Sony VAIO TZ VGN-TZ37GN/N Specifications

Specifications
Model Model VGN-TZ37GN/N
Intel ® Centrino ® Processor Technology
Processor Technology Processor Technology
• Intel ® Core™2 Duo Processor U7700 (1.33GHz) *1*2 • Intel ® Wireless WiFi Link 4965AGN • Mobile Intel
OS OS Genuine Windows Vista ® Business (English Version) with Traditional Chinese Language Pack
Mobile Intel ® 945GMS Express Chipset
Chipset Chipset
533MHz
Processor System Bus Processor System Bus
*3
Memory Bus Memory Bus 667MHz
Cache Memory Cache Memory 2MB
Pre-installed / Max Pre-installed / Max 2GB DDR2 SDRAM (Max)
Main
Memory
SO-DIMM slots SO-DIMM slots 1 SO-DIMM slot (The pre-installed memory module uses one)
120GB *4 (Ultra ATA/100, 4200rpm)
Hard Disk Drive Hard Disk Drive
DVDRW/R DL/RAM Drive
Drive Drive
Optical
Maximum Maximum DVD+R: 8x (Single Layer), 4x (Double Layer) / DVD-R: 8x (Single Layer), 4x (Dual Layer) / DVD+RW: 8x / DVD-RW: 6x /
Disc DVD-ROM: 8x / DVD-RAM: 5x / CD-ROM: 24x / CD-R: 24x / CD-RW: 24x
Reading Speed Reading Speed
Drive
DVD+R: 8x (Single Layer), 4x (Double Layer) / DVD-R: 8x (Single Layer), 4x (Dual Layer) / DVD+RW: 8x / DVD-RW: 6x /
Maximum Maximum
Writing Speed Writing Speed DVD-RAM: 5x / CD-R: 24x / CD-RW: 16x
Graphics Accelerator Graphics Accelerator Intel ® Graphics Media Accelerator 950
11.1" (WXGA: 1366 x 768) TFT Colour display (Clear Bright High Colour LCD: White LED)
Display Display
USB USB High Speed USB 2.0 x 2
i.LINK (IEEE 1394) i.LINK (IEEE 1394) 4pin (S400) x 1
Network (RJ-45) Connector Network (RJ-45) Connector 10Base-T/100Base-TX/1000Base-T x 1
Display Output Connector Display Output Connector Analogue RGB, mini D-sub 15pin x 1
Stereo mini jack x 1
Headphone Headphone
Stereo mini jack x 1
Interface Microphone Microphone
Modem Modem V.92 and V.90 Compliant x 1
Memory Stick Slot Memory Stick Slot Memory Stick (Standard/Duo Size compatible, MagicGate compatible, Memory Stick PRO compatible, High-speed data transfer compatible)
SD Memory Card Slot SD Memory Card Slot SD Memory Card *6 (SDHC compatible, MMC compatible)
DC IN DC IN x 1
Docking Station Connector x 1
Others Others
*7 ®
Wireless LAN Wireless LAN • Integrated Wireless LAN IEEE 802.11a/b/g/Draft n • Intel Wireless WiFi Link 4965AGN • Maximum data rate: 11Mbps (802.11b) /
Wireless
54Mbps (802.11a/g) / 300Mbps (Draft 802.11n) *8 • Frequency: 5GHz (802.11a/Draft n), 2.4GHz (802.11b/g/Draft n)
Connection
Bluetooth standard Ver. 2.0+EDR
Bluetooth Bluetooth
Compatible Memory Cards Compatible Memory Cards • Memory Stick (Standard/Duo Size compatible, MagicGate compatible, Memory Stick PRO compatible, High-speed data transfer
compatible) • SD Memory Card (SDHC compatible) • Multi Media Card
ExpressCard™/34 x 1
PC Card Slot PC Card Slot
x 1
Fingerprint Sensor Fingerprint Sensor
Security Chip Security Chip TCG Ver. 1.2 compliant Trusted Platform Module (TPM)
Camera Camera Effective Pixels: 640 x 480
Audio Audio • Intel ® High Definition Audio compatible • 3D audio (Direct Sound 3D support) • Built-in stereo speakers • Built-in monaural microphone
Keyboard / Input Device Keyboard / Input Device • Approx. 17mm key pitch • 1.7mm keystroke • 82 keys • Intelligent Touchpad
VGP-BPL11 Lithium-ion battery: up to 11 hours of use
Battery Bundled Battery Bundled Battery
*9
Life
Optional Long Battery Optional Long Battery VGP-BPX11 Lithium-ion battery: up to 16.5 hours of use
