www.raisecom.com
RC1104-FE-4W (A)
User Manual
(Rel_01)

Advertisement

Table of Contents
loading

Related Manuals for Raisecom RC1104-FE-4W

Summary of Contents for Raisecom RC1104-FE-4W

  • Page 1 RC1104-FE-4W (A) User Manual (Rel_01)
  • Page 2 Website: http://www.raisecom.com Tel: 8610-82883305 Fax: 8610-82883056 Email: export@raisecom.com Address: Raisecom Building, No. 11, East Area, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing, P.R.China Postal code: 100094 ----------------------------------------------------------------------------------------------------------------------------------------- Notice Copyright © 2014 Raisecom All rights reserved.
  • Page 3 RC1104-FE-4W (A) User Manual Preface Preface Objectives This document describes overview, hardware structure, functions, hardware installation, and technical specifications of the RC1104-FE-4W. Versions The following table lists the product versions related to this document. Product name Product version Hardware version RC1104-FE-4W A.02 or later...
  • Page 4 Raisecom RC1104-FE-4W (A) User Manual Preface General conventions Convention Description Times New Roman Normal paragraphs are in Times New Roman. Arial Paragraphs in Warning, Caution, Notes, and Tip are in Arial. Names of files, directories, folders, and users are in boldface.

  • Page 5: Table Of Contents

    Raisecom RC1104-FE-4W (A) User Manual Contents Contents 1 Product overview........................... 1 1.1 Overview ................................1 1.2 Features ................................1 1.3 Ordering information............................2 2 Technical specifications ....................... 3 2.1 Basic technical specifications ........................... 3 3 Preparing for installation and connecting cables ..............4 3.1 Verifying interface type ............................
  • Page 6 Figures Figures Figure 3-1 Connecting cable ..........................4 Figure 3-2 Point-to-point networking with the RC1104-FE-4W ................5 Figure 3-3 RC1104-FE-4Wworking as the remote end of the RC1108-SHDSL-2W× 8 ........5 Figure 3-4 Installing device in 16-slot chassis ....................... 7 Figure 3-5 DC power module ..........................7 Figure 4-1 Front panel of the RC1104-FE-4W ......................
  • Page 7 RC1104-FE-4W (A) User Manual Tables Tables Table 1-1 Ordering information about the RC1104-FE-4W ................... 2 Table 2-1 Basic technical specifications ......................... 3 Table 3-1 PIN definitions of RJ45 connector ......................4 Table 3-2 Device models on both local and remote ends ..................5 Table 3-3 Device models on both local and remote ends ..................

  • Page 8: Product Overview

    G.SHDSL.BIS feature. It uses two pairs of twisted-pair cables (bare wire) for transmission with the maximum transmission rate of 2 × 11.4 Mbit/s. The RC1104-FE-4W can be used to transmit signals through networks when the rate keeps at 2 × 5.7 Mbit/s and the Ethernet lines are extended to 2.6 km.

  • Page 9: Ordering Information

    RC1104-FE-4W (A) User Manual 1 Product overview 1.3 Ordering information The RC1104-FE-4W is a plug-in device. Table 1-1 Ordering information about the RC1104-FE-4W Model Description Modular device, supporting dual-line pair transmission and being inserted into the RC002 chassis or single-slot chassis ...

  • Page 10: Technical Specifications

    Raisecom RC1104-FE-4W (A) User Manual 2 Technical specifications Technical specifications 2.1 Basic technical specifications Table 2-1 Basic technical specifications Technical specification Description Dimension (mm) 91 (Width) × 25.2 (Depth) × 152 (Height) Weight (g) Interface type RJ45 Operating temperature (° C) 0–45...

  • Page 11: Preparing For Installation And Connecting Cables

    Preparing for installation and connecting cables 3.1 Verifying interface type The RC1104-FE-4W uses the voice-grade twisted-pair cable (telephone wire) as the transmission medium and RJ45 connector (PIN 1 and PIN 2; PIN 4 and PIN 5) Figure 3-1 Connecting cable...

  • Page 12: Verifying Cable Type

    3.4 Connecting to the same device When the RC1104-FE-4W series devices are interconnected with each other, the following requirements on models should be met. Otherwise, the link is disconnected or the data are transmitted improperly.

  • Page 13: Connecting To Other Device (Electrical Interface)

    Step 1 Install the 19-inch 3U standard RC002-16 chassis or single-slot chassis on the rack. Step 2 Align the RC1104-FE-4W with the guiderail and insert it into the chassis. Step 3 Fasten the RC1104-FE-4W with captive screws, as shown in Figure 3-4.

  • Page 14: Installing Dc Power Module

    Raisecom RC1104-FE-4W (A) User Manual 3 Preparing for installation and connecting cables Figure 3-4 Installing device in 16-slot chassis 3.7 Installing DC power module As shown in Figure 3-5, the DC power module provides three cable terminals, that is, -48 V, GND, and 0 V.

