Page 1: User Manual
Z77TM-ITX H77TM-ITX B75TM-ITX H61TM-ITX User Manual Version 1.1 Published November 2013 Copyright©2013 ASRock INC. All rights reserved. -
Page 2: Copyright Notice
ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this manual. With respect to the contents of this manual, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warran- ties or conditions of merchantability or fitness for a particular purpose. -
Page 3: Table Of Contents
Contents 1. Introduction ..............5 1.1 Package Contents ............5 1.2 Specifications ..............6 1.3 Unique Features ............. 10 1.4 Motherboard Layout (Z77M-ITX) ........13 1.5 Motherboard Layout (H77M-ITX) ......... 15 1.6 Motherboard Layout (B75M-ITX) ......... 17 1.7 Motherboard Layout (H61M-ITX) ......... 19 1.8 I/O Panel (Z77M-ITX) ........... - Page 4 3. UEFI SETUP UTILITY ..........42 3.1 Introduction ..............42 3.1.1 UEFI Menu Bar ............. 42 3.1.2 Navigation Keys ............ 43 3.2 Main Screen ..............44 3.3 OC Tweaker Screen ............45 3.4 Advanced Screen ............49 3.4.1 CPU Configuration ..........50 3.4.2 North Bridge Configuration ........
-
Page 5: Introduction
1. Introduction Thank you for purchasing ASRock Z77TM-ITX / H77TM-ITX / B75TM- ITX / H61TM-ITX motherboard, a reliable motherboard produced under ASRock’s consistently stringent quality control. It delivers excellent perfor- mance with robust design conforming to ASRock’s commitment to quality and endurance. -
Page 6: Specifications
1.2 Specifications Thin Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 Platform cm (Compatible with Mini-ITX) Solid Capacitors for CPU power ® Supports 3rd and 2nd Generation Intel Core i7 / i5 / i3 in LGA1155 Package ® Supports Intel Turbo Boost 2.0 Technology Supports Hyper-Threading Technology... - Page 7 RAID 1, RAID 5, RAID 10, Intel Rapid Storage and Intel Smart Response Technology), NCQ, AHCI and “Hot Plug” functions (Z77TM-ITX / H77TM-ITX) 1 x SATA3 6.0 Gb/s connector and 1 x SATA2 3.0 Gb/s con- nector, support NCQ, AHCI and Hot Plug functions (B75TM- ITX) 2 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and...
- Page 8 Certifications ErP/EuP Ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com WARNING Please realize that there is a certain risk involved with over- clocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclock- ing tools.
- Page 9 ® for the reservation for system usage under Windows 32-bit ® operating systems. Windows 64-bit operating systems do not have such limitations. You can use ASRock XFast RAM to uti- ® lize the memory that Windows cannot use. ® PCIE 3.0 is only supported with Intel Ivy Bridge CPU.
-
Page 10: Unique Features
If you desire a faster, less restricted way of charging your Apple devices, such as iPhone/iPad/iPod Touch, ASRock has prepared a wonderful solution for you - ASRock APP Charger. Simply install the APP Charger driver, it makes your iPhone charge much quickly from your computer and up to 40% faster than before. - Page 11 APP Charger driver installed, you can easily enjoy the marvelous charging experience. ASRock XFast USB ASRock XFast USB can boost the performance of your USB storage devices. The performance may depend on the properties of the device. ASRock XFast LAN ASRock XFast LAN provides faster internet access, which includes the benefits listed below.
- Page 12 8 brings the ultimate boot up experience. The lightning boot up speed makes it hard to access the UEFI setup. ASRock Restart to UEFI allows users to enter the UEFI automatically when turning on the PC. By enabling this function; the PC will enter the UEFI directly after you restart.
