NEC MultiSync LCD1770NX Technical Specifications page 2

NEC MultiSync
TECHNICAL SPECIFICATIONS
Panel Technology
Screen Size [inch/cm]
Pixel Pitch [mm]
Viewing Angle [°]
Contrast Ratio (typ.)
Brightness (typ.) [cd/m²]
Response Time (typ.) [ms]
Colours [Mio.]
Horizontal Frequency [kHz]
Vertical Frequency [Hz]
Optimum Resolution
Supported Resolutions
Connectors
Plug & Play
Adjust Functions
Safety and Ergonomics
Power Consumption on Mode [W]
Stand-by Mode [W]
Power Supply
Ambient Temperature (operating) [°C]
Ambient Humidity (operating) [%]
VESA Mounting [mm]
ErgoDesign®: Height adjustable Stand [mm]
Screen Tilt / Swivel [°]
Dimensions (W x H x D) [mm]
Bezel Width [mm]
Weight [kg]
Cable Management
Kensington security slot
Benefits
Audio Functions
Colour Versions
Shipping Content
Warranty
All hardware and software names are brand names and/or registered trademarks of the respective manufacturers. All rights reserved. All specifications are subject to change without notice. 03/10
www.nec-display-solutions.co.uk
NEC (UK) Ltd. - Display Solutions Division, NEC House, 1 Victoria Road, London W3 6BL
Phone: +44 (0) 870 0120 1160, Fax : +44 (0) 208 8752 3670
®
LCD1770NX
TN+ film TFT
17 / 43
0.264
178 horizontal / 178 vertical (typ. at contrast ratio 5:1)
160 horizontal / 160 vertical (typ. at contrast ratio 10:1)
800:1
300 (LCD Module at 25 °C)
5 (1 white / black; 4 black / white)
16.7
31.5 - 81.0
56 - 75
1280 x 1024 at 60 Hz
1152 x 870; 1152 x 864; 1024 x 768; 832 x 624; 800 x 600; 720 x 400; 640 x 480
Digital: 1 x DVI-D; Analog: 1 x mini D-sub 15 pin
VESA DDC/CI; EDID Standard; VESA DDC2B
Auto Adjust; Brightness; Colour Temperature Control; Contrast; Fine Adjust (analog); Intelligent Power
Management; Language Select; Monitor Information; NTAA (Non-Touch-Auto-Adjustment); On-
Screen-Display (OSD) lock-out; sRGB
CE; ERP; TCO 03; TÜV Ergonomics; TÜV GS; GEEA/Energy Label; FCC Class B; PCT/Gost; UL/C-UL or
CSA; CCC; ISO 13406-2 (pixel failure class II); MPR II/ MPR III; RoHS
36 (typ.)
< 2
100-120 V/220-240 V; 0.7 A/0.35 A; internal power supply
+5 to +35
10 to 80
100 x 100
110
-5 to +30 / -170 to +170
367 x 362.5 x 198
13.6
6.1
yes
yes
® ®
NaViSet and NaViSet Administrator compatible; Rapid Response Technology; sRGB Support
®
Option: MultiSync Soundbar 70
Silver Front Bezel, Black Back Cabinet
Silver Front Bezel, Light Grey Back Cabinet
Monitor; Power Cable; Signal Cable VGA - VGA; CD-ROM; Sales Office List; User Manual
3 years warranty incl. backlight
