Fire Sentry SS4-A Installation And Operation Manual

Multi-spectrum digital electro-optical fire detector
Hide thumbs
Table of Contents

Advertisement

Quick Links

Electro-Optical Fire Detector
______________________________________________________________________________________________________________________
Fire Sentry Corporation
Model SS4-A/-A2 Optical Fire Detector
Installation and Operations Guide
Fire Sentry Corporation (FSC)
23311 La Palma Avenue
Yorba Linda, California 92887
Multi-Spectrum Digital
MODEL
SS4-A/-A2
(CENELEC)
STAND-ALONE RELAY MODE
or 4-20 mA Output Option

Installation Guide

Operating Manual
Document No. 1510-007 – Rev D
and
© Copyright 2009
Tel.: 714-694-2700
Fax: 714-694-2701
All Rights Reserved
Page i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS4-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fire Sentry SS4-A

Summary of Contents for Fire Sentry SS4-A

  • Page 1: Installation Guide

    Model SS4-A/-A2 Optical Fire Detector Page i Installation and Operations Guide Fire Sentry Corporation (FSC) 23311 La Palma Avenue Tel.: 714-694-2700 Yorba Linda, California 92887 Fax: 714-694-2701 Multi-Spectrum Digital Electro-Optical Fire Detector MODEL SS4-A/-A2 (CENELEC) STAND-ALONE RELAY MODE or 4-20 mA Output Option...
  • Page 2 Complete Optical Path Integrity, CM1, CM1-A, DartLogic, FireLogic, Fire Signature Analysis, FireBusI, FireBusII, FirePic, FirePicII, FirePicIII, FirePix, FirePicture, FSC, Fire Sentry Corporation, Fire Sentry Corp., FSX, All FSX Nomenclature Variations (such as: FS2, FS2X, FS3, FS3X, FS4, FS4X, FS5, FS5X, FS6, FS6X, FS7, FS7X, FS8,...

  • Page 3: Table Of Contents

    Configuring the Detector Module......................... 7 2.2.4 Wiring the Detector Module........................... 7 2.2.5 Wiring the SS4-A/-A2 Detector for 4 to 20 mA Current Mode Operation (Optional) ........7 2.2.6 Wiring the Detector Relays............................ 8 2.2.7 Replacing the Detector Module in the Enclosure....................9 Enclosure Installation (optional) .........................

  • Page 4: Approvals

    Solar-blind UV, “Quantum-Effect” IR, and visible sensors correspondingly. They are equipped with SRL-BIT (Built-In-Test) for optical “through the lens” of both the sensors and lens. The Model SS4-A/-A2 UV, IR, and VIS Fire Detectors have false alarm immunity, and adjustable alarm range between 15 and 60 feet for a one square foot gasoline pan fire with a 120-degree (...

  • Page 5: Applications

    Mount (Model SM4) for greater flexibility in mounting locations (See Figures 4 and 5). Stand-Alone Operation For Stand-Alone operation, the Model SS4-A/-A2 Detector may be connected to a FM Approved or UL listed Fire/Security Panel. The Detector operated in the Stand-Alone mode uses the Fire, Fault, and Verify (optional) relays to interface to the Fire/Security Panels.

  • Page 6: Overview

    Re-certification is required if a Fault is indicated by both LEDs rapidly blinking (with frequency about 2 Hz.). Version SS4-A2: The operation of this unit is identical to the SS4-A, except the fire alarm LEDs turn off once the fire threat is eliminated, without power cycling of the device.

  • Page 7: 1.5 Configuration Settings

    2. Latching / Non-Latching - The Fire Relay and Verify Relay may be set in a Latching or Non-Latching mode. If Latching mode is selected on the SS4-A, the Fire or Verify Relay and red LEDs will remain energized until the Detector power is cycled (power is turned off then on).

  • Page 8: 1.6 Testing

    For manual testing, the SS4-AUV Detector may be exposed to an actual industry standard open flame or to a Test Lamp simulating a fire. It is mandatory to use the Fire Sentry handheld UV/IR Test Lamp Model No FT-2045 or FT-2145 with SS4 Fire Detectors. The FT-2045 and FT-2145 Test Lamps are housed in an Explosion-Proof enclosure, powered by internal rechargeable batteries, and designed for indoor and outdoor use.

  • Page 9: Section 2 Installation

    Power Supply Considerations The Model SS4-A/-A2 Detector uses 24 Volts DC at a maximum current of 75 mA (with the 4-20 mA option the maximum supply current is 95 mA). Make sure the Panel's power supply can withstand the load current of the total number of Detectors connected to it.