Dimensions (W x H x D) Dimensions (W x H x D) 277 x 22.5 - 29.8 x 198.2mm
Weight Weight 1200g (including the supplied battery)
Included Software Included Software • AV Entertainment: Instant Mode, Image Converter 3 • Video Edit/Playback: VAIO Movie Story 1.1, VAIO Content Exporter
® ® *10
1.2, Adobe Premiere Elements 4.0, VAIO Edit Components 6.4 , WinDVD for VAIO 8.0 • DVD Creation: Click to Disc 1.0,
Click to Disc Editor 1.0 • Music: VAIO MusicBox 1.1, SonicStage Mastering Studio 2.4, SonicStage Mastering Studio Audio
Filter 2.3 • Still Image/Photo: Windows ® Photo Gallery, Picasa™, Adobe
• Home Network: VAIO Media 6.0 • Word Processor/Spreadsheet: 60-Days Trial Version of Microsoft
2007 *11 • Tool: Roxio Easy Media Creator 9.1, Adobe ® Reader ® 8, Norton Internet Security™ 2008 (Installer)
Control Center 2.1, VAIO Camera Capture Utility 2.7, Setting Utility Series 3.1, Infineon TPM Professional Package 3.0 (Installer),
VAIO Launcher 1.1, ArcSoft Magic-i™ Visual Effects 1.0, Protector Suite QL 5.6 • Support: VAIO Recovery Center, VAIO Update
3.0, VAIO Data Restore Tool 1.0
Supplied Accessories Supplied Accessories • AC Adaptor (VGP-AC16V14) • Lithium-ion battery (VGP-BPL11) *13 • Cleaning cloth • Windows
One year *14
Warranty Warranty
Features and specifications are subject to change without notice.
*1 CPU speed will be reduced under certain operating conditions. *2 Intel ® Virtualization Technology is not supported on VAIO. *3 The maximum operating frequency of the memory bus is 533MHz due
to the capacity limitation of the processor system bus. *4 GB means one billion bytes when referring to hard disk drive capacity. Accessible capacity may vary. A portion of hard disk space is reserved as
a recovery partition. *5 Compatibility confirmed with Sony branded "Memory Stick" media only. *6 The copyright protection of the SD memory card is not supported. *7 The maximum communication
distance can vary depending on the obstacles or the distance between the communication devices, the radio waves, the operating system or the software being used. *8 The communication speed
varies depending on the distance between communication devices, existence of obstacles between such devices, the device configuration, the radio conditions, and the software in use. In addition,
communication may be cut off depending on the radio conditions. *9 Estimated battery life (under JEITA Battery Run Time Measurement Method ver. 1.0). Actual battery life may vary with different
operating conditions and settings. For further details, please visit vaio-online.sony.com *10 Though the software is not pre-installed, the official license is registered. It can be downloaded free of charge.
*11 This software is intended for evaluation purposes only. It must be activated before actual use, and the activation procedures will be detailed during initial launch. Activation requires Internet access,
which enables certain functions included. This software has an expiration date of 60 days from date of first use, at which time the software will operate under reduced-functionality mode, limiting options
and operations. *12 Free use of 90 days. Further update will be charged. *13 This product may only function with a genuine Sony battery designed for this model. *14 Warranty conditions may vary by
region.
