Triumph Adler P-3521DN User Manual

Laser printer b/w print a4
Hide thumbs Also See for P-3521DN:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual
EN
P-3521DN

User Manual

P-3521DN
Laser Printer b / w
Print
A4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P-3521DN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Triumph Adler P-3521DN

Summary of Contents for Triumph Adler P-3521DN

  • Page 1: User Manual

    P-3521DN User Manual P-3521DN Laser Printer b / w Print...
  • Page 2 P-3521DN Operation Guide...
  • Page 3 This Operation Guide is for model P-3521DN. Note This Operation Guide contains information that corresponds to using both the inch and metric versions of these machines. The inch versions of these machines are shown in the screens in this guide. If you are using the metric version, use the messages provided for the inch version as reference only.

  • Page 4: Table Of Contents

    Contents Machine Parts ................1-1 Components at the Front of the Printer ........1-2 Components at the Rear of the Printer ........1-2 Operation Panel ................1-3 Loading Paper ................2-1 Preparing the Paper ..............2-2 Loading Paper into Cassette ............. 2-2 Loading Paper into MP (Multi-Purpose) Tray ......
  • Page 6 Legal and Safety Information Please read this information before using your machine. This chapter provides information on the following topics: Legal Information License Agreements Safety Information Symbols xvii Installation Precautions xviii Precautions for Use About the Operation Guide xxii Conventions in This Guide xxiii...

  • Page 7: Legal Information

    Legal Information CAUTION NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED BY IMPROPER INSTALLATION. Notice on Software SOFTWARE USED WITH THIS PRINTER MUST SUPPORT THE PRINTER'S EMULATION MODE. The printer is factory-set to emulate the PCL. The emulation mode can be changed. Notice The information in this guide is subject to change without notification.
  • Page 8 • ITC Avant Garde Gothic, ITC Bookman, ITC ZapfChancery and ITC ZapfDingbats are registered trademarks of International Typeface Corporation. • UFST™ MicroType® fonts by Monotype Imaging Inc. are installed in this machine. • AirPrint and the AirPrint logo are trademarks of Apple Inc. •...

  • Page 9: License Agreements

    License Agreements IBM Program License Agreement THE DEVICE YOU HAVE PURCHASED CONTAINS ONE OR MORE SOFTWARE PROGRAMS (“PROGRAMS”) WHICH BELONG TO INTERNATIONAL BUSINESS MACHINES CORPORATION (“IBM”). THIS DOCUMENT DEFINES THE TERMS AND CONDITIONS UNDER WHICH THE SOFTWARE IS BEING LICENSED TO YOU BY IBM. IF YOU DO NOT AGREE WITH THE TERMS AND CONDITIONS OF THIS LICENSE, THEN WITHIN 14 DAYS AFTER YOUR ACQUISITION OF THE DEVICE YOU MAY RETURN THE DEVICE FOR A FULL...
  • Page 10 1. the equivalent of U.S. $25,000 in your local currency; or 2. IBM's then generally available license fee for the Program This limitation will not apply to claims for bodily injury or damages to real or tangible personal property for which IBM is legally liable. IBM will not be liable for any lost profits, lost savings, or any incidental damages or other economic consequential damages, even if IBM, or its authorized supplier, has been advised of the possibility of such...
  • Page 11 3. To protect proprietary rights of Monotype Imaging, you agree to maintain the Software and other proprietary information concerning the Typefaces in strict confidence and to establish reasonable procedures regulating access to and use of the Software and Typefaces. 4. You agree not to duplicate or copy the Software or Typefaces, except that you may make one backup copy.

  • Page 12: Original Ssleay License

    GPL/LGPL This product contains GPL (http://www.gnu.org/licenses/gpl.html) and/or LGPL (http://www.gnu.org/licenses/lgpl.html) software as part of its firmware. You can get the source code, and you are permitted to copy, redistribute and modify it under the terms of GPL/LGPL. Open SSLeay License Copyright © 1998-2006 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: Redistributions of source code must retain the above copyright...
  • Page 13 This library is free for commercial and non-commercial use as long as the following conditions are adhered to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code; not just the SSL code. The SSL documentation included with this distribution is covered by the same copyright terms except that the holder is Tim Hudson (tjh@cryptsoft.com).
  • Page 14 Compliance and Conformity This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 15: Safety Information

    Radio Frequency Transmitter This machine contains a transmitter module. We, the manufacturer hereby declare that this equipment (page printer), model P-3521DN is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Radio Tag Technology...

