On-Q 364887-01 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

WIRELESS ACCESS POINT

P/N 364887-01(In-Ceiling)
P/N 364891-01(In-Wall)
OWNER'S MANUAL
1307877 REV.B
301 Fulling Mill Road, Suite G
Middletown, PA 17057
(800)-321-2343
Page ii
©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved.
www.onqlegrand.com

Advertisement

Table of Contents
loading

Related Manuals for On-Q 364887-01

Summary of Contents for On-Q 364887-01

  • Page 1: Wireless Access Point

    WIRELESS ACCESS POINT P/N 364887-01(In-Ceiling) P/N 364891-01(In-Wall) OWNER’S MANUAL 1307877 REV.B 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343 Page ii...
  • Page 2 Protection requirements for electromagnetic compatibility in [Article 3.1b] • Testing for electromagnetic compatibility in [EN 301 489-1] & [EN 301] 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343 Page ii...
  • Page 3 Keep the device away from excessive heat and humidity and keep the device free from vibration and dust. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...

  • Page 4: Table Of Contents

    K. System Status L. Wireless Status VI. Troubleshooting A. Contact Information B. Hardware Situations C. Software Situations VII. Glossary 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343 Page iv...

  • Page 5: Introduction

    • Mirrors, especially silver-coated, negatively affect transmission performance. Your On-Q WAP 802.11g is powered over the single Cat 5e cable that connects it to the service provider. A power supply inserts power onto the Cat 5e cable through an inserter module, and then this power is extracted for use at the WAP location.

  • Page 6: Product Overview

    Wireless security via Wired Equivalent Privacy (WEP) and WiFi Protected Access (WPA) encryptions • Firmware upgrades available to stay current with latest specification B. Components Included The On-Q WAP 802.11g (either In-Ceiling or In-Wall version) includes the following components: • WAP Assembly • WAP Cover •...
  • Page 7 INPUT – This RJ-45 connector is where the Cat 5e cable from the Power Over Cat 5e Inserter Module in the On-Q Enclosure plugs in. There is an Extractor Module in the WAP Assembly that breaks out the required DC power from the data on the input Cat 5e cable connection.
  • Page 8 NOTE: Although the WAP is shipped from On-Q with its IP address set to 192.168.40.1 (in the On-Q product 192.168.40.xxx sub-network), if you push the reset button for five seconds, the WAP is reset to the factory default IP address of 192.168.1.220, and will have to be re-configured to the 192.168.40.xxx sub-network to work with the other On-Q...

  • Page 9: Installation

    III. Installation The On-Q WAP 802.11g is best installed during new construction in two steps; at “rough-in” with the other low voltage cabling such as TV and Phone, but prior to drywall being installed, and at “trim-out” after the drywall is installed and painted. These steps are detailed below: A.

  • Page 10: Trim-Out" Steps

    2. It should then be plugged into the “INPUT” connector on the rear of the WAP Assembly as shown in Figure 8. 3. The On-Q WAP 802.11g Assembly can then be screwed into the triple gang box and the cover inserted, insuring that the LEDs on the WAP line up with the holes in the cover (see Figure 9).
  • Page 11 5. A supplied Cat 5e patch cable is then connected from the input RJ-45 jack of the Power over Cat 5e Inserter Module to one of the LAN ports on the On-Q or third party Router, or directly to a Broadband Modem.

  • Page 12: Basic Configuration

    IV. Basic Configuration The On-Q WAP 802.11g is typically configured in one of two ways; (1) From a portable PC connected through the “Data In” port of the Power Inserter Module in the enclosure which is then connected through its “Data/Power Out” port to a Cat 5e cable to the WAP, or (2) From a PC in one of the rooms of the house, connected through an outlet in the room to the enclosure where it is patched to the “Data In”...

  • Page 13: Configuring A Network Interface Card To Talk To A Wap

    5. Click the Properties button to go to the Local Area Connection Properties screen. (For Vista, you may need to click on Continue under the User Account Control popup) 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...
  • Page 14 Internet Protocol (TCP/IP) Properties screen. Figure 14 8. Click on “Use the following IP Address:” so that the circle is filled (see Figure 14). 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343...

  • Page 15: Logging On To The Wap

    9. For a new WAP from On-Q on the 192.168.40.xxx sub-network, enter 192.168.40.10 into the IP Address field, or for a WAP that has been reset, enter 192.168.1.10 into the IP Address field. 10. Enter 255.255.255.0 into the Subnet Mask field.

  • Page 16: Initial Wireless Access Point Setup

    Advanced Setting. Figure 17 NOTE: As shown in Figure 17, the On-Q WAP can act as one of four different devices. On-Q utilizes it as an Access Point (or AP) for the On-Q WAP application and will concentrate on that portion of its functionality for the rest of this documentation.
  • Page 17 Access Point area. Then click on Apply at the lower right corner of the screen. (see Figure 20). Figure 20 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343...

