MultiSync LCD1990FXp
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for NEC MultiSync LCD1990FXp

Summary of Contents for NEC MultiSync LCD1990FXp

  • Page 1 MultiSync LCD1990FXp User’s Manual...

  • Page 2: Table Of Contents

    Index Warning, Caution ........................English-1 Declaration ..........................English-1 Canadian Department of Communications Compliance Statement ........... English-2 Declaration of Conformity ......................English-2 Contents ............................English-3 Quick Start ..........................English-4 Controls ............................English-8 Recommended use ........................English-12 Specifications ..........................English-14 Features ............................English-15 Troubleshooting ...........................

  • Page 3: Warning, Caution

    Therefore, it should be read carefully in order to avoid any problems. Caution: When operating the MultiSync LCD1990FXp with a 220-240V AC power source in Europe, use the power cord provided with the monitor. In the UK, a BS approved power cord with a moulded plug has a Black (five Amps) fuse installed for use with this equipment.

  • Page 4: Canadian Department Of Communications Compliance Statement

    C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2 No. 60950-1. FCC Information Use the attached specified cables with the MultiSync LCD1990FXp colour monitor so as not to interfere with radio and television reception.

  • Page 5: Contents

    Contents Your new NEC monitor box* should contain the following: • MultiSync LCD1990FXp monitor with tilt/swivel/pivot/height adjust stand • Power Cord (European Continental) • Power Cord (UK) • Video Signal Cable (15-pin mini D-SUB male to 15-pin mini D-SUB male) •...

  • Page 6: Quick Start

    6. Make sure all cables are resting flat against the stand (Figure C.2). Please check Tilt, Rise and Lower monitor screen and screen rotation when you manage cables. 30˚ Tilt Highest Stand Position DVI-I DC-OUT D-SUB NEC optional product attachment. Do not use this connector unless specified. Power cord Figure C.1 English-4...
  • Page 7 Figure C.3 Figure C.2 7. Hold all cables firmly and place the cable cover onto the stand (Figure D.1). To remove the cable cover, lift the cover off as shown in Figure D.2. 8. Connect one end of the power cord to the AC inlet on the back of the monitor and the other end to the power outlet. NOTE: Please refer to Caution section of this manual for proper selection of AC power cord.
  • Page 8 Raise and Lower Monitor Screen The monitor may be raised or lowered in either Portrait or Landscape mode. To raise or lower screen, with one hand, grip the top of the display by the handle using the other hand to grip the bottom. Raise or lower to desired height (Figure RL.1).

  • Page 9: Remove Monitor Stand For Mounting

    Remove Monitor Stand for Mounting To prepare the monitor for alternate mounting purposes: 1. Disconnect all cables. 2. With one hand, grip the top of the display by the handle using the other hand to grip the bottom. Lift up to the highest position.

  • Page 10: English

    Controls OSM (On-Screen Manager) control buttons on the front of the monitor function as follows: To access OSM menu, press MENU/EXIT button. To change signal input, press the SELECT button. NOTE: OSM must be closed in order to change signal input. Landscape MENU INPUT...

  • Page 11: Eco Mode

    ECO MODE Decreases the amount of power consumed by reducing the brightness level. 1: Decreases the brightness by 25%. 2: Decreases the brightness by 50%. CUSTOM: Decreases the brightness level as determined by the user. Refer to the Advanced OSM menu for custom setting instructions. AUTO BRIGHTNESS OFF: No function.

  • Page 12: Off Timer

    Colour Control Systems Colour Control System: Six colour presets select the desired colour setting (sRGB and NATIVE colour presets are standard and cannot be changed). R,G,B: Increases or decreases Red, Green or Blue colour depending upon which is selected. The change in colour will appear on screen and the direction (increase or decrease) will be shown by the bars.

  • Page 13: English

    MENU Tools LANGUAGE OSM control menus are available in eight languages. OSM LEFT/RIGHT You can choose where you would like the OSM control image to appear on your screen. Selecting OSM Location allows you to manually adjust the position of the OSM control menu left or right. OSM DOWN/UP You can choose where you would like the OSM control image to appear on your screen.

  • Page 14: Recommended Use

    NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
  • Page 15 CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE FOLLOWING WHEN YOU POSITION THE MONITOR: • For optimum performance, allow 20 minutes for warm-up. • Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.

  • Page 16: Specifications

    Specifications Monitor Specifications MultiSync LCD1990FXp Monitor Notes LCD Module Diagonal: 48.2 cm/19.0 inches Active matrix; thin film transistor (TFT) liquid Viewable Image Size: 48.2 cm/19.0 inches crystal display (LCD); 0.294 mm dot pitch; Native Resolution (Pixel Count): 1280 x 1024 250 cd/m white luminence;...

  • Page 17: Features

    Allows for the monitor to be mounted on a wall or an arm using any third party compliant device. NaViSet: Is a ground-breaking software family, developed by NEC Display Solutions Europe GmbH, providing intuitive access to all monitor setting controls and remote diagnosis via the Windows interface, based upon the VESA standard, DDC/CI. Using a standard VGA or DVI signal cable, NaViSet can either benefit single users or, with NaViSet Administrator, can reduce the Total Cost of Ownership through remote network-wide maintenance, diagnosis and asset-reporting.

  • Page 18: Troubleshooting

    NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.

  • Page 19: Appendix

    Appendix If you need detailed information about the controls, please use the advanced menu. <How to use the advanced menu> • Turn off your monitor. • Turn on your monitor by pushing the “POWER” and “SELECT” button at the same time for at least one second simultaneously.
  • Page 20 Tag4 Color Control Colour Control System: Six colour presets select the desired colour setting (sRGB and NATIVE colour presets are standard and cannot be changed). R,G,B: Increases or decreases Red, Green or Blue colour depending upon which is selected. NATIVE: Original colour presented by the LCD panel that is unadjustable. sRGB: sRGB mode dramatically improves the colour fidelity in the desktop environment by a single standard RGB colour space.
  • Page 21 OSM Lock Out This control completely locks out access to all OSM control functions. When attempting to activate OSM controls while in the Lock Out mode, a screen will appear indicating the OSM controls are locked out. There are three types of OSM LOCK OUT: OSM LOCK OUT with BRIGHTNESS and CONTRAST control: To activate the OSM Lock Out function, press SELECT, then “UP”...

  • Page 22: Using The Auto Brightness Function

    Using the Auto Brightness function The brightness of the LCD screen can be set to increase or decrease depending on the amount of ambient light within the room. If the room is bright, the monitor becomes correspondingly bright. If the room is dim, then the monitor will dim accordingly.

  • Page 23: Tco'03

    TCO’03 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.

  • Page 24: Manufacturer's Recycling And Energy Information

    Manufacturer’s Recycling and Energy Information NEC DISPLAY SOLUTIONS is strongly committed to environmental protection and sees recycling as one of the company’s top priorities in trying to minimize the burden placed on the environment. We are engaged in developing environmentally- friendly products, and always strive to help define and comply with the latest independent standards from agencies such as ISO (International Organisation for Standardization) and TCO (Swedish Trades Union).