  • Page 16: Caution Labels

    High temperature inside. Do not touch parts in this area, because there is a danger of getting burned. P-3521DN CDRH Regulations The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2, 1976.
  • Page 17 Canadian Department of Communications Compliance Statement This Class B digital apparatus complies with Canadian ICES-003. Avis de conformité aux normes du ministere des Communications du Canada Cet appareil numérique de la classe B est conforme à la norme NMB- 003 du Canada. EN ISO 7779 Maschinenlärminformations-Verordnung 3.

  • Page 18: Energy Saving Control Function

    Energy Saving Control Function The device comes equipped with a Low Power Mode where energy consumption is reduced after a certain amount of time elapses since the device was last used, as well as a Sleep where printer functions remain in a waiting state but power consumption is still reduced to a minimum when there is no activity with the device within a set amount of time.

  • Page 19: Energy Star Program

    Your sales or service representative can provide information about recommended paper types. Environmental benefits of "Power Management" To reduce power consumption when idle, this machine is equipped with a power management function that automatically activates energy- saving mode when the machine is idle for a certain period of time. Although it takes the machine a slight amount of time to return to READY mode when in energy-saving mode, a significant reduction in energy consumption is possible.

  • Page 20: Symbols

    Symbols The sections of this guide and parts of the machine marked with symbols are safety warnings meant to protect the user, other individuals and surrounding objects, and ensure correct and safe usage of the machine. The symbols and their meanings are indicated below. DANGER: Indicates that serious injury or even death will very possibly result from insufficient attention to or incorrect compliance with the related points.

  • Page 21: Installation Precautions

    Installation Precautions Environment Caution Avoid placing the machine on or in locations which are unstable or not level. Such locations may cause the machine to fall down or fall over. This type of situation presents a danger of personal injury or damage to the machine. Avoid locations with humidity or dust and dirt.
  • Page 22 Power Supply/Grounding the Machine Warning Do not use a power supply with a voltage other than that specified. Avoid multiple connections in the same outlet. These types of situations present a danger of fire or electrical shock. Plug the power cord securely into the outlet. If metallic objects come in contact with the prongs on the plug, it may cause a fire or electric shock.

  • Page 23: Precautions For Use

    Precautions for Use Cautions when using the machine Warning Do not place metallic objects or containers with water (flower vases, flower pots, cups, etc.) on or near the machine. This situation presents a danger of fire or electrical shock should they fall inside.
  • Page 24 If dust accumulates within the machine, there is a danger of fire or other trouble. It is therefore recommended that you consult with your service representative in regard to cleaning of internal parts. This is particularly effective if accomplished prior to seasons of high humidity.

  • Page 25: About The Operation Guide

    About the Operation Guide This Operation Guide contains the following chapters: Parts Machine This chapter explains the names of parts. 2 Loading Paper This chapter explains paper specifications for this printer and how to load paper into the cassette or MP tray. 3 Printing This chapter explains how to install the printer driver, print from your PC, and use the application software included in the DVD-ROM.

  • Page 26: Conventions In This Guide

    Conventions in This Guide This manual uses the following conventions. Convention Description Example Italic Used to emphasize a key word, Refer to Print Quality Problems on page Typeface phrase or reference to additional 5-3. information. Bold Used to denote buttons on the To start printing, click OK.
  • Page 27 Introduction-xxiv...

  • Page 28: Machine Parts

    Machine Parts This chapter identifies machine parts and operation panel keys. Components at the Front of the Printer Components at the Rear of the Printer Operation Panel Machine Parts...

  • Page 29: Components At The Front Of The Printer

    Components at the Front of the Printer Top Cover Paper Stopper Top Tray Operation Panel USB Memory Slot Right Cover Paper Cassette Front Cover MP Tray 10 Subtray Components at the Rear of the Printer 11 Network Interface Connector 12 USB Interface Connector 13 Rear Cover 14 Power Cord Connector 15 Power Switch...

