Summary of Contents for Premier Builders Guild Two-Rock Jet 22
- Page 1 OWNERS MANUAL...
- Page 2 Dear Customer, Thank you for your purchase of a amplifier from Premier Builders Guild. As a discerning guitarist, you know the road to great tone begins with great components. Our Classic Design, carefully selected parts and hand-built approach combine to make an extremely versatile instrument.
-
Page 3: Front Panel Functions
Front Panel Functions 1. Input Jack- High impedance input to the amplifier. Plug in your instrument here. 2. Push/Pull Treble Control- Adjusts the high frequency response. In the full counter-clockwise position, high frequencies are cut. In the full clockwise position, high frequencies are allowed to pass to the gain stage. -
Page 4: Rear Panel Functions
10. Stand-by Switch- Should be in the “down” or “stand-by” position when you apply power to the unit. After a few seconds, place the switch in the “up” position to use the amplifier. You may leave the unit “powered up” and place this switch in the “stand-by” position to mute the output. 11. -
Page 5: Fuse Chart
Fuse Chart All Fuses are 3AG Type 250 Volt, SLO-BLO Export 100 Volt Domestic Fuses: Export 220, 230, 240 Fuses: 2A – 22/35 Watt 2A – 22/35 Watt 1A-22/35 Watt 2.5 - 50 Watt 2.5 - 50 Watt 1.6 - 50 Watt 3.2 - 100 Watt 3.2 - 100 Watt 2.5 - 100 Watt... - Page 6 (Tube Complement) V1- 12AX7, Rhythm channel V2- 12AX7, Mixing/Effects V3- 5751/12AT7, Reverb Driver V4- 12AX7, Lead Channel V5- 12AX7. Phase Inverter V6, V7- 6V6GC/6L6GC, Output Each fine production tube is tested and matched to our exacting specifications. External bias adjustment and test points are located on the chassis near the output tube sockets. A digital voltmeter and small screwdriver are required for bias adjustment.
- Page 7 Do not set bias higher then recommend levels as it can lead to tube failure or failure within the amplifier! amplifiers are brought to you by Premier Builders Guild. We know your new amplifier will provide many hours of enjoyment and inspiration in the years to come.
- Page 8 DO NOT expose to rain or any other moisture. DO NOT use cleaning solvents. Wipe exterior with a clean, dry cloth only. Refer servicing to a qualified service technician. This is a product of Premier Builders Guild 619 MARTIN AVENUE, SUITE 6 ROHNERT PARK, CA 94928 707-584-8663 www.two-rock.com...
