START HERE
How do I attach the stand to my TV?
(not for wall mounting)
You'll need: A Phillips screwdriver and a soft surface to lay the TV on.
A Carefully place your TV face-down on a cushioned, clean surface to
QUICK SETUP
B Secure the stand column to your TV with the ve provided M4 × 8 mm screws
GUIDE
C Secure the TV stand to the stand column with the four provided B4 × 18 mm
32" LED TV
NS-32D311NA15
Thank you
How do I prepare my TV for wall mounting?
for purchasing this state-of-the-art
(not for use with a TV stand)
Insignia television. We hope you enjoy
You'll need: A soft surface to lay the TV on.
the quality and reliability of this
A Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages and scratches.
television for years to come.
B See the instructions that came with your wall mount for more information about how to correctly mount your TV.
Roku Ready®
Included accessories
Your TV is certi ed to work with the
Roku Streaming Stick™.
Instantly stream 1000+ entertainment
channels, including Net ix, Hulu Plus,
Pandora, and more. Connect the
Streaming Stick (not included) to the
purple MHL port on your TV and enjoy.
FIND YOUR
USER GUIDE ONLINE!
We are going green so a copy of your
User Guide is not provided in the box
but is available online.
Go to www.insigniaproducts.com,
then click Support & Service. Enter your
model number in the box under Manual,
Firmware, Drivers & Product Information,
then click .
M4 screws (8 mm length)
(5 pcs.)
B4 screws (18 mm length)
(4 pcs. )
protect the screen from damages and scratches.
(the short screws).
screws (the long screws).
- OR -
Which cables do you have?
Your TV has several di erent jacks for connecting devices. For the
STOP!
best video quality, use the best available connection.
Do not plug your
VIDEO QUALITY
power adapter in
until all other devices
BEST
have been
connected.
BETTER
Component video and analog audio
GOOD
Composite video and analog audio (AV)
GOOD
Note: You can also connect a DVI device to your TV. See your online User Guide for
connection instructions.
Features
Power adapter
Front view
Power indicator
Remote control sensor
Note: The control buttons are on the
bottom edge of the screen.
Remote control
and two AAA batteries
Back view
Stand column
T
V stand
DC IN
Note: Images may not necessarily represent the exact design of your television.
Before using your new product, please read these instructions to prevent any damage.
A
MAKING CONNECTIONS
How do I watch TV (cable or satellite receiver) or connect a device such as a DVD or
Blu-ray Disc player, game console, Roku Streaming Stick™, or MHL-enabled device?
JACK TYPE
CABLE CONNECTOR
Using an HDMI cable (BEST)
HDMI video/audio
Coaxial video/audio
Using component cables (BETTER)
- OR -
Using an AV cable (GOOD)
AUDIO/VIDEO OUT
MENU
INPUT
V
O
- L
VOL+
CH
CH
How do I connect my TV to an antenna or cable wall jack?
PC / DVI
DC IN
AUDIO IN
B
M4 × 8 mm screws
Front
Component cable option
Note: Connect the yellow video cable
connector to the green VIDEO/Y jack
on the back of your TV.
VGA
ANT / CABLE
DC IN
C
B4 × 18 mm screws
Multipurpose jacks: You can plug any
device that uses HDMI into any HDMI
jack. However, certain devices must be
connected to the HDMI1 (MHL) or
HDMI2 (ARC/DVI) jack. See the
instructions that came with your MHL,
ARC, or DVI device for more information.
Note: The HDMI2 (ARC/DVI) jack is a
shared jack. This means you can only
connect one DVI or ARC device at a
time.
Note: The component video and AV
jacks are shared. This means you can
connect only one component video or
AV device at a time. We suggest using
HDMI if your device supports it.
AUDIO/ VIDEO
OUT
AV cable option
CABLE
OVER