  • Page 10: Configuring The Detector Module

    * Fault relay is shown in the energized condition during normal operation (No Fault). Figure 2: Model SS4-A/-A2 Detector Wiring (Bottom View of SS4-A/-A2 Detector Module) 2.2.5 Wiring the SS4-A/-A2 Detector for 4 to 20 mA Current Mode Operation (Optional) ______________________________________________________________________________________________________________________ Document No. 1510-007 – Rev D Fire Sentry Corporation ©...

  • Page 11: Wiring The Detector Relays

    NORMAL Operation 4 +/- 0.6 mA ALARM 20 +/- 0.6 mA FAULT < 0.6 mA To use the analog output of an SS4-A/-A2, make the following connections: 24 V DC J2, pin-4 24 V DC RTN J2, pin-1 4-20 mA output...

  • Page 12: Replacing The Detector Module In The Enclosure

    Mount the swivel-mount to the wall assuring correct orientation. c. Install the mounting bracket onto the Model SS4-A/-A2 Detector enclosure using the #¼-20 or #6 mm screws and nuts provided. If oriented correctly, the outside contours of the mounting ears on the Detector enclosure and the ends of the bracket will match.
  • Page 13 Model SS4-A/-A2 Optical Fire Detector Page 10 Installation and Operations Guide 2.95 2.00 4.26 4.86 0.295 Dia. 4.7” approx. Figure 4: Model SM2 Swivel Mount Figure 5: Model SM4 Stainless Steel Swivel Mount ______________________________________________________________________________________________________________________ Document No. 1510-007 – Rev D Fire Sentry Corporation ©...
  • Page 14 1.50 4.38 2.40 0.67 2.09 1.10 4.66 Figure 6: Model SS4-A/-A2 Detector Enclosure - Side View Figure 7: Model SS4-A/-A2 Detector Enclosure Rear View ______________________________________________________________________________________________________________________ Document No. 1510-007 – Rev D Fire Sentry Corporation © Copyright 2009 All Rights Reserved...

  • Page 15: Section 3 Troubleshooting And Maintenance

    SECTION 3: TROUBLESHOOTING AND MAINTENANCE Model SS4-A/-A2 Detector Faults The Model SS4-A/-A2 Detector issues a Fault (or Trouble) condition by de-energizing its Fault Relay (J5 connector). The following are Detector Faults: a. Temperature Fault: The Detector faults if the internal temperature during operation rises above 80°C or falls below -40°C causing both LEDs to blink rapidly.

  • Page 16: Personnel Training

    USER SERVICEABLE PARTS IN A ETECTOR MODULE If the Model SS4-A/-A2 Module must be shipped back to the factory for repair, it MUST be packed in static protective material. If not available, the Module should be carefully wrapped with aluminum foil. An RMA (Return Material Authorization) is required for all returns to the factory.

  • Page 17: Detector Pinout Data

    Model SS4-A/-A2 Optical Fire Detector Page 14 Installation and Operations Guide DETECTOR PINOUT DATA TABLE 1: Stand-Alone Model SS4-A/-A2 Detector Connectors - Pinouts J1: DETECTOR INPUT POWER DC Return or Ground (-) 2 and 3: RS-485 Connection to an optional interface unit for viewing FirePic and TriMode Plot.

  • Page 18: Verification Time

    Model SS4-A/-A2 Optical Fire Detector Page 15 Installation and Operations Guide TABLE 2: Configuration DIP Switch Settings Verification Time DIP SWITCH DIP SWITCH DIP SWITCH DESCRIPTION closed closed closed Verify is disabled and the Verify Relay is unused. Factory setting...

  • Page 19: Section 4 Optional Accessories

    Model SS4-A/-A2 Optical Fire Detector Page 16 Installation and Operations Guide SECTION 4: OPTIONAL ACCESSORIES Air Shield for Applications in Contaminated Environment (Part No. DASA1-P) For installation in areas with high levels of airborne contaminants the Detector Air Shield should be mounted to the Flame Detector housing.

  • Page 20: Index

    Model SS4-A/-A2 Optical Fire Detector Page 17 Installation and Operations Guide INDEX Cleaning Products ............12 Installation ..............6 Conduit ................. 6 Conduit ..............6 Detector Detector ..............6 Cleaning ..............12 Enclosure ..............9 Enclosure..............9 Precautions ............... 6 LEDs .................
