Toshiba 23'L900A Owner's Manual

Integrated digital lcd tv
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
O
WNER'S

Integrated Digital LCD TV

23 L900A
2012
M
ANUAL
Owner's Record
You will find the model number and serial number on
the back of the TV. Record these numbers in the spaces
provided below. Refer to them whenever you call upon
your TOSHIBA dealer regarding this product.
Model number:
Serial number:

Advertisement

Table of Contents
loading

Related Manuals for Toshiba 23'L900A

Summary of Contents for Toshiba 23'L900A

  • Page 1: Integrated Digital Lcd Tv

    You will find the model number and serial number on the back of the TV. Record these numbers in the spaces provided below. Refer to them whenever you call upon your TOSHIBA dealer regarding this product. Model number: Serial number:...

  • Page 2: Table Of Contents

    Contents Introduction................3 Reference Section..............26 Welcome to Toshiba...............3 Troubleshooting..............26 Specifi cations...............27 Important Safety Instructions..........3 Installation................3 License Information used with Toshiba Televisions....28 Use...................4 Service................4 Cleaning.................4 Notes on discs...............5 Important information............5 Getting started................7 Connecting an antenna............7 Exploring your new TV............7 Installing the remote control batteries......7 Effective range..............7...

  • Page 3: Introduction

    This may cause a fi re or an electric shock. • Thank you for purchasing this Toshiba LCD Colour Television. This manual will help you use the exciting Always place the TV on the fl oor or a sturdy, level, features of your new TV.

  • Page 4: Use

    Service Never repair, modify or disassemble the TV by yourself. Never place hot objects or open fl ame sources, such as It may cause a fi re or an electric shock. Consult a service lighted candles or nightlights, on or close to the TV. technician for inspection and repair.

  • Page 5: Notes On Discs

    DVD and CD software and/or the manufacture of DVD and playback will not be allowed by the player. (In this case, CD discs, Toshiba cannot assure that this TV/DVD combo will the TV/DVD combo will display a message on-screen.) successfully play every disc bearing the DVD and CD logos.
  • Page 6 PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO Exemptions LICENSE IS GRANTED OR SHALL BE IMPLIED FOR • Toshiba is not liable for any damage caused by fi res, natural ANY OTHER USE. ADDITIONAL INFORMATION disaster (such as thunder, earthquake, etc.), acts by third MAY BE OBTAINED FROM MPEG LA, LLC.

  • Page 7: Getting Started

    • Never mix battery types or combine used batteries with new exact type and positioning of the antenna will depend upon your particular area. Your Toshiba dealer or service personnel ones. can best advise you on which antenna to use in your area.

  • Page 8: Stand Assembly Instructions

    Stand assembly instructions Parts included in box Please take out the parts according to the instruction printed on the box. CAUTION: Before beginning pedestal assembly, carefully lay the front of the LCD panel face down on a fl at, cushionedsurface such as a quilt or blanket.

  • Page 9: Tv Front And Side Panel Controls

    TV front and side panel controls You can operate your TV using the buttons on the TV control panel or the remote control. The back and side of the panel provide the terminal connections to connect other equipment to your TV. (Refer to page 23 Connecting your TV) Standby / On button +/- control/volume buttons Programme / Volume / AV Function...

  • Page 10: Tv Back Panel Connections

    TV back panel connections Before connecting any external equipment, turn off all main power switches. If there is no switch, remove the mains plug from the wall socket. 5. AV terminal: Standard video and standard audio inputs 6. Component input terminals: For use when connecting a high-defi nition component video device with standard audio output.

  • Page 11: Learning About The Remote Control

    Learning about the remote control Location of controls Simple at-a-glance reference of your remote control. 1. For On/Standby mode. 2. To eject/insert the disc. 3. To toggle between ATV and DTV mode. 4. To toggle between TV and DVD mode. 5.
  • Page 12 24. Colour buttons: Text control buttons in TV mode. Blue letter buttons in DVD mode: PLAY MODE: To select a repeat play option among Chapter, Title, All and Repeat Off; ZOOM: To enlarge a picture; SLOW: To do a slow forward. To reveal concealed text in TV mode.

  • Page 13: Learning About The Menu System

    Learning about the menu system Turning on the TV Switching on the TV We suggest you familiarize yourself with the display charts before using the menu system: Connect the power cord to a wall outlet, the power indicator lights in red (standby mode). •...