The trademarks, including but not limited to "SONY", "VAIO", "Memory Stick" and "SonicStage" are either trademarks or registered trademarks of Sony Corporation and/or its s ubsidiaries. Adobe, Adobe
Photoshop, Adobe Reader and Adobe Premiere are trademarks of Adobe Systems Incorporated in the United States and/or other countries. Centrino, Centrino Inside, Centrino Logo, Core Inside, Intel,
Intel Logo, Intel Core, Intel Inside, Intel Inside Logo, Pentium and Pentium Inside are trademarks of Intel Corporation in the U.S. and other countries. Windows, Windows Vista, the Windows logo and
Microsoft are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. All other product and brand names may be trademarks or registered trademarks
of their respective owners. Whilst information given is true at time of printing, small production changes in the course of our company's policy of improvement through research and design might not
necessarily be included in the specifications. E&OE. Actual models may differ slightly in appearance to illustrations provided.
<OS Downgrade to Windows® XP>
Note that you cannot use the following features and software that you could use on Windows Vista® after downgrading to Windows® XP: Plug and Display feature, Instant Mode (on models with Instant
Mode only), VAIO HDD Protection (on models with a hard disk drive only), Sony original audio and visual software, Non-Sony software (e.g. Norton Internet Security, InterVideo WinDVD, etc.), VAIO
Recovery Tool. Refer to the Windows® Professional Install Disc User Guide for further details.
Optional Accessories for VGN-TZ37GN/N
(availability depends on region)
VGP-PRTZ1 VGP-CKTZ2
Black (B), Gold (N), White (W)
Docking Station
Carrying Case
l Monitor connector
l Perfectly sized for VAIO TZ
(Analogue RGB, mini D-SUB 15pin)
l Network connector (Gigabit Ethernet) l Genuine leather material
l Hi-Speed USB (USB 2.0) connector (x3) l Magnet-type flap for easy opening/closing
VGP-BPX11 VGP-CKTZ3
Lithium-ion Battery (LL) Carrying Case
l Large capacity rechargeable battery l Perfectly sized for VAIO TZ
l Up to 16.5 hours l Light material: polyurethane and nylon
*9 of battery time
l New VAIO Smart Protection™
l Magnet-type flap for easy opening/closing
vaio-online.sony.com
Sony recommends Windows Vista
VGN-TZ37GN/N
® 945GMS Express Chipset
1
2
3
4
9 10 11 12
*5
16 18 19 20
17
1.
Built-in MOTION EYE camera
2. Built-in speakers (stereo)
3. Fingerprint sensor
4. Optical disc drive
® Photoshop ® Elements 6.0 (Installer)
® 5.
Office Professional Manual eject hole
*12 • Utilities: VAIO
6. Substitute drive eject button
7. Monitor connector (Analogue RGB, mini D-SUB 15pin)
8. Power button
9. DC IN connector
® XP Professional Install Disc
10. Modem connector
11. Network (Ethernet) connector
12. i.LINK TM (IEEE 1394) S400 connector
TM
13. ExpressCard /34 slot
14. Hi-Speed USB (USB 2.0) connector
15. Security slot
16. Headphones jack
17. Built-in microphone (monaural)
18. Microphone jack
19. Memory Stick TM PRO/Duo media slot
20. SD Memory Card slot
21. AV MODE button
22. Play/Pause button
23. Stop button
24. Previous track button
25. Next track button
26. Disc drive eject button
27. WIRELESS switch
VGP-CP11
Carrying Pouch
l Embossed VAIO logo
l Handy mini-pouch
l Opens smoothly and quietly
VGP-BMS33
Black (B), Gold (N), Silver (S), White (W)
®
Bluetooth Laser Mouse
l Smart wireless mouse for mobile use
l Highly accurate laser sensor
l Innovative PTFE sole for precise operation
l Sensor resolution: 800 dots per inch
® Business.
5 6 7 8
13 14 15
VAIO TZ
21 22 23 24 25 26
27
All you need for a chic mobile lifestyle
Intel ® Centrino ® Processor Technology
VGN-TZ37GN/N
