Page 1 X7SLM-L USER’S MANUAL Revision 1.0...
Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.
Page 3: About This Manual
X7SLM-L motherboard. About This Motherboard The X7SLM-L supports a single Intel® Core™ 2 Duo/Pentium® dual-core/Pentium D/Pentium 4/Celeron® dual-core/Celeron/Celeron D Processor with a system bus speed of up to 800 MHz in an LGA775 socket. With support for the Intel® Core...
Page 4 X7SLM-L User’s Manual Danger/Caution: Instructions to be strictly followed to prevent catastrophic system failure or to avoid bodily injury Warning: Critical information to prevent damage to the components. Important: Important information given to ensure proper system installa- tion or to relay safety precautions.
Page 5: Contacting Supermicro
Contacting Supermicro Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
Page 6: Table Of Contents
X7SLM-L User’s Manual Table of Contents Preface About This Manual ......................3 About This Motherboard ....................3 Manual Organization ..................... 3 Conventions Used in the Manual: ................. 3 Contacting Supermicro ....................5 Chapter 1 Introduction Overview ......................1-1 Checklist ......................1-1 Chipset Overview ...................
Page 7 Table of Contents DIMM Installation ..................2-10 Memory Support .................... 2-10 Connectors/I/O Ports ..................2-12 Back Panel Connectors and I/O Ports ............2-12 ATX PS/2 Keyboard and PS/2 Mouse Ports ..........2-13 Universal Serial Bus (USB) ..............2-14 Serial Ports ....................2-15 Video Connector ..................
Page 8 Appendix B Installing the Windows OS Installing the Windows XP/2000/2003 OS for Systems with RAID Support ... B-1 Installing the Windows XP/2000/2003 OS for Systems without RAID Support ... Appendix C Software Installation Instructions Installing Drivers ....................C-1 Conﬁ guring Supero Doctor II ................C-2 viii...
Page 9: Chapter 1 Introduction
Chapter 1: Introduction Chapter 1 Introduction Overview Checklist Congratulations on purchasing your computer motherboard from an acknowledged leader in the industry. Supermicro boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Please check that the following items have all been included with your motherboard.
Page 10 X7SLM-L User’s Manual X7SLM-L Image Note: All graphics shown in this manual were based upon the latest PCB Revision available at the time of publishing of the manual. The motherboard you've received may or may not look exactly the same as the graphics...
Page 11 Chapter 1: Introduction Motherboard Layout Fan5 JPW2 JPW1 DIMM1B UNB NON-ECC DDR2 400/533/667 Required DIMM1A X7SLM-L Speaker CTRL Intel 945GC Intel CTRL Clock chip Slot 7 PCI-E x16 CTRL Slot 6 PCI 33MHz Intel ICH7R Battery Slot 5 PCI-E x4 in x8...
Page 12 X7SLM-L User’s Manual X7SLM-L Quick Reference (not drawn to scale) Fan5 JPW2 JPW1 DIMM1B UNB NON-ECC DDR2 400/533/667 Required DIMM1A X7SLM-L Speaker CTRL Intel 945GC Intel CTRL Clock chip Slot 7 PCI-E x16 CTRL Slot 6 PCI 33MHz Intel ICH7R...
Page 13 Chapter 1: Introduction X7SLM-L Quick Reference Jumpers Label Description Default Setting JBT1 CMOS Clear See Chapter 2 JPL1/JPL2 #8, 9 GLAN 1/2 Enable Pins 1-2 (Enabled) Watch Dog Timer Enable Pins 1-2 (Reset) Connectors Label Description Battery Onboard Battery BIOS...
Page 14: Motherboard Features
Power-up mode control for recovery from AC power loss • C temperature sensing logic • CPU/System overheat LED and control • System resource alert via Supero Doctor III • CPU Thermal Trip support • Thermal Monitor 2 (TM2) support •...
Page 15 Chapter 1: Introduction ACPI Features • Slow blinking LED for suspend state indicator • Main switch override mechanism Onboard I/O • Built-in ICH7R SATA Controller, 4 connectors for 4 devices (with support for RAID 0, RAID 1, RAID 10 and RAID 5 in the Windows OS environment) •...
