Fire Sentry FS10-CS Installation Manual And Operating Manual

Long range, two-stage, multi-spectral quick response, digital, electro-optical fire detector
Hide thumbs
Table of Contents

Advertisement

Quick Links

_____________________________________________________________________________
Long Range, Two-Stage, Multi-Spectral
Quick Response, Digital, Electro-Optical
Fire Detector
Card Controller OPTION

Installation Guide

Operating Manual
Fire Sentry Corporation
Fire Sentry Corporation (FSC)
23311 La Palma Avenue
Yorba Linda, California 92887
FSC Model No.
FS10-CS
AUTOMOTIVE PAINT
APPLICATIONS
and
Document No. 1527-002 – Rev. E
TM
with
2FLCS
for
©
Copyright 2009
Tel.: 714-694-2700
Fax: 714-694-2701
All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS10-CS and is the answer not in the manual?

Questions and answers

Related Manuals for Fire Sentry FS10-CS

Summary of Contents for Fire Sentry FS10-CS

  • Page 1: Installation Guide

    Fire Sentry Corporation (FSC) 23311 La Palma Avenue Tel.: 714-694-2700 Fax: 714-694-2701 Yorba Linda, California 92887 _____________________________________________________________________________ FSC Model No. FS10-CS Long Range, Two-Stage, Multi-Spectral Quick Response, Digital, Electro-Optical Fire Detector with 2FLCS Card Controller OPTION AUTOMOTIVE PAINT APPLICATIONS Installation Guide Operating Manual ©...
  • Page 2 This manual is subject to change without notice. ACCTTL, ALERT-1, ALARM-2, ALERT-1: ALARM 2, ALERT-1: ALARM-2, ATAG, Clean Room Sentry, COP-i, Complete Optical Path Integrity, CM1, CM1-A, DartLogic, FireLogic, Fire Sentry VSD-8 Fire Sentry VSD-8 Visual Smoke Detection System, VSD-4, VSD-8, Fire Signature Analysis, FireBusI, FireBusII, FirePic, FirePicII, FirePicIII, FirePix, FirePicture, FSC, Fire Sentry Corporation, Fire Sentry Corp., FSX, All...

  • Page 3: Table Of Contents

    2.4.1 Mounting Flame Detectors ..............................13 2.4.2 Mounting Card Controllers ..............................13 FS10-CS Detector Rotary Switch Settings ........................ 13 FS10-CS Card Controller, Option 2FLCS, DIP Switch #1 Settings ................14 SECTION 3: OPERATION ................................ 14 FS10-CS Detector Operation with the Card Controller ....................14 Initial Start Up ................................

  • Page 4: Approvals

    FirePic. The FirePic data includes graphical display of the relative spectral intensities versus time preceding and during the fire. Note: A PC computer and Fire Sentry‟s Window PC software is required to access FirePic. Page 4 Fire Sentry Corporation ©...

  • Page 5: Fs10-Cs Flame Detector

    Note: 15, 30, or 45 feet ranges are set by the user via the FS10-CS rotary switch located at the rear of the Detector‟s module. (See Section 2.5.) 1.5.6 Automatic Detector Self-Test...

  • Page 6: Time Delay Setting

    Fire Detector with Card Controller INSTALLATION GUIDE and OPERATING MANUAL The FS10-CS Detector is directly connected (home run) to its Card Controller using a four wire 18 to 22 gauge twisted pair shielded cable. The Flame Detector communicates to the Controller using a two-wire serial digital differentially driven RS-485 communication link, with the other two wires providing low voltage DC power (+9 Volts) and DC return.

  • Page 7: Backplane Mounting Assemblies

    20-pin screw-down terminal (J2). Refer to Figure 3. Fire Sentry Corporation recommends that the BMA be installed with a clear view of the status LEDs and their function labels as may be required by the local authority at the user site. A viewing angle of about 20 degrees from the left should be available as shown in the following illustration.
  • Page 8 OPTION 2FLCS Model FS10-CS Fire Detector with Card Controller INSTALLATION GUIDE and OPERATING MANUAL Figure 1: Backplane Mounting Assembly for Four Cards Page 8 Fire Sentry Corporation © Document No. 1527-002 – Rev. E Copyright 2009 All Rights Reserved...
  • Page 9 Provides screw-down terminals for connecting up to two Flame Detectors with their 4-wire cabling, and for inputting and looping through 24 VDC electrical power for the Card Controllers. For details refer to Table 5. Page 9 Fire Sentry Corporation © Document No. 1527-002 – Rev. E Copyright 2009...

  • Page 10: Cable

    24 VDC power for the Card Controller. For details refer to Table 6. Cable Table 1 specifies the gauge and length of cable for connection of the Flame Detector to the Card Controller, recommended by Fire Sentry Corporation. Page 10 Fire Sentry Corporation ©...