-
Page 13: Motherboard Layout (Z77M-Itx)
1.4 Motherboard Layout (Z77TM-ITX) 6 7 8 CHA_FAN1 PCI Express 3.0 DDR3 PLED PWRBTN CIR1 PANEL1 USB8 DC Jack HDLED RESET SATA_POW1 USB6_7 USB3_0_1 PLED1 SATA_0 BKT_PWR1 SATA_1 PNL_PWR1 USB 2.0 T: USB0 B: USB1 CMOS Battery BLT_VOL1 DDR3_B1 COM1... - Page 14 Intel Z77 Chipset SATA3 Connector (SATA_1) USB 2.0 Header (USB8) Chassis Fan Connector (CHA_FAN1) Consumer Infrared Module Header (CIR1) SATA3 Connector (SATA_0) USB 2.0 Header (USB6_7) Mini PCI Express Slot (MINI_PCIE1) USB 3.0 Header (USB3_0_1) SATA Power Connector (SATA_POW1) Power LED Header (PLED1) System Panel Header (PANEL1) Backlight Power Jumper (BKT_PWR1) Panel Power Jumper (PNL_PWR1)
-
Page 15: Motherboard Layout (H77M-Itx)
1.5 Motherboard Layout (H77TM-ITX) 6 7 8 CHA_FAN1 PCI Express 3.0 DDR3 PLED PWRBTN CIR1 PANEL1 USB8 DC Jack HDLED RESET SATA_POW1 USB6_7 USB3_0_1 PLED1 SATA_0 BKT_PWR1 SATA_1 PNL_PWR1 USB 2.0 T: USB0 B: USB1 CMOS Battery BLT_VOL1 DDR3_B1 COM1 DVI1 DDR3_A1 CLRCMOS1... - Page 16 Intel H77 Chipset SATA3 Connector (SATA_1) USB 2.0 Header (USB8) Chassis Fan Connector (CHA_FAN1) Consumer Infrared Module Header (CIR1) SATA3 Connector (SATA_0) USB 2.0 Header (USB6_7) Mini PCI Express Slot (MINI_PCIE1) USB 3.0 Header (USB3_0_1) SATA Power Connector (SATA_POW1) Power LED Header (PLED1) System Panel Header (PANEL1) Backlight Power Jumper (BKT_PWR1) Panel Power Jumper (PNL_PWR1)
-
Page 17: Motherboard Layout (B75M-Itx)
1.6 Motherboard Layout (B75TM-ITX) 6 7 8 CHA_FAN1 PCI Express 3.0 DDR3 PLED PWRBTN CIR1 PANEL1 USB8 DC Jack HDLED RESET SATA_POW1 USB6_7 USB3_0_1 PLED1 SATA_0 BKT_PWR1 SATA_1 PNL_PWR1 USB 2.0 T: USB0 B: USB1 CMOS Battery BLT_VOL1 DDR3_B1 COM1 DVI1 DDR3_A1 CLRCMOS1... - Page 18 Intel B75 Chipset SATA2 Connector (SATA_1) USB 2.0 Header (USB8) Chassis Fan Connector (CHA_FAN1) Consumer Infrared Module Header (CIR1) SATA3 Connector (SATA_0) USB 2.0 Header (USB6_7) Mini PCI Express Slot (MINI_PCIE1) USB 3.0 Header (USB3_0_1) SATA Power Connector (SATA_POW1) Power LED Header (PLED1) System Panel Header (PANEL1) Backlight Power Jumper (BKT_PWR1) Panel Power Jumper (PNL_PWR1)
-
Page 19: Motherboard Layout (H61M-Itx)
1.7 Motherboard Layout (H61TM-ITX) 6 7 8 CHA_FAN1 PCI Express 3.0 DDR3 PLED PWRBTN CIR1 PANEL1 USB8 DC Jack HDLED RESET SATA_POW1 USB6_7 USB3_0_1 PLED1 SATA_0 BKT_PWR1 SATA_1 PNL_PWR1 USB 3.0 T: USB0 B: USB1 CMOS Battery BLT_VOL1 DDR3_B1 COM1 DVI1 DDR3_A1 CLRCMOS1... - Page 20 Intel H61 Chipset SATA2 Connector (SATA_1) USB 2.0 Header (USB8) Chassis Fan Connector (CHA_FAN1) Consumer Infrared Module Header (CIR1) SATA2 Connector (SATA_0) USB 2.0 Header (USB6_7) Mini PCI Express Slot (MINI_PCIE1) USB 3.0 Header (USB3_0_1) SATA Power Connector (SATA_POW1) Power LED Header (PLED1) System Panel Header (PANEL1) Backlight Power Jumper (BKT_PWR1) Panel Power Jumper (PNL_PWR1)