Page 16 X7SLM-L User’s Manual VRM V11 LGA775_PROCESSOR VRM 11 IDTCV183-1 FSB: 800/533MHz INTEGRATED DIMM_CHA DDR2_667/533/400 GRAPHIC 945GC PCIE_x16 1 PCIE_x16 PCIE_x4 Slot 1 PCIE_x4 (x8 Slot) Gb_LAN1 RTL8111C PCIE_x1 UDMA/100 PRI_IDE RJ45 PCIE_x1 RTL8111C Gb_LAN2 ICH7R RJ45 S-ATA/300 4 x SATA...
Page 17: Chipset Overview
Chapter 1: Introduction Chipset Overview The Intel® 82945GC chipset, designed for use with a single Intel® Core™ 2 Duo/ Pentium® dual-core/Pentium D/Pentium 4/Celeron® dual-core/Celeron/Celeron D Processor with a system bus speed of up to 800 MHz in an LGA 775 socket, contains two components: GMCH (North Bridge) and ICH7R (South Bridge).
Page 18: Pc Health Monitoring
SD III. Fan Status Monitor with Software The PC health monitor can check the RPM status of the cooling fans via Supero Doctor III. CPU Overheat LED and Control This feature is available when the user enables the CPU overheat warning function in the BIOS.
Page 19: Slow Blinking Led For Suspend-State Indicator
It is even more important for processors that have high CPU clock rates of 1 GHz and faster. X7SLM-L accommodates 12V ATX power supplies. Although most power supplies generally meet the speciﬁ cations required by the CPU, some are inadequate.
Page 20: Super I/O
X7SLM-L User’s Manual Super I/O The disk drive adapter functions of the Super I/O chip include a data separator, write pre-compensation circuitry, decode logic, data rate selection, a clock generator, drive interface control logic and interrupt and DMA logic. The wide range of functions integrated onto the Super I/O greatly reduces the number of components required for interfacing with I/O devices.
Page 21: Chapter 2 Installation
Chapter 2: Installation Chapter 2 Installation Static-Sensitive Devices Electrostatic-Discharge (ESD) can damage electronic com ponents. To prevent damage to your system board, it is important to handle it very carefully. The following measures are generally sufﬁ cient to protect your equipment from ESD.
Page 22: Tools Needed
X7SLM-L User's Manual Motherboard Installation All motherboards have standard mounting holes to ﬁ t different types of chassis. Make sure that the locations of all the mounting holes for both motherboard and chassis match. Although a chassis may have both plastic and metal mounting fas- teners, metal ones are highly recommended because they ground the motherboard to the chassis.
Page 23: Installation Instructions
Chapter 2: Installation Caution: To avoid damaging the motherboard and its components, please do not use a force greater than 8 lb/inch on each mounting screw during motherboard installation. Installation Instructions Install the I/O shield into the chassis. I/O Shield Locate the mounting holes on the motherboard.
Page 24: Processor And Heatsink Installation
X7SLM-L User's Manual Processor and Heatsink Installation Warning: When handling the processor package, avoid placing direct pressure on the label area of the fan. Notes: 1. Always connect the power cord last and always remove it before add- ing, removing or changing any hardware components. Make sure that you install the processor into the CPU LGA 775 socket before you install the CPU heatsink.
Page 25 Chapter 2: Installation Gently lift the load lever to open the load plate. Use your thumb and your index ﬁ nger to hold the CPU at the top center edge and the bottom center edge of the CPU. North Center South Center Edge Align CPU Pin1 (the CPU corner marked with a triangle) against the socket corner that is marked with a triangle cutout.
Page 26 X7SLM-L User's Manual Do not rub the CPU against the surface or against any pins of the socket to avoid damage to the CPU or the socket.) With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed.
Page 27 Chapter 2: Installation If the CPU is properly installed into the socket, the plastic PnP cap will be automatically released from the load plate when the load lever is pushed in the lever lock. Remove the PnP cap from the motherboard. Load lever locked into place CPU properly...
Page 28: Installing A Passive Cpu Heatsink
X7SLM-L User's Manual Installing a Passive CPU Heatsink Do not apply any thermal grease to the heatsink or the CPU die -- the required amount has already been applied. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the Motherboard's and the Heatsink Bracket under- neath.
Page 29: Removing The Heatsink
Chapter 2: Installation Removing the Heatsink Warning: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instruc- tions below to uninstall the heatsink to prevent damage done to the CPU or the CPU socket.