  • Page 14: Setting The Programmes

    Notes: Press the button to select Automatic Search and press OK to enter. The options include Digital & Analogue, • Home is recommended for normal home use. Select Digital and Analogue. Use the button to select one, Store when using a TV for displaying in a shop, etc. then press OK to start channel scan.

  • Page 15: General Control

    General Control Information Selecting programme positions The on screen information will give the details of the After you have tuned the TV, you have several ways to navigate channel programme currently being viewed. through all programmes: 1. Press , the information screen will appear giving details of the programme and event currently being •...

  • Page 16: Changing Picture Format

    Changing Picture Format Depending on the type of broadcast being transmitted, programmes can be viewed in a number of formats. Press the QUICK button and select Picture Size. Press OK to display the option list, including Wide, 4:3 Stretch, Super Live, 14:9, Subtitle, and Cinema. Use the button to select one format.

  • Page 17: Using The Tv's Features (General)

    Using the TV’s features (General) DNR: selects an option from Off, Low, Middle and High. Picture MPEG NR: selects an option from Off, Low, Middle and High. Press MENU and select PICTURE by using the ◄ or ► Press RETURN to go back to the previous menu. button.

  • Page 18: Setup

    Press RETURN to go back to the previous menu. Updating Wizard Press EXIT to exit. Updating..Setup Press MENU and select SETUP by using the ◄ or ► button. Please DO NOT unplug the USB dongle and turn off the TV set during firmware updating! Press OK to enter the SETUP menu.

  • Page 19: Applications

    • You must obtain any required permission from copyright settings. When CEC devices are connected to the HDMI owners to use copyright content. Toshiba cannot and does terminals, you can enable the REGZA-LINK function so that not grant such permission.

  • Page 20: Viewing Photos

    - Audio only: Select it and press OK, you can listen to • Depending on the fi le size and amount in your USB storage music with the screen turned off. Any key press will turn device, it may take some time for loading to view. A message on the screen.

  • Page 21: Dvd Playback

    DVD Playback Important Information 1. Press SLOW during playback to select the required speed: Unless otherwise stated, all operations described are based on 1/2, 1/4, 1/8, 1/16 -(forward only). Sound will be muted. remote control use. 2. Press PLAY to return to normal speed. The blue silkscreen letters on the remote control are available in DVD mode.
  • Page 22 to change password. Language Preference Default Parental Password Change Spdif Output The default password from the factory is 0000. Language Preference Change Old Password New Password Confirm PWD...

  • Page 23: Connecting Your Tv

    Connecting your TV Connecting an HDMI or a DVI device The HDMI input on your television receives digital audio and uncompressed digital video from an HDMI source device or uncompressed digital video from a DVI (Digital Visual Interface) source device. This input is designed to accept HDCP (High-Bandwidth Digital Content Protection) programme material in digital form from HDMI...

  • Page 24: Regza-Link Connections

    • The REGZA-LINK feature uses CEC technology as regulated by the HDMI standard. This feature is limited to models incorporating Toshiba's REGZA-LINK. However, Toshiba is not liable for those operations. Refer to individual instruction manual for compatibility information.

  • Page 25: Connecting A Computer

    Connecting a USB Device Connecting a Computer Notes: To Connect a Computer • You can connect a USB device to your TV by using the USB port of the TV. This feature allows you to display/play With either an RGB/PC or an HDMI connection, you can watch your computer’s display on the television.

  • Page 26: Reference Section

    Reference Section Troubleshooting Why is the VCR/DVD picture in black and white? ● Check the correct input has been AV or COMPONENT. Before calling a service technician, please check the following Why did TV turn off by itself? table for a possible cause of the symptom and some solution. ●...

  • Page 27: Specifi Cations

    Specifications Aspect ratio 16:9 Visible size (diagonal) Model 58.5cm 23DL900A Number of pixels Power source ~220-240V 50Hz 1920(H) x 1080(V) dots Sound output (at 10% distortion) Power consumption 3Wx2 Input/Output terminals Standby (approx) < 0.5W Antenna Input: 75 Ω RF Input Composite Input: Dimensions (includes foot stand) Video: RCA, CVBS...

  • Page 28: License Information Used With Toshiba Televisions

    Some of the software components distributed under EULAs are made available for use by the user on the premise that they are not copyrighted or warranted by TOSHIBA or any third party. These software components are licensed to the user free of charge and therefore not covered by any warranty within the scope of the applicable laws.
  • Page 29 72-MT10AN-AUN1E...

This manual is also suitable for:

23dl900a
