
equipment with non-tilting lowering deck.
winch driven deck allows one person to load and
unload equipment.
Contents
t e
t e
a l a
a l a
e r
e r
s c
s c
a i l
a i l
E
T r
T r
Load Capacity: 1500 lbs
®
T
RAILER
offers ground
The
Advertisement
Table of Contents
Related Manuals for Bil-Jax ET 1500
Summary of Contents for Bil-Jax ET 1500
-
Page 1: Table Of Contents
Load Capacity: 1500 lbs ® The ET 1500 E SCALATE RAILER offers ground level roll-on loading and roll-off unloading of equipment with non-tilting lowering deck. winch driven deck allows one person to load and unload equipment. -
Page 2: Safety
Failure to comply with these instructions may result in serious personal injury or death as well as damage to cargo. SPECIAL FEATURES ® The Bil-Jax SCALATE RAILER includes all the features of a heavy duty trailer, plus: Escalator Deck and Winch... -
Page 3: Specifications
Bil-Jax. Bil-Jax shall not in any event be liable for the cost of any special, indirect or consequential damages to anyone, product, or thing. This warranty is in lieu of all other warranties expressed or implied. We neither assume nor authorize any representative, or other person, to assume for us any other liability in connection with the sale, rental, or use of this product. - Page 4 This page intentionally left blank...
-
Page 5: Trailer Hitching
TRAILER HITCHING Hook Up the Trailer 1. Raise trailer and lift ball latch. 2. Line up ball with hitch. NOTE: The trailer hitch uses a 2 inch ball. 3. Lower hitch onto ball and close ball latch. 4. Raise and secure jack. NOTE: Trailer frame should be level when hitch is on ball. -
Page 6: Equipment Loading
EQUIPMENT LOADING Lower the Deck NOTE: Trailer must be hitched to vehicle according to page 5 before lowering or raising the deck. 1. Lift latch release lever. 2. Lift latch handle. NOTE: The trailer frame should be on a level NOTE: If the deck pulls against the clamp when the surface when lowering the deck. - Page 7 EQUIPMENT LOADING Load the Equipment 1. Remove bumper bar. 2. Load equipment so that the resulting tongue weight is 15 to 20% of the total load. a la a la a il a il Maximum capacity = 1500 lbs. Do not exceed. 3.
- Page 8 EQUIPMENT LOADING Raise the Deck (trailer must be hitched to the vehicle) 1. Check the latch clamp. Tilt the latch clamp back 2. Crank winch handle to raise the deck. Stop onto the handle. cranking when the deck is aligned with the frame. Make sure people are away from the trailer before raising the deck.
-
Page 9: Service
SERVICE Adjusting the Hitch Height The trailer frame and deck should be level for equipment loading and unloading. If the trailer hitch is too high or too low when hitched to the towing vehicle, readjust the hitch height. 1. Unhitch trailer. Remove hitch mounting screws. 2. - Page 10 SERVICE Replacing the Lift Rollers 1. On a paved, level surface, pull trailer onto 4x4 2. Lower the deck until the front or rear lift rollers blocks. Jack up and unhitch the trailer. can be removed from the roller access holes. 3-1/2 The deck must be supported by the paved surface or shoring before the lift rollers are removed.
-
Page 11: Tire Maintenance
SERVICE Tire Maintenance Wheel Torque Requirements At least once each week, use an accurate tire It is extremely important to apply and maintain pressure gage to check the air pressure in both proper wheel mounting torque on your axle. trailer tires. Inflate to the pressure recommended by Wheel nuts should be retorqued after 50 miles the tire manufacturer (located on the tire). -
Page 12: Parts List
PARTS LIST Item Item No. Part No. Description No. Part No. Description B12-00-0044 Deck Weldment 32 0090-0045 Screw, Cap, 3/8-16 x 1-1/2 B03-00-0124 Load Bar Assembly 33 B06-00-0318 Decal, ET1500 B07-06-5456 Plate, Spring Push-Off 34 B06-00-0315 Decal, “Max. Cap. 1500 lbs.” B39-00-0023 Spring, Compression, 7/8 in. - Page 13 PARTS LIST 14, 14A, 14B, 14C a l a a i l 62,62A, 20, 20A ® Model ET 1500 E SCALATE RAILER...
