Zanussi ZXC 60/25 Instruction Booklet

Refrigerator - freezer
Hide thumbs Also See for ZXC 60/25:
Table of Contents

Advertisement

Quick Links

REFRIGERATOR-
FREEZER
ZXC 60/25
INSTRUCTION BOOKLET
2222 178-36/1

Advertisement

Table of Contents
loading

Related Manuals for Zanussi ZXC 60/25

Summary of Contents for Zanussi ZXC 60/25

  • Page 1 REFRIGERATOR- FREEZER ZXC 60/25 INSTRUCTION BOOKLET 2222 178-36/1...

  • Page 2: General Safety

    Always ensure that there is adequate This product should be serviced by an authorised ventilation as a failure to do this will result in ZANUSSI Service Centre, and only genuine spare possible food loss. See installation instructions. parts should be used.
  • Page 3 CONSERVATION Environment Protection This appliance does not contain gasses which could damage the ozone layer, in either its refrigerant circuit or insulation materials. The appliance shall not be discarded together with the urban refuse and rubbish. Avoid damaging the cooling unit, especially at the rear near the heat exchanger.

  • Page 4: Table Of Contents

    CONTENTS Description of the appliance Guarantee conditions Installation Positioning Before using Instructions for totally built-in appliances The electrical connections Technical specification Operation Setting the temperature The freezer compartment Freezing fresh food Thawing Making ice cubes Health and safety guidelines Fresh food refrigeration Dual purpose meat box Positioning the door shelves Drink dispenser...

  • Page 5: Description Of The Appliance

    DESCRIPTION OF THE APPLIANCE F A S T F R E E Z A - Thermostat control for fridge and freezer compartments B - Dairy compartment C - Can storage shelves with egg tray D - Drink dispenser E - Bottle storage shelf F - Freezer calendar (recommended storage times for frozen foods) and produce storage card (write on / wipe off card for recording what has been stored in the freezer and when) G - Storing frozen food...

  • Page 6: Installation

    INSTALLATION Before using Warning Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to IF YOU ARE DISCARDING AN OLD APPLIANCE 0.5 litre of water). Do not use soap or detergent as the THAT HAS A LOCK OR CATCH ON THE DOOR, smell may linger.

  • Page 7: Instructions For Totally Built-In Appliances

    Instructions for totally built-in appliances The appliance doors have been locked in position for transport by means of pins on both sides. Depending upon the position which you choose for your appliance, the door can be hinged on the left or the left.
  • Page 8 Recess dimensions Height 1446 mm Fig. 1 50-min. cm Depth 550 mm Width 560 mm To ensure adequate ventilation, allow the clearances shown in figure 1. min. D027 Fig. 2 Push appliance into housing until stop strip (A) touches the kitchen unit. D023 Open the door and push the appliance against the side Fig.
  • Page 9 Apply covers (B) on joint cover lugs and into hinge holes. Fig. 5 D339 Fig. 6 Position the runners (H) at the top and bottom of the inside of the kitchen unit as shown in Fig. 6 and mark the position of the external holes. After preparing the holes, screw the runners to the kitchen unit door using 3.5x16 mm screws.

  • Page 10: The Electrical Connections

    A replacement cover/carrier must be obtained from this safety measure not be observed. your local Zanussi Service Force Centre whose address is listed in the Customer Care Booklet which If the plug that is fitted to your appliance is not accompanies your instruction manual.

  • Page 11: Technical Specification

    TECHNICAL SPECIFICATIONS POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz TOTAL POWER ABSORBED 100 W AVERAGE DAILY UNITS ELECTRICITY* 1.30 kWh GROSS CAPACITY Fridge 174 l Freezer 76 l NET CAPACITY Fridge 170 l Freezer 62 l STAR RATING * This figure is based on standard test results in accordance with European Standard EN153.

  • Page 12: Operation

    OPERATION Setting the temperature The freezer compartment The temperature inside the refrigerator and freezer The four-star freezer compartment is suitable for is regulated by a single thermostat with 6 temperature storage of commercially frozen food and for freezing positions and one «OFF» ( O ) position. fresh foods.

  • Page 13: Health And Safety Guidelines

    HEALTH AND SAFETY GUIDELINES Because of consumer demand, preservatives have Regularly check the refrigerator door seal to been removed from many pre-prepared foods. This ensure that it is clean and free from bits and together with the changes in shopping habits to a pieces.

  • Page 14: Fresh Food Refrigeration

    Fresh food refrigeration To obtain the best performance, do not store warm food or evaporating liquids in the refrigerator; do cover or wrap the food, particularly if it has a strong flavour. Do not cover the shelves with any protective material, such as paper, cardboard or plastic, which may obstruct the air circulation through them.

  • Page 15: Drink Dispenser

    Drink dispenser Fig. 13a The container for cooling drinks (Fig. 13a) is located in the door of the fridge. It is easily removed from its runners for filling and cleaning by pushing it upwards from the left side and then by pulling sharply outwards.

  • Page 16: Cool Check Temperature Guide

    fluctuation may safe temperatures for all food types. The guide occur. A Zanussi fridge is designed to cope with any consists of a temperature sensitive strip sealed in the changes in temperature but under certain conditions shelf trim.

  • Page 17: Defrosting

    Defrosting Refrigerator The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via the pipe, into a tray located at the back of the appliance above the compressor, where it evaporates. Fig. 14 Important To avoid defrost water overflowing into the fridge, periodically clean the water discharge hole in the centre of the V shaped drip collector at the back of the refrigerator compartment behind the salad drawer.
  • Page 18 Important When defrosting the freezer, the fridge is also controlled by the thermostat and will not be operational during this period. A temperature rise of the frozen food packs, during defrosting, may shorten their safe storage life. Attention! «In the event of a power failure causing the temperature within your freezer to rise, do not re- freeze the food without checking its condition.

  • Page 19: Maintenance And Cleaning

    Unscrew the bulb and replace it with a new 15 watt bulb (available from your nearest Zanussi Service Force Centre). Replace the light cover by sliding it into its original position and replacing the screw.

  • Page 20: What Happens If Something Goes Wrong

    WHAT HAPPENS IF SOMETHING GOES WRONG? Before contacting your local Zanussi Service Centre, check the following points: The appliance does not work... Check that: There is power at the socket. Ensure that there is not a power cut by checking the household lights.
  • Page 21 If, after the above checks, there is still a fault, call your local Zanussi Service Centre, whose address can be found in the accompanying Customer Care Booklet, and can also be found in your local telephone directory under «Z». Please make sure you give the model and serial number of the appliance. This information can be found on the rating plate inside the fridge compartment on the left side behind the salad drawer, or on the guarantee certificate.
  • Page 22 We, Zanussi Ltd., undertake that if, within twentyfour Costs incurred for calls to put right machines months of the date of the purchase, this ZANUSSI improperly installed or calls to machines outside appliance or any part thereof is proved to be defective the United Kingdom.