  • Page 15: Actual Line Measurement

    Raisecom RC1104-FE-4W (A) User Manual 3 Preparing for installation and connecting cables DC: -48 V –  Voltage range AC: 85–264 V – DC: -36 to -72 V – 3.9 Actual line measurement The common telephone wire (wire diameter: 0.4 mm/0.5 mm/0.6 mm) is used as the connecting line.

  • Page 16: Leds

    Raisecom RC1104-FE-4W (A) User Manual 4 LEDs LEDs 4.1 Front panel Figure 4-1 Front panel of the RC1104-FE-4W Table 4-1 LEDs on the RC1104-FE-4W Interface Name Description  ON: the link is connected properly. LNK1  OFF: the link is connected improperly.
  • Page 17 Raisecom RC1104-FE-4W (A) User Manual 4 LEDs Interface Name Description Remote device  ON: the remote device is discovered.  OFF: the remote device is not discovered. Module  ON: the power module works properly. Power LED  OFF: the power module works improperly.

  • Page 18: Dip Switches

    RC1104-FE-4W (A) User Manual 5 DIP switches DIP switches 5.1 Overview The RC1104-FE-4W can be configured through the DIP switches, including SW1, SW2, and SW4. 5.1.1 SW1 SW1 is an 8-bit switch. Definitions for each bit are listed in Table 5-1...

  • Page 19: Sw2

    Raisecom RC1104-FE-4W (A) User Manual 5 DIP switches Usage Status Description ANNEX mode. ANNEX B/G 2W mode Configure the 4W/2W mode. 4W mode The SHDSL coding mode may influence the interface rate. Table 5-2 Coding mode and interface rate Coding mode...
  • Page 20 Raisecom RC1104-FE-4W (A) User Manual 5 DIP switches When bit 8 is OFF, the rate can be configured as (1–178)× 64 Kbit/s through bits 1–6. The rate is divided into two ranges (1–89)× 64 Kbit/s and (90–178)× 64 Kbit/s by Rate 5.
  • Page 21 Raisecom RC1104-FE-4W (A) User Manual 5 DIP switches Rate 5 Rate 4-0 STU-C rate STU-R rate ON-ON-ON-ON-ON 90× 64 Kbit/s (90–178)× 64 Kbit/s ON-ON-ON-ON-OFF 91× 64 Kbit/s (90–178)× 64 Kbit/s ON-ON-ON-OFF-ON 92× 64 Kbit/s (90–178)× 64 Kbit/s ON-ON-ON-OFF-OFF 93× 64 Kbit/s (90–178)×...

  • Page 22: Sw4

    Raisecom RC1104-FE-4W (A) User Manual 5 DIP switches Rate 5-0 STU-C rate STU-R rate ON-ON-ON-OFF-ON-OFF (179+5)× 64 Kbit/s (179–235)× 64 Kbit/s OFF-OFF-OFF-ON-ON-ON (179+56)× 64 Kbit/s (179–235)× 64 Kbit/s OFF-OFF-OFF-ON-ON-OFF 235× 64 Kbit/s (179–235)× 64 Kbit/s 5.1.3 SW4 SW4 is a 4-bit switch, that is, SHDSL interface external loopback (G.SHDSL interface data loopback), SHDSL interface internal loopback (electrical interface data loopback), reserved bit, and reserved bit.

  • Page 23: Network Management Features

    6 Network management features Network management features 6.1 Checking device information Through the NView NNM system, you can check basic information about the RC1104-FE- 4W, as well as control and configure the RC1104-FE-4W. Table 6-1 Checking device information Item Value Description ...
  • Page 24 Raisecom RC1104-FE-4W (A) User Manual 6 Network management features Item Value Description  Open  Shut down  Shut down due to remote Electrical Interface: Electrical Interface Configurable electrical interface failure  Shut down due to G. interface failure ...
  • Page 25 Raisecom RC1104-FE-4W (A) User Manual 6 Network management features Item Value Description  Enable G Interface: Line Probe Configurable  Disable G. Interface: Max. Line Rate (N× 64 Kbit/s) Configurable G. Interface: Min. Line Rate (N× 64 Kbit/s) Configurable Uncontrollable and G.

  • Page 26: Configuring Device

    Raisecom RC1104-FE-4W (A) User Manual 6 Network management features Item Value Description Uncontrollable and G. Interface Current 24-Hour Statistics Table read-only G. Interface Current Recent 7× 24-Hour Uncontrollable and Table and K-line diagram Statistics read-only Uncontrollable and G. Interface: LOS Times...

  • Page 27: Loopback Detection

    Raisecom RC1104-FE-4W (A) User Manual 6 Network management features – Annex type Coding mode Max./Min. rate (64 Kbit/s) autopam 3–89 When two G. interfaces are interconnected, the Annex type and coding mode of these two interfaces should be identical. Otherwise, the link may be disconnected.
  • Page 28 Address Raisecom Building, No. 11, East Area, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing, P.R.China Postal code: 100094 Tel: +86-10-82883305 Fax: 8610-82883056 http://www.raisecom.com Email: export@raisecom.com...