Page 30: Installing Ddr2 Memory
Repeat step 1 to install DIMM1B if needed. Memory Support The X7SLM-L supports up to 2GB Unbuffered Non-ECC DDR2 667/533/400 in 2 DIMM slots. Populating these DIMM modules with a pair of memory modules of the same type and same size will result in interleaved memory, which will improve memory performance.
Page 31 Chapter 2: Installation DDR2 Slot Position the DIMM module's bottom key so it aligns with the receptive point on the slot. Notches Release Push the Lock/Release tabs to their Release po- sitions. Make sure that the DIMM module's side notches align with the slot's Lock/ Release Release tabs as it is pressed in.
Page 32: Connectors/I/O Ports
X7SLM-L User's Manual Connectors/I/O Ports The I/O ports are color coded in conformance with the PC 99 speciﬁ cation. See the ﬁ gure below for the colors and locations of the various I/O ports. Back Panel Connectors and I/O Ports...
Page 33: Atx Ps/2 Keyboard And Ps/2 Mouse Ports
Chapter 2: Installation ATX PS/2 Keyboard and PS/2 PS/2 Keyboard/Mouse Pin Mouse Ports Deﬁ nitions PS2 Keyboard PS2 Mouse The ATX PS/2 keyboard and PS/2 Pin# Deﬁ nition Pin# Deﬁ nition mouse are located next to the Back KB Data Mouse Data Panel USB Ports 01/ on the mother- No Connection...
Page 34: Universal Serial Bus (Usb)
X7SLM-L User's Manual Universal Serial Bus (USB) Back Panel USB 0/1 Pin Deﬁ nitions Two Universal Serial Bus ports (USB Pin# Deﬁ nition Pin# Deﬁ nition 0 and USB 1) are located on the I/O backplane. Additionally, two Type A...
Page 35: Serial Ports
Chapter 2: Installation Serial Ports Serial Ports-COM1/COM2 Pin Deﬁ nitions Two COM connections (COM1 & COM2) Pin # Deﬁ nition Pin # Deﬁ nition are located on the motherboard. COM1 is located on the Backplane I/O panel. COM2 is located below the Super I/O chip to provide additional onboard se- rial connection support.
Page 36: Video Connector
X7SLM-L User's Manual Video Connector A Video (VGA/CRT) connector is lo- cated next to COM Port1 on the I/O backplane. This connector is used to provide video and CRT display. Refer to the board layout below for the location. 1. VGA...
Page 37: Ethernet Ports
Chapter 2: Installation Ethernet Ports LAN Ports Pin Deﬁ nition Two Ethernet ports are located at on Pin# Deﬁ nition the I/O backplane. These ports accept P2V5SB SGND RJ45 type cables. (Note: Please refer TD0+ Act LED to the LED Indicator Section for LAN TD0- P3V3SB LED information.)
Page 38: Front Control Panel
X7SLM-L User's Manual Front Control Panel JF1 contains header pins for various buttons and indicators that are normally lo- cated on a control panel at the front of the chassis. These connectors are designed speciﬁ cally for use with Supermicro server chassis. See the ﬁ gure below for the descriptions of the various control panel buttons and LED indicators.
Page 39: Front Control Panel Pin Deﬁ Nitions
Chapter 2: Installation Front Control Panel Pin Deﬁ nitions NMI Button NMI Button Pin Deﬁ nitions (JF1) The non-maskable interrupt button Pin# Deﬁ nition header is located on pins 19 and 20 Control of JF1. Refer to the table on the right Ground for pin deﬁ...
Page 40: Hdd Led
X7SLM-L User's Manual HDD LED HDD LED The HDD LED connection is located Pin Deﬁ nitions (JF1) on pins 13 and 14 of JF1. Attach a Pin# Deﬁ nition hard drive LED cable here to display disk activity (for any hard drive ac-...
Page 41: Overheat (Oh)/Fan Fail Led
Chapter 2: Installation Overheat (OH)/Fan Fail LED OH/Fan Fail LED Pin Deﬁ nitions (JF1) Connect an LED Cable to the OH/ Pin# Deﬁ nition Fan Fail connection on pins 7 and 8 of JF1 to provide advanced warnings Ground of chassis overheat or fan failure. OH/Fan Fail Indicator Refer to the table on the right for pin Status...
