- Page 1 PT RW330 P ro d u c t N u m b e r : ™ Projector P ro d u c t N a m e : As of November 2012. Specifications and appearance are subject to change without notice. 1 / 1 2 SFD12M010...
-
Page 2: Specifications
PT RW330 ™ Projectors Specifications Main unit Power supply 100 – 240 V AC, 5.2 – 2.0 A, 50/60 Hz Power consumption 460 W (470 VA) (When light source setting: 256 W* with EcoSave mode set to 1, 226 W* with EcoSave mode set to 2. - Page 3 PT RW330 ™ Projectors COMPUTER (RGB) IN D-sub HD 15-pin (female) × 1 R, G, B R: 0.7 Vp-p, 75 ohms, G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms, B: 0.7 Vp-p, 75 ohms HD/VD, SYNC: TTL, high impedance, positive/negative automatic NOTE: HD/SYNC, and VD terminals do not accept tri-level sync signals.
- Page 4 PT RW330 ™ Projectors Dimensions unit : mm (inch) NOTE: This illustration is not drawn to scale. 455 (17-29/32) Terminals LAN / DIGITAL LINK connector HDMI input DVI-I input Computer input Video input Audio input Audio output Serial input As of November 2012 4 / 1 2 SFD12M010...
- Page 5 PT RW330 ™ Projectors Standard setting-up position NOTE: Illustrations show the projector installed using optional ceiling mount bracket 60.5 ∅ ET-PKR100H. (∅ 2-3/8) This illustration is not drawn to scale. Upper edge of projected image * Adjustable in 40 mm (1-9/16 in) steps. Projected image (8-19/32) (7-3/4)
- Page 6 PT RW330 ™ Projectors Projection distance for 16:9 aspect ratio screen unit: meters (feet) Projection size Projection distance [L] Height from the edge of screen [diagonal] to center of lens [ H ] Min [wide] Max [telephoto] [in] 1.02 (4.4) (8.9) -0.05 −...
- Page 7 PT RW330 ™ Projectors Shift range Optical axis shift function allows to shift the position of a projected image as shown below. • Floor mount • Ceiling mount (Width of projected image) 0.28H 0.37H Standard postition of projected image Standard postition of projected image 0.37H 0.28H...
- Page 8 PT RW330 ™ Projectors List of compatible signals The signals that can be input to this projector are shown in the table below. Horizontal scanning fre- quencies of 15 kHz to 100 kHz, vertical scanning frequencies of 24 Hz to 120 Hz, and a dot clock of 162 MHz maximum can be input.
- Page 9 PT RW330 ™ Projectors Serial connector The serial connector complies with RS-232C. To control the projector from a personal computer, com- mands must be input through communication software, based on the format and satisfying the commu- nication conditions shown below. Pin assignments and signal names Signal name Description...
-
Page 10: Digital Link
PT RW330 ™ Projectors Projector PC (DTE) Cable specifications Control commands Command : Parameter Function Callback POWER (STANDBY) IIS:DL1 DIGITAL LINK IIS:DL1 INPUT SELECT IIS:HD1 IIS:HD1 HDMI IIS:DVI IIS:DVI IIS:RG1 COMPUTER IIS:RG1 IIS:VID VIDEO IIS:VID When DIGITAL LINK input is IIS: DL1:HD1 HDMI 1 IIS:DL1:HD1... - Page 11 PT RW330 ™ Projectors Status request commands Command : Parameter Function Callback Description Standby power status Input signal status DIGITAL LINK HDMI RGB 1 RGB 2 VIDEO Input signal status of the digital DL1*HD1 HDMI 1 interface box ET-YFB100G when DL1*HD2 HDMI 2 DIGITAL LINK input is selected.
- Page 12 PT RW330 ™ Projectors Notes on projector placement and operation Please observe the following precautions for projector placement and operation. Never place objects on top of the projector while it is operating. Make sure there is an unobstructed space of 500 mm (1 feet 8 inches) or more around the projec- tor’s exhaust openings.
