Page 1: User Manual
RC801-60B-FV35, RC803-60B-FV35, RC805-60B-FV35 Series Standalone V.35＋E1 Dual Interface Fiber Optic Modem User Manual REV.N Raisecom Technology Co., Ltd. (05/2006) -
Page 2: Cautions
Raisecom Technology Co., Ltd 1. Cautions Please read the following notices carefully before installing and using the device. Raisecom does not respond to any loss that caused by violating safety notice. RC801/803/805-60B-FV35 series device provides V.35 synchronization data interface which complied with ITU standard. - Page 3 Raisecom Technology Co., Ltd coaxial-cable is consistent, and so that the shield layer of the coaxial-cable can has the same grounding. There must be grounding protection for the sake of safety and stability. Do not disassemble the device yourself, we regard it...
-
Page 4: Table Of Contents
Raisecom Technology Co., Ltd Contents Cautions........................1 Overview ........................5 2.1. Introduction ......................5 2.2. Main features ...................... 5 2.3. Model Description ....................6 Parameters ....................... 8 3.1. Fiber Optic Interface Specification ..............8 3.2. V.35 Interface Specification................. 8 3.3. - Page 5 Raisecom Technology Co., Ltd Appendix A: Introduction of Cable Making ..............27 1. CBL-V35-M34M/M34F-D Cable making Instruction ..........27 2. CBL-V35-M34M/M34M-X-D Cable making Instruction ......... 27...
-
Page 6: Overview
Raisecom Technology Co., Ltd 2. Overview 2.1. Introduction RC801/803/805-60B-FV35 series device is PDH fiber optic modem which is deployed to transmit V.35 signals and transparent E1 data line on fiber. It also provides solution for Router remote connection and is widely used in constructing Wide Area Networks. -
Page 7: Model Description
Raisecom Technology Co., Ltd IT provides fault pass function to transfer alarm of line side to V.35 interface so that to judge E1 line error through router. Features of the second tributary E1 interface of client side: It complies with PDH transmission conception to realize the transparent transmission of E1 data and clock setting in fiber line. - Page 8 Raisecom Technology Co., Ltd 0-25km Module type, two E1 interfaces (four BNC or two RJ45), one optical port, SM dual strand (DSC), RC802-60B-S2 10-60km Module type, two E1 interfaces (four BNC or two RJ45), one optical port, SM dual strand (DSC),...
-
Page 9: Parameters
Raisecom Technology Co., Ltd 3. Parameters 3.1. Fiber Optic Interface Specification Bit rate: 100Mbps Line code: 4B5B Fiber connecter: SC (RC801-60B-FV35-S1 dual strand fiber port also has FC type) Model Type Transmission Laser Receiver Launch Over Receiving Typical Wavelength Type... -
Page 10: Cable Type
When connect this series product with DTE equipments such as routers through M34 interface, please use the special DTE router cable. When the cable is not long enough please order the extended cable CBL-V35-M34M/M34F-D from Raisecom (in Appendix). When connecting this series product with other DCE equipments, the cross cable CBL-V35-M34M/M34M-X-D is necessary, and please order it from Raisecom (in Appendix). -
Page 11: How To Use
Raisecom Technology Co., Ltd 4. How to Use 4.1. Description of the Front Panel RC800-60B-FV35 SERIES CH1 V35 CH2 E1 LOOP PWR/PAT LOOP BALANCE View of the front panel 4.1.1. Power Supply/Error Code Test Indicator PWR/PAT Green/Yellow: Steady Green, built-in power works in good condition. -
Page 12: Interface Data Channel Indicator
Raisecom Technology Co., Ltd Non-periodically flash: There is 1E-3 error code alarm in remote or local optical receiving signal; Steady off: There is no error code alarm in local/remote optical receiving signal. 4.1.3. V.35 Interface Data Channel Indicator AIS Red: Steady Light: There is AIS alarm in E1 data channel of local optical receiving signal;... -
Page 13: E1 Interface And It's Indicator
Raisecom Technology Co., Ltd Steady Off: There is no receiving data in V.35 interface. Notice: This device provides CRC4 checkout’s auto-negotiation function. If there is CRC4 checkout signal in E1 data of optical interface the CRC4 checkout function will be enabled automatically, and the CRC alarm indicator will be available when there is CRC4 error. -
Page 14: Power Supply Switch
Raisecom Technology Co., Ltd -48V PGND BGND Back Panel of the DC Device 4.2.1. Power Supply Switch I stands for ON, O stands for OFF 4.2.2. Power Connector AC Power connector: It is the standard three-phase power connector. Please make sure that the grounding is correct. -
Page 15: Dip-Switch On The Bottom
Raisecom Technology Co., Ltd Receive Timing (B) — RCK(B) Send Data (A) — TD(A) Send Data (B) — TD(B) Send Timing (A) — TCK(A) Send Timing (B) — TCK(B) Terminal Timing (A) — SCTE(A) Terminal Timing (B) — SCTE(B) Request to Send — RTS Clear to Send —... -
Page 16: Setup Of Timeslot Dip-Switch (Sw1 To Sw4)
Raisecom Technology Co., Ltd 4.3.1. Setup of Timeslot Dip-switch (SW1 to SW4) Timeslot switches are SW1, SW2, SW3 and SW4. “√” indicates enable; “×” indicates disable SW1 definition (default is all OFF) 1st bit 2nd bit 3rd bit 4th bit... - Page 17 Raisecom Technology Co., Ltd Clock Clock Timeslot Error Phase Tributary Tributary Loop back Follow Code Bidirectional Bidirectional position Test loopback loopback √ √ Reverse √ √ Local × × Positive × × Remote 1. The 1 and 2 bit: Clock mode choosing dip-switch Timing1, Timing2 (default is...
