D-Link DCS-2330L Specifications

D-Link DCS-2330L Specifications

Hd wireless n day/night outdoor cloud camera
Hide thumbs Also See for DCS-2330L:

Advertisement

Quick Links

Product Highlights
HD Image Quality and Detail
A high-resolution megapixel sensor provides 720p
HD resolution images and video to ensure that you
capture the details you need
All-Day Outdoor Surveillance
Night vision with built-in infrared illuminator allows
you to monitor 24 hours a day, and the weatherproof
housing protects the camera from the elements
mydlink™-enabled Cloud Access
Easy setup, management and remote viewing your
camera through the free mydlink™ app on your
mobile device or via the secure mydlink™ website
portal
DCS-2330L
HD Wireless N Day/Night Outdoor Cloud Camera
Features
Camera
• 1/4" Megapixel CMOS progressive sensor
• Fixed lens: 3.45 mm F2.0
• IP65 weatherproof housing
• Built-in microphone for audio monitoring
• Built-in infrared-cut removable (ICR) filter for all-
day surveillance
• Built-in IR LED illuminator for use in complete
darkness
• Built-in PIR sensor for enhanced motion
detection
• ONVIF-compliant
Connections
• 802.11n wireless
• 10/100 Fast Ethernet port
• MicroSD/SDHC card slot for onboard storage
• 16GB MicroSD card included, supporting motion
recording up to 7 days
2
Image & Video
• HD resolution (1280 x 720)
• H.264 and Motion JPEG compression
• ePTZ viewing
• Simultaneous multi-stream support
• Privacy Mask feature
• Supports multiple access lists
The DCS-2330L HD Wireless N Day/Night Outdoor Cloud Camera is the perfect solution for
monitoring an outdoor area 24 hours a day from anywhere. This mydlink™-enabled network
camera is built to last with rugged metal housing while the megapixel image sensor and infrared
night vision give you high-quality resolutions up to 720p HD even in complete darkness.
24/7 HD Surveillance
The DCS-2330L is built with a megapixel image sensor to give you high-quality snapshots and
video with resolutions up to 720p HD. This gives you sharp, high-resolution snapshots and
videos with rich detail, so you can capture important details often missed by lower resolution
cameras. Get a closer look with ePTZ, which lets you zoom in, zoom out, and pan across your
camera's video so you can survey a large area easily.
An infrared cut removable (ICR) filter is also built into the DCS-2330L, which blocks infrared light
during the day for improved image quality. At night, it moves out of the way to use all available
light for low-light surveillance, and paired with the IR LED illuminator, this camera can monitor
an area even in complete darkness.
mydlink™: the easiest way to setup up your camera and monitor
your home
Connecting a camera on your network and accessing it has traditionally required complex
configuration. mydlink™ makes it easy to access your camera from wherever you are, whenever
it's convenient for you. Using the free mydlink™ Lite app for iOS and Android smartphones and
tablets, you can connect and setup your mydlink™ camera without turning on a computer.
A step-by-step guide has your camera up and running in a matter of minutes. Through the
mydlink™ Lite app, you can set up a free mydlink™ account which allows you to view and
manage your camera from any Internet connected device. If you have more than one camera,
you can add it to your existing mydlink™ account and watch all your cameras from a single
location.
16GB MicroSD
card included for
motion recording
up to 7 days
2