  • Page 30: Operation Panel

    Operation Panel Indicators Message Display Cursor Keys [GO] Key [Cancel] Key [OK] Key [MENU] Key Machine Parts...
  • Page 31 Machine Parts...

  • Page 32: Loading Paper

    Loading Paper This chapter explains how to load paper into the cassette or MP tray Preparing the Paper Loading Paper into Cassette Loading Paper into MP (Multi-Purpose) Tray Loading Paper...

  • Page 33: Preparing The Paper

    Preparing the Paper After removing paper from the packaging, fan through the sheets to separate them prior to loading. If using paper that has been folded or is curled, straighten it prior to loading. Failure to do so may result in a paper jam. IMPORTANT Ensure paper is not stapled and clips are removed.
  • Page 34 Adjust the paper length guide to the paper size required. If you are going to use paper that is longer than A4, pull out the extension paper cassette by pushing the release lever one by one and adjust it to the desired paper size. Load the paper in the cassette.
  • Page 35 Insert the paper cassette into the slot in the printer. Push it straight in as far as it will go. There is a paper gauge on the left side of the front of the paper cassette to indicate the remaining paper supply. When paper is exhausted, the pointer will go down to the level of (empty).

  • Page 36: Loading Paper Into Mp (Multi-Purpose) Tray

    Loading Paper into MP (Multi-Purpose) Tray This machine can load up to 50 sheets of 11 × 8 1/2" or A4 paper (80 g/m²) into the MP tray. Pull the MP tray towards you until it stops. Adjust the position of the paper guides on the MP tray. Standard paper sizes are marked on the MP tray.

  • Page 37: Paper Stopper

    Note If the paper is considerably curled in one direction, for example, if the paper is already printed on one side, try to roll the paper in the opposite direction to counteract the curl. Printed sheets will then come out flat. Correct Incorrect When loading envelope, place with the envelope flap closed and...

  • Page 38: Connecting And Printing

    Connecting and Printing This chapter explains how to start up the printer, print from your PC, and use the application software included in the DVD-ROM. Connections Changing Network Interface Parameters Printing a Network Interface Status Page Embedded Web Server RX Installing the Printer Driver 3-14 Printing...

  • Page 39: Connections

    Connections This section explains how to start up the printer. Connecting the USB Cable Follow the steps as below for connecting the USB cable. Connect the USB cable to the USB Interface Connector. Note Use a USB cable with a rectangular Type A plug and a square Type B plug.

  • Page 40: Connecting The Power Cord

    Connecting the Power Cord Install the printer close to an AC wall outlet. If an extension cord is used, the total length of the power cord plus extension should be 5 meters (16 feet) or less. Note Ensure the printer's power switch is off. Only use the power cord supplied with the printer.

  • Page 41: Changing Network Interface Parameters

    Changing Network Interface Parameters This printer supports TCP/IP, TCP/IP (IPv6), IPP, SSL Server and the IPSec protocols and Security Level. The table below shows the items required for each of the settings. Configure the printer's network parameters as appropriate for your PC and your network environment.
  • Page 42 Menu Submenu Setting SSL Server On/Off On/Off 3DES On/Off On/Off IPP over SSL On/Off HTTPS On/Off IPSec On/Off LAN Interface Auto/ 10BASE-Half/ 10BASE-Full/ 100BASE-Half/ 100BASEFull/ 1000BASE-T Security Level High/Low Note After all network related settings have been done, turn the machine OFF and ON again. This is mandatory to make the settings effective! Connecting and Printing...

  • Page 43: Printing A Network Interface Status Page

    Printing a Network Interface Status Page You can print out a status page for the network interface. The network status page shows the network addresses, and other information under various network protocols about the network interface. Adjust/Maintenance Adjust/Maintenance is used to adjust the print quality and to carry out printer maintenance.

  • Page 44: Embedded Web Server Rx

    Embedded Web Server RX If the machine is connected to the network, you can configure various settings using Embedded Web Server RX. This section explains how to access Embedded Web Server RX, and how to change security settings and the host name. For details on Embedded Web Server RX, refer to the Embedded Web Server RX User Guide.