-
Page 21: I/O Panel (Z77M-Itx)
1.8 I/O Panel (Z77TM-ITX) <20mm DC Jack USB 2.0 Ports (USB01) DVI-I (DVI1) eSATA Connector (eSATA1) LAN RJ-45 Port USB 3.0 Ports (USB23) Front Speaker (Lime) Microphone (Pink) HDMI Port (HDMI1) * Please use a 19V power adapter for the DC jack. This jack accepts dual barrel plugs with an inner diameter of 5.1 mm and an outer diameter of 7.4 mm, where... -
Page 22: I/O Panel (H77M-Itx)
1.9 I/O Panel (H77TM-ITX) <20mm DC Jack USB 2.0 Ports (USB01) DVI-I (DVI1) eSATA Connector (eSATA1) LAN RJ-45 Port USB 3.0 Ports (USB23) Front Speaker (Lime) Microphone (Pink) HDMI Port (HDMI1) * Please use a 19V power adapter for the DC jack. This jack accepts dual barrel plugs with an inner diameter of 5.1 mm and an outer diameter of 7.4 mm, where the inner contact is +19 (±10%) VDC and the shell is GND. -
Page 23: I/O Panel (B75M-Itx)
1.10 I/O Panel (B75TM-ITX) <20mm DC Jack USB 2.0 Ports (USB01) DVI-I (DVI1) eSATA Connector (eSATA1) LAN RJ-45 Port USB 3.0 Ports (USB23) Front Speaker (Lime) Microphone (Pink) HDMI Port (HDMI1) * Please use a 19V power adapter for the DC jack. This jack accepts dual barrel plugs with an inner diameter of 5.1 mm and an outer diameter of 7.4 mm, where the inner contact is +19 (±10%) VDC and the shell is GND. -
Page 24: I/O Panel (H61M-Itx)
1.11 I/O Panel (H61TM-ITX) <20mm DC Jack USB 3.0 Ports (USB01) DVI-I (DVI1) eSATA Connector (eSATA1) LAN RJ-45 Port USB 2.0 Ports (USB23) Front Speaker (Lime) Microphone (Pink) HDMI Port (HDMI1) * Please use a 19V power adapter for the DC jack. This jack accepts dual barrel plugs with an inner diameter of 5.1 mm and an outer diameter of 7.4 mm, where the inner contact is +19 (±10%) VDC and the shell is GND. -
Page 25: Installation
Chapter 2: Installation This is a Thin Mini-ITX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard com- ponents or change any motherboard settings. -
Page 26: Installing The Cpu
In order to provide the LGA 1155 CPU Load sockets more protection and make the Plate Load Lever installation process easier, ASRock Cover has added a new protection cover on top of the load plate to replace the former PnP caps that were under the Socket... - Page 27 orientation key notch alignment key Pin1 Pin1 alignment key 1155-Pin Socket orientation key notch 1155-Pin CPU For proper installation, please ensure to match the two orientation key notches of the CPU with the two alignment keys of the socket. Step 2-3. Carefully place the CPU into the socket.