  • Page 18: Returning The Pc To Dhcp Control

    5. Next you need to change how the On-Q WAP gets its IP Address (manually instead of automatically) and give it an IP address that will work with the rest of the On-Q Data Products in the 192.168.40.xxx sub-network. Click on “IP Config” from the list on the left of the screen and you will see the IP Config –...
  • Page 19 6. Ensure the box next to Internet Protocol (TCP/IP) is selected (see Figure 23). (For Vista, use Internet Protocol Version 4 (TCP/IPv4) 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...
  • Page 20 (For Windows 2000 you will have to restart the computer to save these settings). 10. After the reboot (if appropriate), your PC should be now be ready for operation as before, directly through the On-Q Router, or through the On-Q WAP (if a Wireless NIC card was installed).

  • Page 21: Advanced Configuration

    V. Advanced Configuration The On-Q WAP 802.11g has many advanced configuration options to tailor it to your specific needs. Use the list on the left of any screen and click on “Wireless” to see some of the advanced configuration functions (see Figure 25).

  • Page 22: Wireless Bridge Configuration

    “Auto” and click on the “AP Scan” button. Information, including MAC Address, SSID, security settings, Channel number and signal strength will be returned. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...

  • Page 23: Wireless Access Control Configuration

    3. Use the “Apply” button to save your new setting (without re-starting), and the “Finish” button to save your setting and restart the WAP. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...

  • Page 24: Wireless Radius Setting Configuration

    2. You will need to enter the IP address of the RADIUS Server, its UDP port number and a connection secret (password to use for a RADIUS Server connection. Figure 29 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343...

  • Page 25: Wireless Advanced Configuration

    6. The Fragmentation Threshold function allows 802.11 frames to be segmented into defined sizes (256-2346). If you are experiencing a large number of collisions, a smaller size may help with overall throughput. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343...

  • Page 26: System Setup Global Settings

    WAP configuration. Figure 31 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343...

  • Page 27: System Setup Operation Mode

    Firmware Upgrade screen (see Figure 33). This screen shows the current firmware installed on your WAP. If you have downloaded a new firmware file from the On-Q Tech Support area of our website (www.onqlegrand.com), browse to the file location and click the “Upload” button. The WAP will reboot automatically at the end of the firmware upgrade process.

  • Page 28: System Setup Setting Management

    WAP after installed and press the Reset tab as shown in Figure 4 to perform the same function. Figure 35 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343...

  • Page 29: System Status

    NOTE: Although the WAP is shipped with its default On-Q IP address (192.168.40.1) in the On- Q default sub-network (192.168.40.xxx), when you push the reset button for five seconds, the WAP is reset to the factory hardware default IP address of 192.168.1.220.

  • Page 30: Troubleshooting

    VI. Troubleshooting This section will detail possible solutions to common problems that might occur in using the On-Q Wireless Access Point (WAP). Contact Information If you are unable to locate a solution here, please access our website at www.onqlegrand.com the latest information. You can also reach us at 1-800-321-2343.
  • Page 31 Then replace the assembly back in the 3 gang box and replace the cover. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...
  • Page 32 Figure 42 5. My computer is experiencing difficulty connecting to the wireless network. a. Ensure that your On-Q WAP is powered on and that the Wireless LED is lit (see Figure 38). b. Ensure that your wireless adapter (PCI card, Notebook or Ethernet adapter) is installed correctly and is active.

  • Page 33: Software Situations

    If you do NOT receive a reply, try from a different computer to verify that the first PC is not the cause of the problem. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...
  • Page 34 WAP’s default IP address and press Enter. For example type: ping 192.168.40.3. e. If you have changed the On-Q configured IP address of the WAP, you will need to set your network adapter accordingly. Verify you are entering the correct URL in the browser. The default is http://192.168.40.1.

  • Page 35: Glossary

    Basic Service Set. A configuration of Wireless Access Points that communicate with each other without resorting any infrastructure. Also known as Ad-Hoc networks. Also see ESS. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...
  • Page 36 To copy a file from one computer to another. You can use the Internet to download files from a server to a computer. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...
  • Page 37 Internet servers. Gateway A device that enables communication between networks using different protocols. See also router. Graphical User Interface 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343 Page 33...
  • Page 38 Local Area Network. A local area network provides a full-time, high-bandwidth connection over a limited area such as a home, building, or campus. Ethernet is the most widely used LAN standard. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...
  • Page 39 Packet The unit of data that is routed between the sender and destination on the Internet or other packet- switched network. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343...
  • Page 40 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com (800)-321-2343...
  • Page 41 On an Ethernet network, a switch filters frames based on the MAC address, in a manner similar to a bridge. A switch is more advanced because it can connect more than two segments. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...
  • Page 42 A VPN connection provides security and performance similar to a dedicated link (for example, a leased line), but at much lower cost. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...
  • Page 43 Wi-Fi Protected Access. A security regimen developed by IEEE for protection of data on a WLAN. World Wide Web. An interface to the Internet that you use to navigate and hyperlink to information. 301 Fulling Mill Road, Suite G ©Copyright 2007 by On-Q/Legrand, Inc All Rights Reserved. Middletown, PA 17057 www.onqlegrand.com...