  • Page 45: Accessing Embedded Web Server Rx

    Accessing Embedded Web Server RX Launch your Web browser. In the address or location bar, enter the machine's IP address or the host name. Examples: https://192.168.48.21/ (for IP address) https://P001 (if the host name is "P001") The web page displays basic information about the machine and Embedded Web Server RX as well as their current status.

  • Page 46: Changing Security Settings

    Changing Security Settings This section explains how to change the security settings. Access Embedded Web Server RX by referring to Accessing Embedded Web Server RX on page 3-8. From the Security Settings menu, select the setting you want to configure. The configurable settings are Device Security, Network Security, and Certificates.

  • Page 47: Changing Device Information

    Changing Device Information Change the device information of the machine. Access Embedded Web Server RX by referring to Accessing Embedded Web Server RX on page 3-8. From the Device Settings menu, select System. Enter the device information, and then click Submit. IMPORTANT After changing the setting, restart the network or turn the machine OFF and then ON.
  • Page 48 E-mail settings By configuring the SMTP settings, you can send E-mail notifications on completed jobs. To use this function, this machine must be connected to a mail server using the SMTP protocol. In addition, check the following. • The network environment used to connect this machine to the mail server A full-time connection via a LAN is recommended.
  • Page 49 Enter the appropriate values to each field. Setting Description SMTP Set to send e-mail from the machine. SMTP Protocol Set SMTP protocol. Set the SMTP (E-mail TX) setting to On on the Protocol Settings page. SMTP Server Enter the host name or IP address of the SMTP server. Name SMTP Port Specify the port number to be used for SMTP.
  • Page 50 Setting Description E-mail E-mail Size Limit Enter the maximum size of E-mail that can be sent in kilobytes. Send When E-mail size is greater than this value, an error message Settings appears and E-mail sending is cancelled. Use this setting if you have set E-mail Size Limit for SMTP server.

  • Page 51: Installing The Printer Driver

    Installing the Printer Driver Ensure the printer is plugged in and connected to the PC before installing the printer driver from the DVD-ROM. Note Installation on Windows must be done by a user logged on with administrator privileges. When connected by USB cable, Plug and Play is disabled on this device when in Sleep mode.
  • Page 52 Select the device to be installed. You can also select Use host name for port name and set to use the host name of the standard TCP/IP port. (A USB connection cannot be used.) Note The machine cannot be detected unless it is on. If the computer fails to detect the machine, verify that it is connected to the computer via a network or USB cable and that it is turned on and click...
  • Page 53 Custom Install The following procedure is an example for installing the software in Windows 7 using Custom Install. Insert the DVD-ROM. Note Installation on Windows must be done by a user logged on with administrator privileges. If the Welcome to the Found New Hardware Wizard dialog box displays, select Cancel.
  • Page 54 Select the device to be installed and driver to be installed, and then click the arrow button to move it to the Products to Install list. Select the utility to be installed, and then click the arrow button to move it to the Products to Install list. Note To install Status Monitor, it is necessary to install Microsoft .NET Framework 4.0 beforehand.

  • Page 55: Uninstalling The Software

    Uninstalling the Software Perform the following procedure to delete the Software from your computer. Note Uninstallation on Windows must be done by a user logged on with administrator privileges. Click Start button on the Windows and then select All Programs, (name of offer company), and Uninstall Product Library to display the Uninstall Wizard.
  • Page 56 Double-click the GEN_LIB icon. Double-click OS X 10.5 or higher. Double-click (Brand Name) OS X 10.5+. The printer driver installation program starts up. Install the printer driver as directed by the instructions in the installation software. This completes the printer driver installation. If a USB connection is used, the machine is automatically recognized and connected.
  • Page 57 Click the plus symbol (+) to add the installed printer driver. Click the IP icon for an IP connection and then enter the IP address and printer name. The number entered in Address will automatically appear in Name. Change if needed. Note When using a Bonjour connection, select Default and click the item that appears in Printer Name.