  • Page 11: Section 2: Installation

    Detector Views The Detector may be mounted directly on the wall, or with the optional SM2 swivel mounting assembly (refer to Section 6.1 for details). Page 11 Fire Sentry Corporation © Document No. 1527-002 – Rev. E Copyright 2009 All Rights Reserved...
  • Page 12 ¾ NPT 2.40 0.67 2.09 1.10 4.66 Figure 4: Flame Detector Housing – Side View Figure 5: Flame Detector Housing – Rear View Page 12 Fire Sentry Corporation © Document No. 1527-002 – Rev. E Copyright 2009 All Rights Reserved...

  • Page 13: Wiring Flame Detectors

    The Card Controllers are only to be mounted on Card Controller Backplane Mounting Assemblies. The Card Controller is not designed for explosive atmospheres. Refer to Section 1.6 for details. FS10-CS Detector Rotary Switch Settings To set the rotary switches located on the rear of the Detector‟s black internal module, use a flat head screwdriver.

  • Page 14: Fs10-Cs Card Controller, Option 2Flcs, Dip Switch #1 Settings

    Detector switch #2 is set for position 2, 3, 4, 5, or 6, a Fault condition #5 will occur. FS10-CS Card Controller, Option 2FLCS, DIP Switch #1 Settings Use a small flathead screwdriver to set the DIP switch located at the front of the Card Controller enclosure: ON is UP position.

  • Page 15: Initial Start Up

    Card Controller Faults For diagnostic purposes, possible Faults reported by the Card Controller are shown in the Table 2. Should remedial action fail to clear a Fault condition, consult Fire Sentry Corporation, or one of their Distributors, or Representatives. Page 15 Fire Sentry Corporation ©...

  • Page 16: Cleaning Detectors Housing Windows

    Card Controller Fault, such as a broken relay coil (if not a Fault Ground Fault condition). If this condition persists, return the entire Card Controller to Fire Sentry for service. Section 4.6. Card Controller - yellow LED turns on and Detector LED...

  • Page 17: Detector Faults

    Fault, return the black Detector module, located within the red housing, and return to Fire Sentry for service. There are no user-serviceable parts in Detector modules. Note: Under Normal Operation, the Detector‟s green LED will blink 2 times in succession every 10 seconds if the Detector is communicating with the Card Controller.

  • Page 18: Section 5: Pinout Data

    Pin-outs 5 through 10 are not used and are open connections. DO NOT CONNECT CABLE SHIELD AT THE FLAME DETECTOR! 1 2 3 4 5 6 7 8 9 10 Page 18 Fire Sentry Corporation © Document No. 1527-002 – Rev. E Copyright 2009...
  • Page 19 K1 - COMMON Fault Relay K1 - N.O. K2 - A Alert / Fire Early Warning DETECTOR # K2 - B Relay (Normally Open) Page 19 Fire Sentry Corporation © Document No. 1527-002 – Rev. E Copyright 2009 All Rights Reserved...
  • Page 20 K3 - A Alert / Fire Early Warning K3 - B Relay (Normally Open) K4 - A Fire Alarm Relay K4 - B Not Used Page 20 Fire Sentry Corporation © Document No. 1527-002 – Rev. E Copyright 2009 All Rights Reserved...
  • Page 21 24 VOLT RETURN loop through * IMPORTANT: Detector cable shields are to be terminated at Controller chassis symbol ( ) on back plane. Page 21 Fire Sentry Corporation © Document No. 1527-002 – Rev. E Copyright 2009 All Rights Reserved...
  • Page 22 K3 - A Alert / Fire Early Warning K3 - B Relay (Normally Open) K4 - A Fire Alarm K4 - B Not Used Page 22 Fire Sentry Corporation © Document No. 1527-002 – Rev. E Copyright 2009 All Rights Reserved...
  • Page 23 24 VOLT RETURN loop through * IMPORTANT: Detector cable shields are to be terminated at Controller chassis symbol ( ) on back plane. Page 23 Fire Sentry Corporation © Document No. 1527-002 – Rev. E Copyright 2009 All Rights Reserved...
  • Page 24 ) on back plane. NOTE: All Card Controller relays are shown during Normal Operation, in the absence of Fire Alarm Conditions or Faults. Page 24 Fire Sentry Corporation © Document No. 1527-002 – Rev. E Copyright 2009 All Rights Reserved...

  • Page 25: Section 6: Accessories

     Part No. CCBPMA1-4: 9.00 x 9.50 inch BMA mounts up to Four-Card Controllers. Test Lamp (Part No. FT-CS) This battery powered portable test source for close range remote activation of the FS10-CS Detectors simulates the radiant energy emitted by an actual fire in order to test the Detectors operation without the need for an open flame.

  • Page 26: Disposable Protective Covers For Detectors (Part No. Dpc-12)

    Software Diskette and plug-in interface cable to connect the Card Controller to the PC. Warranty Fire Sentry Corporation warrants the Flame Detector and the Card Controller against any defects in material and workmanship, as well as premature internal parts failure, for a period of two years from the shipment date.
  • Page 27 Four Card Backplane K3, 7 Cabling, 6 Mounting Assembly K4, 7 Delay Settings, 6 Size, 7 RS-232, 5, 6, 26 Event History, 6 FS10-CS Fire/Flame Detector, RS-485, 6 Faults, 15 Silicone Functions, 6 , 16 Greases, 16 Ground Fault Humidity Range, 6...