-
Page 28: Installing The Cpu Fan And Heatsink
2.2 Installing the CPU Fan and Heatsink This motherboard is equipped with 1155-Pin socket that supports Intel 1155-Pin CPUs. Please adopt the type of heatsink and cooling fan com- pliant with Intel 1155-Pin CPU to dissipate heat. Before you install the heatsink, you need to spray thermal interface material between the CPU and the heatsink to improve heat dissipation. -
Page 29: Installing Memory Modules (Dimm)
2.3 Installing Memory Modules (DIMM) This motherboard provides two 204-pin DDR3 (Double Data Rate 3) SO- DIMM slots. Step 1. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. The DIMM only fits in one correct orientation. It will cause per- manent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation. -
Page 30: Expansion Slots (Pci Express Slots)
2.4 Expansion Slots (PCI Express Slots) There is 1 PCI Express slot and 1 mini PCI Express slot on this mother- board. Mini-PCIE Slot: MINI_PCIE1 is used for mini PCIE cards. PCIE slots: The x4 lane width PCIE1 (PCIE 3.0 x4 slot) is used for PCI Express expansion cards. -
Page 31: Installing Serial Sata2 / Sata3 Hard Disks
2.5 Installing Serial SATA2 / SATA3 Hard Disks STEP 1: Connect the SATA power cable to the hard disk. STEP 2: Connect one end of the SATA data cable to the hard disk. STEP 3: Connect the other end of the SATA data cable to the mother- board’s SATA2 connectors. -
Page 32: Power Connectors
2.6 Power Connectors SATA Power Connector Please connect a SATA (SATA_POW1) power cable. (see p.13/15/17/19, No. 10) -
Page 33: Installing The System Panel
2.7 Installing the System Panel Connect the power switch, reset switch and system status indicator on the chassis to this header according to the pin assignments below. Note the positive and negative pins before connecting the cables. PWRBTN (Power Switch): Connect to the power switch on the chassis front panel. -
Page 34: Onboard Headers And Connectors
2.8 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Plac- ing jumper caps over the headers and connectors will cause permanent damage to the motherboard! USB 2.0 Headers Besides two default USB 2.0 DUMMY (9-pin USB4_5) - Page 35 Front Panel Audio Header This is an interface for the PRESENCE# MIC_RET (9-pin HD_AUDIO1) front panel audio cable that OUT_RET (see p.13/15/17/19, No. 26) allows convenient connec- tion and control of audio OUT2_L J_SENSE devices. OUT2_R MIC2_R MIC2_L 1. High Definition Audio supports Jack Sensing, but the panel wire on the chassis must support HDA to function correctly.
- Page 36 3W Audio AMP Output Please connect the chassis Front_R- Front_R+ Wafer Header speaker to this header. Front_L+ Front_L- (4-pin SPEAKER1) (see p.13/15/17/19, No. 28) Power LED Header Please connect the chassis PLED- PLED+ (3-pin PLED1) power LED to this header PLED+ (see p.13/15/17/19, No.
- Page 37 HDMI_SPDIF Header This header provides SPDIF (2-pin HDMI_SPDIF1) audio output to HDMI VGA SPDIFOUT (see p.13/15/17/19, No. 25) cards, allowing the system to connect HDMI Digital TV/projector/LCD devices. Please connect the HDMI_ SPDIF connector of a HDMI VGA card to this header. Backlight &...
- Page 38 LPC Debug Header PIN Signal Name PIN Signal Name No pin (13-pin LPC1) (see p.13/15/17/19, No. 30) LAD3 LAD2 LAD1 LAD0 LFRAME# RESET#...
