3 | Varifocal 960H Lenses
960H Lenses
LVF-4000C-D2812
Varifocal Lens
Max. sensor format
1/3 inch
Focal length
2.8 – 12 mm
Iris range
F1.3 - 360
Min object distance
0.3 m (1.0 ft)
Weight
71 g (0.16 lb)
∅38 x 48 x 56 mm
Dimensions
∅1.5 x 1.9 x 2.2 in
(approx.)
Lens mount
CS
Angle of view (HxV)
W: 102.2 x 74.2
T: 23.7 x 17.8
MTF on-axis (lp/mm)
>178
>146 (IR)
MTF off-axis (lp/mm)
>123
>79 (IR)
Iris control
4-pin, DC control
Focus control
manual
Zoom control
manual
IR corrected
yes
Operating temperature
-10°C to +50°C
(+14°F to +122°F)
Represented by:
Americas:
Europe, Middle East, Africa:
Bosch Security Systems, Inc.
Bosch Security Systems B.V.
130 Perinton Parkway
P.O. Box 80002
Fairport, New York, 14450, USA
5617 BA Eindhoven, The Netherlands
Phone: +1 800 289 0096
Phone: + 31 40 2577 284
Fax: +1 585 223 9180
Fax: +31 40 2577 330
security.sales@us.bosch.com
emea.securitysystems@bosch.com
www.boschsecurity.us
www.boschsecurity.com
© Bosch Security Systems 2013 | Data subject to change without notice
11449838603 | en, V1, 28. Aug 2013
LVF-4000C-D0550
LVF-5000C-D2811
Varifocal Lens
Varifocal Lens
1/3 inch
1/3 inch
5.0 – 50 mm
2.8 – 11 mm
F1.4 - 360
F1.4 - 360
0.5 m (1.6 ft)
0.3 m (1.0 ft)
118 g (0.1 lb)
79 g (0.17 lb)
∅37 x 64 x 49 mm
∅40 x 59 x 46 mm
∅1.5 x 2.5 x 1.9 in
∅1.6 x 2.3 x 1.8 in
CS
CS
W: 49 x 36.7
W: 97.4 x 72.4
T: 5.47 x 4.1
T: 26.2 x 19.7
>145
>250
>119 (IR)
>223 (IR)
>71
>145
>30 (IR)
>131 (IR)
4-pin, DC control
4-pin, DC control
manual
manual
manual
manual
yes
yes
-20°C to +50°C
-20°C to +60°C
(-4°F to +122°F)
(-4°F to +140°F)
Asia-Pacific:
Robert Bosch (SEA) Pte Ltd, Security
Systems
11 Bishan Street 21
Singapore 573943
Phone: +65 6571 2808
Fax: +65 6571 2699
apr.securitysystems@bosch.com
www.boschsecurity.asia
LVF-5000C-D0550
Varifocal Lens
1/3 inch
5.0 – 50 mm
F1.6 - 360
0.3 m (1.0 ft)
85 g (0.1 lb)
∅41 x 59 x 55 mm
∅1.6 x 2.3 x 2.2 in
CS
W: 51.2 x 39.4
T: 5.3 x 4.1
>165
>144 (IR)
>81
>30 (IR)
4-pin, DC control
manual
manual
yes
-10°C to +50°C
(+14°F to +122°F)
China:
America Latina:
Bosch (Shanghai) Security Systems Ltd.
Robert Bosch Ltda Security Systems Division
201 Building, No. 333 Fuquan Road
Via Anhanguera, Km 98
North IBP
CEP 13065-900
Changning District, Shanghai
Campinas, Sao Paulo, Brazil
200335 China
Phone: +55 19 2103 2860
Phone +86 21 22181111
Fax: +55 19 2103 2862
Fax: +86 21 22182398
al.securitysystems@bosch.com
www.boschsecurity.com.cn
www.boschsecurity.com
LTC 3664/31
Varifocal Lens
1/3 inch
3.0 – 8 mm
F1.0 - 360
0.2 m (0.7 ft)
45 g (0.1 lb)
∅33 x 43 x 48 mm
∅1.3 x 1.7 x 1.9 in
CS
W: 92.5 x 68
T: 35.7 x 26.8
>178
>58 (IR)
>77
>55 (IR)
4-pin, DC control
manual
manual
yes
-20°C to +60°C
(-4°F to +140°F)
