Read and understand all safety precautions in this manual before operating. Failure to comply with instructions in this manual could result in personal injury, property damage and/or voiding of your warranty. The manufacturer WILL NOT be liable for any damage because of failure to follow these instruc- tions.
SAFETY GUIDELINES - DEFINITIONS SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recog- nize this information, we use the following symbols. Please read the manual and pay attention to these sections.
Page 3
RISK OF INJURY. When servicing a tool, use only identical replacement parts. Use only authorized parts. Use only the lubricants supplied with the tool or specified by Coleman Powermate. AIR SOURCE SAFETY RISK OF BURSTING AND/OR INJURY. Never connect to an air source that is greater than 50 psi.
TYPICAL INST ALLA TION TYPICAL INST ALLA TION Figure 1 Description Description Description Description Air hose In-line Oiler Quick Coupler Female Connector In-line Filter Air Hose Male Connector Spray Gun Tee Fitting Whip Hose Air Tool OPERA TING INSTRUCTIONS OPERA TING INSTRUCTIONS Spray Gun Setup This spray gun is shipped from the factory designed for use as a...
OPERA TING INSTRUCTIONS (continued) OPERA TING INSTRUCTIONS (continued) Spraying Instructions (continued) Install a 1/4” NPT female connector (not included) into the air inlet port on the tool (see Figure 2). Note: Use Teflon® Tape on all threaded connections. Mix material according to the manufacutrer’s instructions, adding thinner if needed.
TROUBLESHOOTING GUIDE TROUBLESHOOTING GUIDE SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION Gun does not spray Air hose connection at compres- Tighten and seal hose fittings with Teflon® tape if sor loose leaks are found. Canister loose Tighten canister to gun. Fluid tube, fluid tip or air caps Clean parts with solvent per instructions in the “user loose, clogged or damaged maintenance”...
Page 7
LIMITED W ARRANTY ONE YEAR LIMITED WARRANTY: Powermate Corporation (the Company) warrants that for a period of twelve (12) months from the date of purchase, it will replace or repair, free of charge, for the original retail purchaser only, any part or parts, manufactured by the Company, found upon examination by the Company or its assigned representa- tives, to be defective in material or workmanship or both.
LIGNES DIRECTRICES DE SÉCURITÉ—DÉFINITIONS LIGNES DIRECTRICES DE SÉCURITÉ—DÉFINITIONS Le présent guide contient des renseignements importants que vous devriez connaître et comprendre. Ces ren- seignements traitent de VOTRE SÉCURITÉ et de la PRÉVENTION DE PROBLÈMES DE MATÉRIEL. Pour vous aider à reconnaître les renseignements, nous avons utilisé les symboles suivants. Veuillez lire ce guide et porter une attention particulière à...
Page 9
RISQUE DE BLESSURE. Lorsque vous effectuez l'entretien d'un outil, n'utilisez que des pièces de rechange identiques. N'utilisez que des pièces de rechange approuvées. N'utilisez que les lubrifiants fournis avec l'outil ou ceux spécifiés par Coleman Powermate. SÉCURITÉ DE LA SOURCE D'ALIMENTATION EN AIR RISQUE D'ÉCLATEMENT OU DE BLESSURE.
INST ALLA TION TYPE INST ALLA TION TYPE Figure 1 Description Description Description Description Tuyau flexible d'air Huilier sur canalisation Raccord rapide Raccord femelle Filtre sur canalisation Tuyau flexible d'air Raccord mâle Pistolet pulvérisateur Raccord en T Flexible de raccordement Outil pneumatique MODE D'EMPLOI MODE D'EMPLOI...
Page 11
MODE D'EMPLOI (suite) MODE D'EMPLOI (suite) Instructions pour la pulvérisation Vous devriez, comme pratique courante, vider l'eau du réservoir et des conduites d'air chaque jour avant de les utiliser (consultez le guide d'utilisation du compresseur pour obtenir de plus amples renseignements). NOTE : Négliger d'installer l'équipement approprié...
ENTRETIEN P AR L'UTILISA TEUR (suite) ENTRETIEN P AR L'UTILISA TEUR (suite) Nettoyage des conduites obstruées Désassemblez le pistolet pulvérisateur et faites tremper toutes les pièces de métal dans un diluant ou un solvant approprié pendant 15 à 30 minutes. Vous pouvez avoir à prolonger le trempage si les conduites sont gravement obstruées.
GARANTIE LIMITÉE GARANTIE LIMITÉE GARANTIE LIMITÉE D'UN AN : Powermate Corporation (la Société) garantit contre tout vice de fabrication et de main-d'œuvre, au premier acheteur au détail seulement, et ce pour une période de douze (12) mois à compter de la date d'achat, qu'elle remplacera ou réparera, sans frais, toute pièce fabriquée par la Société...
AS DE SEGURIDAD - DEFINICIONES AS DE SEGURIDAD - DEFINICIONES Es importante que usted conozca y entienda la información contenida en este manual. Esta información está relacionada con la protección de SU SEGURIDAD y la PREVENCIÓN DE PROBLEMAS DE EQUIPOS. Como ayuda para reconocer esta información, utilizamos los siguientes símbolos.
Page 15
únicamente. Utilice sólo partes autorizadas. Utilice sólo los lubricantes suministrados con la herramienta o especificados por Coleman Powermate. SEGURIDAD DEL SUMINISTRO DE AIRE RIESGO DE ESTALLAR Y/O DE LESIÓN. No conecte nunca a un suministro de aire superior a 344,7 kPa.
INST ALACIÓN TÍPICA INST ALACIÓN TÍPICA Figura 1 Description Description Description Description Manguera de aire Engrasador en línea Acoplador rápido Conector hembra Filtro en línea Manguera de aire Conector macho Pistola aspersora Conector en T Manguera de conexión flexible Herramienta neumática INSTRUCCIONES DE OPERACIÓN INSTRUCCIONES DE OPERACIÓN Montaje de la pistola aspersora...
INSTRUCCIONES DE OPERACIÓN (continuación) INSTRUCCIONES DE OPERACIÓN (continuación) Instrucciones de aspersión Como práctica estándar, drene el agua del tanque del compresor de aire y las tuberías de aire antes de utilizar la herramienta cada día (consulte el manual del usuario del compresor para obtener instrucciones detalladas). NOTA: En caso de no instalar equipos adecuados de eliminación de aceite/agua, se dañará...
INSTRUCCIONES DE MANTENIMIENT O DEL USUARIO (continuación) INSTRUCCIONES DE MANTENIMIENT O DEL USUARIO (continuación) Aplique aceite liviano para máquinas en el empaque de cuero. Esto ayuda a evitar fugas de aire. Si las fugas de aire continúan luego de aplicar aceite, probablemente el empaque esté gastado y deba cambiarlo. El empaque y los anil los de la pistola se dañarán si deja el montaje de la pistola aspersora sumergido en solvente durante períodos prolongados de tiempo.
GARANTÍA LIMIT GARANTÍA LIMITADA DE UN AÑO: Powermate Corporation (la Empresa) garantiza que durante un período de doce (12) meses a partir de la fecha de adquisición, cambiará o reparará de forma gratuita y únicamente al comprador minorista original, toda parte o partes, fabricadas por la empresa, que la empresa o sus representantes designados determinen que presentan defectos de material, mano de obra o ambos.