-
Page 39: Jumpers Setup
2.9 Jumpers Setup When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins. -
Page 40: Operating System Setup
2.10 Operating System Setup ® ® This motherboard supports various Microsoft Windows operating sys- tems: 8 / 8 64-bit / 7 / 7 64-bit / Vista / Vista 64-bit / XP / XP 64-bit. Because motherboard settings and hardware options vary, use the setup procedures in this chapter for general reference only. -
Page 41: Installing Drivers
Click on a specific item then follow the installation wizard to install it. 2.11.4 Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. -
Page 42: Uefi Setup Utility
Chapter 3: UEFI SETUP UTILITY 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. -
Page 43: Navigation Keys
3.1.2 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter> to get into the sub screen. You can also use the mouse to click your required item. -
Page 44: Main Screen
3.2 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. Active Page on Entry This allows you to select the default page when entering the UEFI setup utility. -
Page 45: Oc Tweaker Screen
3.3 OC Tweaker Screen In the OC Tweaker screen, you can set up overclocking features. CPU Configuration CPU Ratio Use this to change the ratio value of this motherboard. Intel SpeedStep Technology Intel SpeedStep technology is Intel’s power saving technology. Processors can switch between multiple frequencies and voltage points to enable power saving. - Page 46 Use this to configure short duration power limit in watts. The default value is [Auto]. Primary Plane Current Limit Use this to configure the maximum instantaneous current allowed for the primary plane. The default value is [Auto]. Secondary Plane Current Limit Use this to configure the maximum instantaneous current allowed for the secondary plane.
- Page 47 DRAM tRCD Use this to change RAS# to CAS# Delay (tRCD) Auto/Manual set- tings. The default is [Auto]. DRAM tRP Use this to change Row Precharge Time (tRP) Auto/Manual set- tings. The default is [Auto]. DRAM tRAS Use this to change RAS# Active Time (tRAS) Auto/Manual settings. The default is [Auto].
- Page 48 [Auto]. ODT WR (CHB) Use this to change ODT (CHB) Auto/Manual settings. The default is [Auto]. ODT NOM (CHA) Use this to change ODT (CHA) Auto/Manual settings. The default is [Auto]. ODT NOM (CHB) Use this to change ODT (CHB) Auto/Manual settings. The default is [Auto].
-
Page 49: Advanced Screen
3.4 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Nouth Bridge Configuration, South Bridge Configuration, Storage Configuration, Intel(R) Rapid Start Technology, Intel(R) Smart Connect Technology, Super IO Configuration, ACPI Configuration, USB Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction. -
Page 50: Cpu Configuration
3.4.1 CPU Configuration Intel Hyper Threading Technology To enable this feature, a computer system with an Intel processor that supports Hyper-Threading technology and an operating system ® that includes optimization for this technology such as Microsoft ® Windows XP / Vista / 7 / 8 is required. - Page 51 CPU Thermal Throttling Use this to enable CPU internal thermal control mechanism to keep the CPU from overheated. The default value is [Enabled]. No-Execute Memory Protection No-Execution (NX) Memory Protection Technology is an enhance- ment to the IA-32 Intel Architecture. An IA-32 processor with “No Execute (NX) Memory Protection”...
-
Page 52: North Bridge Configuration
3.4.2 North Bridge Configuration Primary Graphics Adapter This allows you to select [Onboard] or [PCI Express] as the primary graphics adapter. The default value is [PCI Express]. PCIE1 Link Speed This allows you to select PCIE1 Link Speed. Share Memory This allows you to configure share memory. - Page 53 Volume Control Use this to fine tune the desired volume.
-
Page 54: South Bridge Configuration
3.4.3 South Bridge Configuration Onboard HD Audio Select [Auto], [Enabled] or [Disabled] for the onboard HD Audio. If you select [Auto], the onboard HD Audio will be disabled when a Sound Card is plugged. Front Panel Select [Auto] or [Disabled] for the onboard HD Audio Front Panel. External Panel Select [Auto] or [Disabled] for the External Audio Panel. - Page 55 when the power recovers. If [Power On] is selected, the AC/power resumes and the system starts to boot up when the power recov- ers. Good Night LED Use this to enable or disable the Power LED and LAN LED.