  • Page 58: Printing

    Printing This section explains the printing procedure from an application software. You can specify the printing settings from each tab on Printing System Driver. Printing System Driver is stored in the DVD-ROM (Product Library). For more information, refer to the Printing System Driver User Guide in the DVD-ROM.

  • Page 59: Printing From Application Software

    Printing from Application Software The steps required to print a document created with an application are explained below. You can select the printing Paper Size and Output Destination. Load the paper required into the paper cassette. From the application File menu, select Print. The Print dialog box displays.

  • Page 60: Printing By Airprint

    Printing by AirPrint AirPrint is a printing function that is included standard in iOS 4.2 and later products, and Mac OS X 10.7 and later products. This function enables you to connect and print to any AirPrint compatible device without installing a printer driver. To allow the machine to be found when printing by AirPrint, you can set machine location information in Embedded Web Server RX.

  • Page 61: Status Monitor

    Status Monitor The Status Monitor monitors the printer status and provides an ongoing reporting function. Note When you activate Status Monitor, check the status below. • Printing System Driver is Installed. • Either Enhanced WSD or EnhancedWSD(SSL) are set to On in Security section of the Advanced Operation Guide.
  • Page 62 Printing Progress Tab The status of the print jobs is displayed. Job list Status icon Select a job on the job list and it can be canceled using the menu displayed with a right-click. Paper Tray Status Tab Information is displayed about the paper in the printer and about the amount of paper remaining.
  • Page 63 Alert Tab If an error occurs, a notice is displayed using a 3D image and a message. Status Monitor Context Menu The following menu is displayed when the settings icon is clicked. Settings icon • Configure... If the printer is connected to a TCP/IP network and has its own IP address, use a web browser to access the Embedded Web Server RX to modify or confirm the network settings.
  • Page 64 Status Monitor Notification Settings The Status Monitor settings and event list details are displayed. Select whether notification is performed when an error in the event list occurs. Select Enable event notification. If this setting is set to Off, then the Status Monitor will not start up even when printing is executed.

  • Page 65: Energy Saver Function

    Energy Saver Function Low Power Mode When the set time (factory setting is 1 minute) elapses after the printer is last used, the printer automatically enters low power mode. The message display backlight and lights turn off and power consumption is reduced.
  • Page 66 Note that ambient environmental conditions, such as ventilation, may cause the machine to respond more slowly. For more information about configuring settings, refer to Sleep Timer (Sleep timer timeout setting) section of the Advanced Operation Guide. Energy Saver Mode This mode reduces power consumption even more than quick recovery mode, and allows Sleep mode to be set separately for each function.
  • Page 67 3-30 Connecting and Printing...

  • Page 68: Maintenance

    Maintenance This chapter explains how to replace the toner container and clean the printer General Information Toner Container Replacement Cleaning the Printer Prolonged Non-Use and Moving of the Printer Maintenance...

  • Page 69: General Information

    General Information This chapter describes basic maintenance tasks you can perform for the printer. You can replace the toner container according to the printer's display. Also, the internal parts need periodic cleaning. Note Information Collection on Memory Chips - The memory chip attached to the toner container is designed to improve convenience for the end user;...

  • Page 70: Replacing The Toner Container

    Replacing the Toner Container This section explains how to replace the toner container. CAUTION Do not attempt to incinerate parts which contain toner. Dangerous sparks may cause burns. IMPORTANT During toner container replacement, temporarily move storage media and computer supplies (such as floppy disks) away from the toner container.
  • Page 71 Take the new toner container out of the toner kit. Shake the new toner container at least 5 times as shown in the figure in order to distribute the toner evenly inside the container. Remove the label from the toner container. Install the new toner container in the printer.

  • Page 72: Maintenance Kit Replacement

    Turn the lock lever to the lock position. Close the top cover. Maintenance Kit Replacement When the machine prints 100,000 pages, a message is displayed indicating that the maintenance kit should be replaced. The maintenance kit must then be replaced immediately. To replace the maintenance kit, contact your service technician.

