  • Page 1 FUNDAMENTAL ACOUSTIC RESEARCH OWNER’S MANUAL ACTIVE MONITOR AV-100C(E)

  • Page 2: Table Of Contents

    FUNDAMENTAL ACOUSTIC RESEARCH Thank you for choosing the FAR AV-100C(E) active three way monitor. In order to obtain the best performance from this active AV-100(C) monitor, please be sure to read this owner’s manual and use your speaker only in accordance with its instructions.

  • Page 3: Installation

    FUNDAMENTAL ACOUSTIC RESEARCH Thank you for choosing a FAR active monitor. This unit is The link functions the same as both of the inputs. Use the an exceptional product that will give you years of superb link to connect one speaker to another performance.

  • Page 4: Technical Description

    Crossover frequency 250 Hz 24 dB/Octave Control -1dB/flat/+1dB/+2dB Mid pass section Crossover frequency 300/3000 Hz 24 dB/Octave High pass section Crossover frequency 7000 Hz 24 dB/Octave Control -3dB/-2dB/-1dB/flat/+1dB/+2dB Band-pass filter 20-20000 Hz 6 dB/Octave Limiter (on/off) +2dB OWNERS MANUAL AV-100C(E)
  • Page 5 Tweeter soft dome Single 2,5cm/1 inch Listening position 200-400 Amplifier Specifications Power (PEAK) Tweeter: Power Medium: Power Woofer: Power 1200 Power (NOMINAL) Tweeter: Power @ 8 Ohm Medium: Power @ 8 Ohm Woofer: Power @ 4 Ohm OWNERS MANUAL AV-100C(E)
  • Page 6 35 V/µs SN ratio > 100 dB Distortion Inter-modulation 0,01% Total 0,05% Input Sensitivity 0 dB Impedance > 10 kOhm Connectors Input (symmetric) XLR & Jack Link Remote RJ-45 External dimensions Height Width Depth Weight 135 kg OWNERS MANUAL AV-100C(E)

  • Page 7: Technical Drawing

    FUNDAMENTAL ACOUSTIC RESEARCH TECHNICAL DRAWING LEGEND 1. Main level tuning 2. Limiter function 3. Link 4. Input XLR 5. Low pass section settings 6. Pre-set curves 7. Cooling system 8. Mains 9. Power 10. High pass section settings OWNERS MANUAL AV-100C(E)

  • Page 8: Fine Frequency Tuning

    Positions available: -1, flat, +1, +2 dB Positions available: -3, -2, -1, flat, +1, +2 dB Figure 1 : high frequency control Figure 2: Low frequency control OWNERS MANUAL AV-100C(E)

  • Page 9: Limiter Function

    FUNDAMENTAL ACOUSTIC RESEARCH Limiter function Rear panel level. The AV-100C(E) has a built in limiter developed to protect Adjust the sound level by turning the main level knob to the drivers against harmful signals. The limiter acts the desired position.

  • Page 10: Troubleshooting

    This section is designed to trouble free technical operation. Most of the problems encountered by the users are due to operating mistakes .Please support@far-audio.com check this list first for a possible solution. If the problem persists, consult your local FAR distributor or EMAIL to : Your problem is...

  • Page 11: Optional Curves

    Integrated into the loudspeakers, these tuning curves reproduce a sound under condition identical to those TELEVISION SPEAKER LIMITATION perceived by the final users. FAR measured the speakers of more than 20 domestic televisions in the large anechoic room of the university. ACADEMY CURVE REMOTE...
  • Page 12 • The sound colour will obviously be the same as you use the same speaker for both curves. • The only one position will ensure you to hear the reflections and the own modes the same way OWNERS MANUAL AV-100C(E)

  • Page 13: Optional Remote Control

    5+1 mode. TABLE OF USE AV-2 AV-6 AV-20 AV-50 AV-100 Peak 2 Peak-6 the RC-3 upgrades the RC-2 by RC-2 adding a fine 8-step volume level RC-3 adjustment. RC-V + =ESSENTIAL / =NOT USEFUL 0 =NOT AVAILABLE OWNERS MANUAL AV-100C(E)