-
Page 56: Storage Configuration
3.4.4 Storage Configuration SATA Controller(s) Use this to enable or disable the SATA Controllers. SATA Mode Selection Use this to select the SATA mode. Configuration options: [IDE Mode], [AHCI Mode] and [RAID Mode]. The default value is [AHCI Mode]. (RAID Mode is for Z77M-ITX / H77M-ITX only.) AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk performance but IDE mode does not have these advantages. -
Page 57: Intel(R) Rapid Start Technology
3.4.5 Intel(R) Rapid Start Technology Intel(R) Rapid Start Technology Use this to enable or disable Intel(R) Rapid Start Technology. Intel(R) Rapid Start Technology is a new zero power hibernation mode which allows users to resume in just 5-6 seconds. The default is [Enabled]. -
Page 58: Intel(R) Smart Connect Technology
3.4.6 Intel(R) Smart Connect Technology Intel(R) Smart Connect Technology Use this to enable or disable Intel(R) Smart Connect Technology. Intel(R) Smart Connect Technology keeps your e-mail and social networks, such as Twitter, Facebook, etc. updated automatically while the computer is in sleep mode. The default is [Enabled]. -
Page 59: Super Io Configuration
3.4.7 Super IO Configuration Serial Port Use this to enable or disable the onboard serial port. Serial Port Address Use this to set the address for the onboard serial port. Configura- tion options: [3F8h / IRQ4] and [3E8h / IRQ4]. -
Page 60: Acpi Configuration
3.4.8 ACPI Configuration Suspend to RAM Use this to select whether to auto-detect or disable Suspend-to- RAM. Select [Auto] to enable if the OS supports it. Check Ready Bit Use this to enable or disable Check Ready Bit. ACPI HPET Table Use this to enable or disable the ACPI HPET Table. - Page 61 system. Please disable CSM when Fast Boot is enabled. The default value is [Enabled].
-
Page 62: Usb Configuration
3.4.9 USB Configuration USB 2.0 Controller Use this to enable or disable the USB 2.0 controller. USB 3.0 Controller Use this to enable or disable the USB 3.0 controller. Legacy USB Support Use this to select legacy support for USB devices. There are four configuration options: [Enabled], [Auto], [Disabled] and [UEFI Setup Only]. -
Page 63: Trusted Computing
3.4.10 Trusted Computing Security Device Support Use this to enable or disable BIOS support for security devices. -
Page 64: Tool
3.5 Tool OMG (Online Management Guard) Administrators are able to establish an internet curfew or restrict internet access at specified times via OMG. You may schedule the starting and ending hours of internet access granted to other us- ers. In order to prevent users from bypassing OMG, guest accounts without permission to modify the system time are required. - Page 65 Network Configuration Use this to configure internet connection settings for Internet Flash. User Defaults You are allowed to load and save three user defaults according to your own requirements.
-
Page 66: Hardware Health Event Monitoring Screen
3.6 Hardware Health Event Monitoring Screen This section allows you to monitor the status of the hardware on your sys- tem, including the parameters of the CPU temperature, motherboard tem- perature, fan speed and voltage. CPU Fan 1 Setting This allows you to set CPU fan 1’s speed. Configuration options: [Full On] and [Automatic Mode]. -
Page 67: Boot Screen
3.7 Boot Screen This section displays the available devices on your system for you to con- figure the boot settings and the boot priority. Fast Boot Fast Boot minimizes your computer’s boot time. Configuration op- tions: [Disabled] - Disable Fast Boot. [Fast]: When selecting “Fast”, it is not allowed to boot from a USB storage device. - Page 68 after boot-up. Full Screen Logo Use this item to enable or disable OEM Logo. The default value is [Enabled]. AddOn ROM Display Use this option to adjust AddOn ROM Display. If you enable the option “Full Screen Logo” but you want to see the AddOn ROM information when the system boots, please select [Enabled].
-
Page 69: Security Screen
3.8 Security Screen In this section you may set or change the supervisor/user password for the system. You may also clear the user password. Secure Boot Use this to enable or disable Secure Boot Control. The default value is [Disabled]. -
Page 70: Exit Screen
3.9 Exit Screen Save Changes and Exit When you select this option the following message, “Save configu- ration changes and exit setup?” will pop out. Select [OK] to save changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option the following message, “Discard changes and exit setup?”...
