Seaward
OWNER'S MANUAL
Installation – Operation - Maintenance
Princess Model 1273
Princess Model 2277
PRINCESS MODELS:
1273, 2276, 3276, G3278-1000, G3278-1001
2277-1000, 2277-1001
2277NS-1002, 2277NS-1103
Serial Number:
Products
Princess Model 2276
Princess Model 3276
Read all instructions before operating cooktop.
Save the Owner's Manual / Installation instructions
for local inspector's use.
Installer:
Provide this manual to the vehicle owner.
Vehicle Owner:
Keep this manual for future reference.
LP GAS COOKTOP
IMPORTANT:
Advertisement
Table of Contents
Related Manuals for Seaward PRINCESS 1273
Summary of Contents for Seaward PRINCESS 1273
- Page 1 Save the Owner’s Manual / Installation instructions for local inspector’s use. Installer: PRINCESS MODELS: Provide this manual to the vehicle owner. 1273, 2276, 3276, G3278-1000, G3278-1001 Vehicle Owner: 2277-1000, 2277-1001 Keep this manual for future reference. 2277NS-1002, 2277NS-1103 Serial Number:...
-
Page 2: For Your Safety
WARNING If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. -
Page 3: Important Instructions
Note to consumer: Have the installer or dealer show you where the main gas shut off valve is located so that you will know how and where to turn off the gas supply when necessary. IMPORTANT INSTRUCTIONS Save the Owner’s Manual / Installation instructions for local inspector’s use. NOTE: LPG is heavier than air and if allowed to settle, accumulate and if ignited WILL CAUSE AN EXPLOSION!! Install cooktop, cylinder, and regulating system in compliance with ABYC A-1... - Page 4 CYLINDER, REGULATING SYSTEM, FUEL LINE INSTALLATION CYLINDERS Cylinders used in LPG systems shall be constructed, tested, marked, maintained and re-qualified for continued service in accordance with DOT regulations. No repairs or alterations shall be made on any cylinder. Cylinders that have been subject to fire or physical damage shall not be returned to service unless re-qualified.
- Page 5 Cylinder valves and safety relief devices shall be installed in, or be directly connected to, the vapor space of the cylinder. The LPG tank valve outlet fitting does not require pipe dope or Teflon tape and should be attached to the regulation system nut dry and clean to keep foreign materials out of the system.
-
Page 6: Fuel Supply Lines
FUEL SUPPLY LINES The fuel supply line system and its components, as installed, shall be designed to be compatible with LPG and to withstand the stresses and exposure to the marine environment. One type is annealed copper tubing, standard type, Grade K or L, conforming to specifications for seamless copper water tube. -
Page 7: Installation
INSTALLATION Installation must conform with local codes or in the absent of local codes, with the American Standard for Recreational Vehicles, ANSI A119.2 and article 551, ANSI/NFPA 70. For Marine installation, refer to ABYC standard A-1, A-3, A-26 and A-30. It is the responsibility of the installer to comply with the insulation clearances specified on the serial / rating plate. - Page 8 CAUTION The minimum vertical distance to combustible material above the cooktop is 30 inches. This distance may be reduced to 24 inches if the combustible material above the cooktop is protected by no less than ¼ inch thick insulating millboard covered with 28 gauge sheet metal extending 9 inches beyond the sides of the cooktop and covering the entire bottom of the material to be protected extending over the top of the cooktop.
- Page 9 INSTALLATION 1. Make the cutout. 2. Insert the cooktop. 3. Loosen the fastener, bracket (1). 4. Rotate the bracket (2) outward. 5. Tighten the fastener, bracket (1). 6. Screw the installation bolt (3) until the cooktop is secured. 7. Tighten the locknut (4). To remove the cooktop, reverse the above sequence.
- Page 10 • Place the cooktop upside down on a protected surface. • Remove the paper backing from the foam sealing strip. • Place the strip on the underside of the glass. • Continue until foam strip completely outlines the edges of the cooktop. Insert the cooktop into the cutout...
- Page 11 3. Install the two installation brackets as shown. The top edge of the bracket must be flush to the counter top surface for the proper engagement of the 3M mounting pads. 4. Set cooktop into cutout. Press down to engage 3M pad on glass top to pad on mounting bracket. Princess Model 1273...
- Page 12 LEAK CHECK & LEAK DOWN TEST Check all connections for gas leaks with a non-corrosive and non-toxic leak detection fluid. Test the unit by turning on the LPG tank and observing the pressure gauge. Turn the tank valve off and note the pressure. If there is no drop on the gauge in 3 minutes, the system is free of leaks.
-
Page 13: Care And Cleaning
CAUTION • Be sure your cooktop is installed properly. • Do not operate cooktop if it is damaged or not working properly. • Do not store flammable materials on or near the cooktop. • Never leave lit burners unattended. A boil-over may result, causing smoke or fire. •... - Page 14 EXPLODED VIEW & PARTS LIST PRINCESS 1273 ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION 75422 Burner Cap 72906 Fitting 75421 Burner Base 73449 Cover 80716 Burner Spill Bowl 75431 Fixing Flange 73592 Regulator 75419 Gas Valve 75420...
- Page 15 EXPLODED VIEW & PARTS LIST PRINCESS 2276 ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION 73420 Grate 73666 Cover, Bottom 75422 Cap, Burner 74144 Bracket, Installation 75421 Burner, Base 73251 Grommet 75420 Burner 73204 Clip 80716 Bowl, Spill 73120 Spring, Hold Down 80292...
- Page 16 EXPLODED VIEW & PARTS LIST PRINCESS 2277-1000, 2277-1001 ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION 73420 Grate, 7k btu 75423 Valve, 10k btu 75422 Cap, Burner 7k btu 74383 Manifold 75421 Burner, Base 7k btu 73592 Regulator 75420 Injector Holder, 7k btu 70192...
- Page 17 EXPLODED VIEW & PARTS LIST PRINCESS 2277NS-1002, 2277NS-1003 ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION 73420 Grate, 7k btu 75430 Valve, 10k btu 75422 Cap, Burner 7k btu 74383 Manifold 75421 Burner, Base 7k btu 73592 Regulator 75420 Injector Holder, 7k btu 70192...
- Page 18 EXPLODED VIEW & PARTS LIST PRINCESS 3276 ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION 80298 Assy. Top, Black 73719 Bracket, Installation 80421 Knob, With Insert 75431 Bracket, Valve 73884 Grommet 75419 Valve 75228 Module, Ignition 75470 Fuel Line, Left Front 75462 Fuel Line, Left Rear 75505...
- Page 19 EXPLODED VIEW & PARTS LIST PRINCESS GOURMET G3278-1000, G3278-1001 ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION 80668 Assy. Top, Glass 74515 Grate Large 80696 Assy. Top, SS 80717 Large Spill Bowl 75315 Cover Bottom 74250 Knob 75470 Fuel Line Left 75418 Thermocouple...
-
Page 20: Limited Two-Year Warranty
The foregoing warranty and condition shall apply to any repaired, reworked, or replaced products, part or component supplied by SEAWARD and shall in no event be liable to BUYER or BUYER’S customers for any incidental or consequential damages, or loss of use, or other losses, however occasioned.