  • Page 73: Cleaning The Printer

    Cleaning the Printer To avoid print quality problems, the interior of the printer must be cleaned with every toner container replacement. Open the top cover and front cover. Lift the developer unit together with the toner container out of the printer.
  • Page 74 Place the drum unit flat on a clean, level surface. IMPORTANT Do not place the drum unit on end. Use a clean, lint free cloth to clean dust and dirt away from the metal registration roller. IMPORTANT Take care not to touch the transfer roller (black) during cleaning.
  • Page 75 Return the developer unit to its position, aligning the guides at both ends with the slots in the printer. Then, close the front cover and top cover. Use a lint free cloth to clean dust and dirt away from the vent on the left and the right side of the machine.

  • Page 76: Prolonged Non-Use And Moving Of The Printer

    Prolonged Non-Use and Moving of the Printer Prolonged Non-use If you ever leave the printer unused for a long period of time, remove the power cord from the wall outlet. We recommend you consult with your dealer about the additional actions you should take to avoid possible damage that may occur when the printer is used next time.
  • Page 77 4-10 Maintenance...

  • Page 78: Troubleshooting

    Troubleshooting This chapter explains how to handle printer problems, understand error messages, and clear paper jams General Guidelines Print Quality Problems Error Messages Ready, Data, and Attention Indicators Clearing Paper Jams 5-10 Troubleshooting...

  • Page 79: General Guidelines

    General Guidelines The table below provides basic solutions for problems you may encounter with the printer. We suggest you consult this table to troubleshoot the problems before calling for service repairs. Symptom Check Items Corrective Actions Print quality is poor. –...

  • Page 80: Print Quality Problems

    Print Quality Problems The tables and diagrams in the following sections define print quality problems and the corrective action you can conduct to solve the problems. Some solutions may require cleaning or replacing parts of the printer. If the suggested corrective action will not solve the problem, call for service representative.
  • Page 81 Printed Results Corrective Action Faint or blurred printing Check the toner container and if necessary replace. Refer to Toner Container Replacement on page 4-2. Clean the charger wire. Refer to Cleaning the Printer on page 4-6. Gray background Check the toner container and if necessary replace. Refer to Toner Container Replacement on page 4-2.

  • Page 82: Error Messages

    Error Messages The following table lists errors and maintenance messages that you can be dealt with by yourself. If Call service or Error.Power off. is displayed, turn off the printer then turn it back on to see if the printer has recovered. If the printer has not recovered, turn off the printer, disconnect the power cord, and contact your service representative or authorized service center.
  • Page 83 Message Corrective Action Current print processing cannot continue because of occurrence of KPDL error which is categorized by ##. To print out an error report, display >>Error Report from the KPDL error menu system, and select On. Press [GO] to resume printing. You can abandon printing Press GO by pressing [Cancel].
  • Page 84 Message Corrective Action Toner has run out in the toner container. Replace the toner container using a new toner kit. The printer does not operate when this message is displayed. Replace toner Replace the toner container using a new toner kit. Toner low We will not be liable for any damage caused by the use of third party supplies in this Unknown toner...

  • Page 85: Storage Error Codes

    Storage Error Codes USB Flash Memory Errors Code Meaning The amount of data that can be saved at once has been exceeded. Split the large file into multiple smaller files. The USB flash memory is write protected. Remove the write protection. The USB flash memory is broken.

  • Page 86: Ready, Data, And Attention Indicators

    Ready, Data, and Attention Indicators The following indicators light during normal operation and whenever the printer needs attention. Depending on the status of lighting, each indicator has the following meaning: Indicator Description Flashing. Indicates an error that you can resolve. Refer to Error Messages on page 5-5.

  • Page 87: Clearing Paper Jams

    Clearing Paper Jams If paper jams in the paper transport system, or no paper sheets are fed at all, the Paper jam message appears and the location of the paper jam (the component where the paper jam has occurred) is also indicated.