Page 42: Reset Button
X7SLM-L User's Manual Reset Button Reset Button The Reset Button connection is located Pin Deﬁ nitions (JF1) on pins 3 and 4 of JF1. Attach it to a Pin# Deﬁ nition hardware reset switch on the computer Reset case. Refer to the table on the right for Ground pin deﬁ...
Page 43: Connecting Cables
+12V (Required) A. 24-Pin ATX Main PWR Fan5 JPW2 JPW1 B. 8-Pin Auxiliary PWR DIMM1B UNB NON-ECC DDR2 400/533/667 Required DIMM1A X7SLM-L Speaker CTRL Intel 945GC Intel CTRL Clock chip Slot 7 PCI-E x16 CTRL Slot 6 PCI 33MHz Intel ICH7R...
Page 44: External Power Connector
X7SLM-L User's Manual External Power Connector 12V 4-Pin External Power Connector In addition to the 24-pin main power connec- Pin Deﬁ nitions tor and the 8-pin auxiliary power, the 4-pin Deﬁ nition External Power connector at JP3 is used to...
Page 45: Fan Headers
Chapter 2: Installation Fan Headers The X7SLM-L has ﬁ ve fan headers (Fan1 Fan Header ~ Fan5). Fans 2~5 are system cooling Pin Deﬁ nitions fans. Fan 1 is used as a CPU fan. These Pin# Deﬁ nition fans are 4-pin fan headers. However,...
Page 46: Internal Speaker
X7SLM-L User's Manual Internal Speaker Internal Buzzer Pin Deﬁ nition The Internal Speaker can be used to Pin# Deﬁ nitions provide audible indications for various Pin 1 Pos. (+) Beep In beep codes. See the table on the right Pin 2 Neg.
Page 47: Overheat/Fan Fail Led (Joh1 )
Fan5 JPW2 A. Overheat/Fan Fail LED JPW1 DIMM1B UNB NON-ECC DDR2 400/533/667 Required B. Chassis Intrusion DIMM1A X7SLM-L Speaker CTRL Intel 945GC Intel CTRL Clock chip Slot 7 PCI-E x16 CTRL Slot 6 PCI 33MHz...
Page 48: Jumper Settings
X7SLM-L User's Manual Jumper Settings Explanation of Jumpers To modify the operation of the mother- board, jumpers can be used to choose between optional settings. Jumpers cre- ate shorts between two pins to change the function of the connector. Pin 1 is identiﬁ...
Page 49: Cmos Clear
Watch Dog must also be enabled in the BIOS. A. Clear CMOS Fan5 JPW2 JPW1 B. Watch Dog Enable DIMM1B UNB NON-ECC DDR2 400/533/667 Required DIMM1A X7SLM-L Speaker CTRL Intel 945GC Intel CTRL Clock chip Slot 7 PCI-E x16 CTRL Slot 6 PCI 33MHz...
Page 50: Onboard Indicators
X7SLM-L User's Manual Onboard Indicators Activity LED Link LED LAN Port LEDs Two LAN ports are located on the I/O Rear View (when facing the Backplane. Each Ethernet LAN port has two rear side of the chassis) LEDs. The yellow LED indicates activity,...
Page 51: Serial Ata And Hdd Connections
A. I-SATA0 Fan5 B. I-SATA1 JPW2 JPW1 DIMM1B C. I-SATA2 UNB NON-ECC DDR2 400/533/667 Required DIMM1A D. I-SATA3 X7SLM-L Speaker CTRL Intel 945GC Intel CTRL Clock chip Slot 7 PCI-E x16 CTRL Slot 6 PCI 33MHz Intel ICH7R...
Page 52: Ide Connector
X7SLM-L User's Manual IDE Connector IDE Drive Connectors Pin Deﬁ nitions An IDE Connector is located close to Pin# Deﬁ nition Pin # Deﬁ nition SATA Ports 0~3 on the motherboard. Reset IDE Ground This 44-pin connector provides support Host Data 7 Host Data 8 for 2.5"...
Page 53: Chapter 3 Troubleshooting
Chapter 3: Troubleshooting Chapter 3 Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Always disconnect the AC power cord before adding, changing or installing any hardware components.
Page 54: Memory Errors
X7SLM-L User's Manual 2. Use the speaker to determine if any beep codes exist. (Refer to Appendix A for details on beep codes.) 3. Remove all memory modules and turn on the system. (If the alarm is on, check the specs of memory modules, reset the memory or try a different one.) Memory Errors 1.
