APPENDIX 3: RECEIVER FRONT AND BACK PANELS
SATELLITE IN 1 – Connect one line from your satellite dish here. A Single Wire Multi-Switch (SWM) connection, if applicable, is
1.
made to this satellite in port.
2.
SATELLITE IN 2 – Connect the second line from your satellite dish here.
S-VIDEO OUT – A Standard-Definition video output.
3.
4.
RCA-Audio/Video Jacks – Standard-Definition output. You can use the entire row of RCA connectors (yellow, white and red) to
feed a VCR or DVD player/burner.
5.
COMPONENT VIDEO OUT – Use this block to connect up component video cables (green, blue, red); use the white and red RCA
connectors below it for analog audio out. These connectors provide an HD picture, but do not support 1080p or 3D.
6.
DIGITAL AUDIO OUT COAXIAL – Use this digital audio connection for sound.
7.
DIGITAL AUDIO OUT OPTICAL – Use this digital audio connection for sound.
HDMI – Use this combination digital video and audio connector for the best picture quality. This is the recommended
8.
connector for HD TV.
9.
ETHERNET – Please refer to Appendix 4 for information on networking options on your HD DVR before connecting anything to
the Ethernet port.
USB – For future use. USB 2.0 Host (FRONT/REAR EACH 5V = 500mA)
10.
11.
SATA – Use this connector to add an external hard drive to your Receiver.
12.
PHONE JACK – Connect your phone line here to enable Pay Per View purchasing and Caller ID (if your phone service package
includes it).
POWER – Your Receiver must be plugged in at all times to function properly.
13.
14.
IR RECEIVE – Connect an IR (infrared) extender or repeater here when your Receiver is in a cabinet or otherwise not "visible"
to your remote control.
162