- Page 18 Raisecom Technology Co., Ltd The device will add test sequence to user data channel after the error code test function is enabled. This function is available in fractional mode and unframed (transparent) mode, and when this function is enabled the V.35 operation will intermit.
- Page 19 Raisecom Technology Co., Ltd Tributary Tributary Bidirectional Bidirectional Remote Loopback loopback disable loopback disable Tributary V.35 interface remote bidirectional loopback sketch map: V.35 V.35 V.35 Error Code V.35 Error Code Equipment Local Fiber Equipment Fiber Remote Fiber Optic Modem Optic Modem Above figure is the result of configuring remote bidirectional loopback of 1 tributary V.35...
-
Page 20: Function Dip-Switch (Sw6)
Raisecom Technology Co., Ltd V.35 and E1 interface both remote bidirectional loopback sketch map: V.35 Error code V.35 Error code V.35 V.35 equipment equipment Local fiber Remote fiber Fiber E1 Error code optic modem optic modem E1 Error code equipment equipment Above figure is the result of the configuring remote bidirectional loopbacks of both V.35... -
Page 21: Impedance Choosing Dip-Switch Sw7
Raisecom Technology Co., Ltd be closed and DTE device will have some reflection. When the fault pass function is enabled, and if there is remote alarm on fiber optic modem, that is to say there are errors on fiber transmitting side, the CTS signal of V.35 interface will be closed and DTE device will have some reflection. -
Page 22: Basic Connection Type
Raisecom Technology Co., Ltd 4.5. Basic Connection Type The connection topologies introduced in this part is only for user reference. Users are advised to design and deploy the most appropriate topology according to their specific environment. 4.5.1. Point-to-point, ‘Master Clock – Slave Clock’ Topology When connecting Routers or other V.35 interface equipment point to point, routers should... -
Page 23: Extended Connection Type
(fiber resuming clock). 4. In this connection type, the E1 CRC checkout function of ATM device is commonly disabled, but the V.35 data channel CRC checkout function of Raisecom RC801-60B-FV35 is enabled, so please adjust their CRC property to consistent. -
Page 24: Installation & Preparation
Raisecom Technology Co., Ltd 5. Installation & Preparation 5.1. Before installation Please make sure that your V.35 cable matches the equipment you want to connect Please check whether the equipment has been destroyed If you do not use network management, please configure the device through DIP-switch before installation. -
Page 25: Equipment Deployment
Raisecom Technology Co., Ltd 5.3. Equipment Deployment Keep the center office clean The deployment and settlement should be in order. Configure the clock mode, time slot, master/slave setting and other parameters according to the specific connection type. 5.4. Connection Diagnoses... - Page 26 Raisecom Technology Co., Ltd 6. F & Q If there is any problem during installation and operation, please try the following solutions. If the problems still cannot be solved, please contact distributors for technical support. Power/Error code test indicator (PWR/PAT) is not on Answer: Power supply fails.
- Page 27 Answer: The optical interface of this equipment deploys PDH technology, so the optical interface can only communicate with Raisecom RC800 series optical modem. But if the remote site is E1 interface fiber optic modem, the E1 interface can communicate with all the other venders’...
-
Page 28: Appendix A: Introduction Of Cable Making
Converter Router CBL-V35-M34M/M34F-D User DTE cable When you order this cable from Raisecom or our agency please make sure the length you want. If you want to make the cable by yourself please refer to below table: ISO2593Male（M34M） V.35 STD Name ISO2593 Female（M34F）... - Page 29 Equipment CBL-V35-M34M/M34M-X-D User DTE Cable When you order this cable from Raisecom or our agency please make sure the length you want. If you want to make the cable by yourself please refer to below table: The two ends of the cable are both M34 connector.
- Page 30 Raisecom Technology Co., Ltd BROADBAND to RAISECOM @2005 Raisecom Technology Co., Ltd. All trademarks are the property of their respective owners. Technical information may be subject to change without prior notification.