Page 55: Frequently Asked Questions
2, or by fax at (408)503-8019. Frequently Asked Questions Question: What type of memory does my motherboard support? Answer: The X7SLM-L supports up to 2 GB of unbuffered Non-ECC DDR2-667 /533/400, two-way interleaved or non-interleaved SDRAM. See Section 2-4 for details on installing memory.
Page 56: Returning Merchandise For Service
X7SLM-L User's Manual may take a few minutes to complete. Do not be concerned if the screen is paused for a few minutes. Warning : Do not shut down or reset the system while updating BIOS to prevent possible system boot failure! Also, the SPI BIOS chip installed on this motherboard is not removable.
Page 57: Chapter 4 Bios
BIOS Introduction This chapter describes the AMI BIOS Setup Utility for the X7SLM-L. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter de- scribes the basic navigation of the AMI BIOS Setup Utility setup screens.
Page 58: Starting The Setup Utility
X7SLM-L User’s Manual Starting the Setup Utility Normally, the only visible POST (Power On Self Test) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS Setup Utility. From the main menu, you can access the other setup screens.
Page 59 Chapter 4: AMI BIOS Processor The AMI BIOS automatically displays the status of processor as shown below: Genuine Intel (R) CPU @ XX.XXGHz Speed :XXXXMHz Count System Memory This displays the size of memory available in the system, in megabytes (MB). Size :XXXXMB...
Page 60: Advanced Setup Conﬁ Gurations
X7SLM-L User’s Manual Advanced Setup Conﬁ gurations Use the arrow keys to select Boot Setup and hit <Enter> to access the submenu items: BIOS Features Quick Boot If Enabled, this option will skip certain tests during POST to reduce the time needed for system boot.
Page 61 Chapter 4: AMI BIOS enabled. Use this feature to select the interrupt address. The options are [FED00000h], [FED01000h], [FED02000h], and [FED03000h]. ACPI Conﬁ guration Use this feature to conﬁ gure ACPI (Advanced Conﬁ guration and Power Interface) power management settings for your system. ACPI Aware OS Select Yes to enable ACPI support for the OS.
Page 62 X7SLM-L User’s Manual Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at boot and allow the drives that are attached to these host adaptors to func- tion as bootable disks.
Page 63: Advanced Chipset Settings
Chapter 4: AMI BIOS Execute-Disable Bit Capability (Available when supported by the OS and the CPU) Set to Enabled to enable the Execute Disable Bit which will allow the processor to designate areas in the system memory where an application code can execute and where it cannot, thus preventing a worm or a virus from ﬂ...
Page 64 X7SLM-L User’s Manual Conﬁ gure DRAM Timing by SPD Select Enable to allow the BIOS to read the SPD (Serial Presence Detect) chip which is built in the memory module in order to get the exact memory speciﬁ ca- tions. The options are Enabled and Disabled.
Page 65: Usb Functions
Chapter 4: AMI BIOS Boot Display Device This option allows the user to select the boot display device. The options are CRT on Port 0, LFP on Port2, and CRT-Port 0 & LFP-Port 2. USB Functions This feature allows the user to decide the number of onboard USB ports to be enabled.
Page 66 X7SLM-L User’s Manual IDE Conﬁ guration Submenu When this submenu is selected, the AMI BIOS automatically detects the presence of the IDE Devices and displays the following items: Floppy A This feature allows the user to select the type of ﬂ oppy drive connected to the sys- tem.
Page 67 Chapter 4: AMI BIOS Type Select the type of device connected to the system. The options are Not Installed, Auto, CD/DVD and ARMD. LBA/Large Mode LBA (Logical Block Addressing) is a method of addressing data on a disk drive. In the LBA mode, the maximum drive capacity is 137 GB. For drive capacities over 137 GB, your system must be equipped with a 48-bit LBA mode addressing.
Page 68 X7SLM-L User’s Manual DMA Mode Select Auto to allow the BIOS to automatically detect IDE DMA mode when the IDE disk drive support cannot be determined. Select SWDMA0 to allow the BIOS to use Single Word DMA mode 0. It has a data transfer rate of 2.1 MBs.
Page 69 Chapter 4: AMI BIOS Hard Disk Write Protect Select Enabled to use the feature of Hard Disk Write Protect to prevent data from being written to HDD. The options are Enabled or Disabled. IDE Detect Time Out Use this feature to set the time-out value for the BIOS to detect the ATA, ATAPI devices installed in the system.