  • Page 88: General Considerations For Clearing Jams

    Paper jam message Paper jam location Description Reference page Paper jam inside the printer. page 5-15 Paper jam Printer Paper jam at the rear cover. page 5-17 Paper jam Rear Cover General Considerations for Clearing Jams Bear in mind the following considerations when attempting paper jam removal: CAUTION When pulling the paper, pull it gently so as not to tear it.
  • Page 89 MP Tray Remove the paper jammed at the MP tray. IMPORTANT Do not try to remove paper that has already been partially fed. Proceed to Inside the Printer on page 5-15. Reload the MP tray. Open and close the top cover to clear the error and the printer warms up and resumes printing.
  • Page 90 Paper Cassette/Paper Feeder Pull out the cassette or optional paper feeder. Remove any partially fed paper. IMPORTANT Do not try to remove paper that has already been partially fed. Proceed to Inside the Printer on page 5-15. Note Check to see if paper is loaded correctly. If not, reload the paper.
  • Page 91 Duplexer Paper is jammed in the duplexer. Remove the jammed paper using the procedure given below. Pull the paper cassette all the way out of the printer. Open the duplexer’s cover in front of the printer and remove any jammed paper. Open the duplexer’s cover at the rear of the printer and remove any jammed paper.

  • Page 92: Inside The Printer

    Inside the Printer Pull the paper cassette all the way out of the printer. Remove any partially fed paper. IMPORTANT Do not try to remove paper that has already been partially fed. Proceed to step 2. Open the top cover and front cover, and lift the developer unit together with the toner container out of the printer.
  • Page 93 Return the drum unit to its position, aligning the guides at both ends with the slots in the printer. Insert the developer unit together with the toner container, back into the machine. Close the top cover and the front cover. The printer warms up and resumes printing.

  • Page 94: Rear Cover

    Rear Cover Open the rear cover and remove the jammed paper by pulling it out. CAUTION The fuser unit inside the printer is hot. Do not touch it, as it may result in burn injury. If the paper is jammed inside the fuser unit, open the fuser cover and remove the paper by pulling it out.
  • Page 95 5-18 Troubleshooting...

  • Page 96: Appendix

    Appendix This section lists the following information of this printer. Specifications Environmental Standard Requirements Appendix...

  • Page 97: Specifications

    Specifications Note These specifications are subject to change without notice. Item Description Type Desktop Printing Method Electrophotography, laser scan Paper Weight Cassette 60 to 120 g/m² (Duplex: 60 to 105 g/m²) MP Tray 60 to 220 g/m² Paper Type Cassette Plain, Preprinted, Bond, Recycled, Rough, Letterhead, Color (Colour), Prepunched, High Quality, Custom 1 to 8 MP Tray...
  • Page 98 Item Description Interface USB Interface: 1 USB Memory Slot: 1 Network Interface: 1 (10 BASE-T/100 BASE-TX/1000BASE-T) Network Option eKUIO slot: 1 PRESCRIBE Emulation PCL 6, KPDL, KPDL (AUTO), Line Printer, IBM Proprinter, EPSON LQ-850 Memory Standard 256 MB Maximum 1280 MB Dimension (W ×...

  • Page 99: Environmental Standard Requirements

    Environmental Standard Requirements This machine conforms to the following environmental standard requirements. • Time for switching to Sleep mode (default): 15 minutes (For Europe), 1 minute (Except for Europe) • Time for switching to Low power mode (default): 1 minute •...

  • Page 100: Index

    Index troubleshooting ............5-2 Cassette loading paper ............2-2 Charger cleaner ............... 4-7 Inside the printer Cleaning clearing paper jams ..........5-15 charger wire .............. 4-7 Installation method printer ............... 4-6 custom mode ............3-16 registration roller ............4-7 express mode ............3-14 Clearing paper jams Installation precautions ...........xviii duplexer ..............
  • Page 101 Paper gauge ..............2-4 Turning on the power ............3-3 Paper guides ..............2-5 Paper length guide ............2-3 Paper stopper components ..............1-2 USB cable Possible paper jam locations .........5-10 connection ..............3-2 Power cord USB interface connector connection ..............3-3 components .............. 1-2 Power cord connector components ..............1-2 Power switch...
  • Page 102 We recommend the use of our own brand supplies. We will not be liable for any damage caused by the use of third party supplies in this machine.
  • Page 103 TA Triumph-Adler GmbH Betriebsstätte Norderstedt Ohechaussee 235 22848 Norderstedt Germany First edition 2013.12 2PJGEEN000...