Page 70 X7SLM-L User’s Manual Load Onboard LAN 1 Option ROM/ Load Onboard LAN 2 Option ROM Select Enabled to load the onboard LAN Option ROM for the LAN port as speciﬁ ed. The options are Enabled and Disabled. Super IO Conﬁ guration Onboard Floppy Controller Select Enabled to enable the onboard Floppy Controller.
Page 71 Chapter 4: AMI BIOS CPU Temperature, System Temperature, Fan Speed Control Modes This feature allows the user to decide how the system controls the speeds of the onboard fans. The CPU temperature and the fan speed are correlative. When the CPU on-die temperature increases, the fan speed will also increase, and vice versa.
Page 72: Security Settings
X7SLM-L User’s Manual Flow Control This feature allows the user to set the ﬂ ow control for Console Redirection. The options are None, Hardware, and Software. Redirection After BIOS POST Select Disabled to turn off Console Redirection after Power_On_Self_Test (POST). Select Always to keep Console Redirection active all the time after POST.
Page 73 Chapter 4: AMI BIOS Change Supervisor Password: Use this feature to set a supervisor password. It secures the system from unau- thorized use by restricting access to persons only with the proper supervisor-level password. Select this feature and press <Enter>, and then type in the Supervisor Password.
Page 74: Boot Conﬁ Guration
X7SLM-L User’s Manual Boot Conﬁ guration Use this feature to conﬁ gure Boot Settings: Boot Device Priority This feature allows the user to specify the sequence of priority for the Boot Device. The settings are 1st boot device, 2nd boot device, 3rd boot device, and Disabled.
Page 75: Exit Options
Chapter 4: AMI BIOS CD/DVD Drives This feature allows the user to specify the boot sequence from available CD/DVD Drives. The settings are 1st boot device and Disabled. • 1st Drive - [CD/DVD: XXXXXXXXXXX] Exit Options Select the Exit tab from the AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen.
Page 76 X7SLM-L User’s Manual Load Fail-Safe Defaults To set this feature, select Load Fail-Safe Defaults from the Exit menu and press <Enter>. The Fail-Safe settings are designed for maximum system stability, but not for maximum performance. 4-20...
Page 77: Appendix A Post Error Beep Codes
Appendix A: POST Error Beep Codes Appendix A POST Error Beep Codes This section lists POST (Power On Self Test) error beep codes for the AMI BIOS. POST error beep codes are divided into two categories: recoverable and terminal. This section lists Beep Codes for recoverable POST errors. Recoverable POST Error Beep Codes When a recoverable type of error occurs during POST, BIOS will display a POST code that describes the problem.
Page 78 X7SLM-L User's Manual Notes...
Page 79: Appendix B Installing The Windows Os
Appendix B: Installing the Windows OS Appendix B Installing the Windows OS After all the hardware has been installed, you must ﬁ rst conﬁ gure Intel South Bridge RAID settings before you install the OS and other software drivers. To install the Linux OS or to conﬁ...
Page 80: Installing The Windows Xp/2000/2003 Os For Systems Without Raid Support
X7SLM-L User's Manual Guide B-2 Installing the Windows XP/2000/2003 OS for Systems without RAID Support Insert Microsoft's Windows XP/2000/2003 Setup CD in the CD Driver, and the system will start booting up from CD. Continue with the OS installation. The Windows OS Setup screen will display.
Page 81: Appendix C Software Installation Instructions
Appendix C: Software Installation Instructions Appendix C Software Installation Instructions C-1 Installing Drivers After you've installed the Windows Operating System, a screen as shown below will appear. You are ready to install software programs and drivers that have not yet been installed. To install these software programs and drivers, click the icons to the right of these items.
Page 82: C-2 Conﬁ Guring Supero Doctor Ii
The Supero Doctor III program is a Web-base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called the SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
Page 83 Appendix C: Software Installation Instructions Supero Doctor III Interface Display Screen-II (Remote Control) Note: SD III Software Revision 1.0 can be downloaded from our Web site at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/ Manuals/SDIII/UserGuide.pdf. For Linux, we will still recommend that you...
Page 84 X7SLM-L User's Manual Notes...
Page 85 Disclaimer The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signiﬁ cant injury or loss of life or catastrophic property damage.
