- Page 1 In Gas Oven SY23...
-
Page 2: Declaration Of Ce Compliance
INSTRUCTIONS FOR THE USER This manual is an integral part of the appliance. It is necessary to keep it for the life cycle of the oven and to read it carefully for the installation, use, maintenance, cleaning and handling of the appliance. - Page 3 The oven gets extremely hot during operation. The oven remains hot for a long time, even after it has been turned off, and cools off only very slowly until reaching room temperature. Wait for a suitable period of time before carrying out work such as cleaning.
- Page 4 Insert the racks and the drip pan into their respective runners. When this operation is complete, plug the oven into the electrical mains and bring it up to maximum temperature for at least 20 minutes in order to eliminate any residual grease, oil or resins from manufacturing which may cause unpleasant odours during cooking;...
-
Page 5: Instructions For Installation
It is important that all installation procedures be performed by a qualified technician. After unpacking the oven to connect it, rest it on its base without damaging it. Do not lift the oven by the door handle, but hold it at the sides. -
Page 7: Installation
After the oven has been installed, the electrical components must be inaccessible. Make sure that the voltage stated on the appliance rating plate is the same as the voltage in your home. The rating plate is on the lower front edge of the oven (visible with the door open). - Page 8 The wires in the mains supply lead are coloured in accordance with the following code: Green and Yellow - E arth Blue - Neutral Brown – Live The connection must be made as follows: The wire coloured Green and Yellow must be connected to the terminal marked ‘E’...
-
Page 9: Connection To The Gas Supply
The supply system must be compliant with the current standards in the country of use. The type of gas for which the oven has been regulated is indicated on the serial number plate located on one of the side edges of the cavity (visible with the door open) and on the packaging. - Page 10 It is possible to use other types of gas by adapting the burner adjustment as follows: Make sure that the oven is not connected to the electric power supply. Open the oven door completely and remove the oven bottom unscrewing the screws.
- Page 11 Complete the operations (replacing the injector, adjusting the air and minimum), turn off the oven and apply the new data plate (which shows the type of gas being used) replacing the previous one and apply seals using sealing wax or similar.
-
Page 12: Before Using The Oven
It is possible for the inside of the glass in the oven door to cloud up during cooking. Do not rest heavy weights on the door because these could damage the oven cavity and the hinges. -
Page 13: Switching The Gas Oven On
1 Check there has been no interruption in the electricity supply; if so, stop cooking, switch off the oven and wait for the electricity to come. 2 If there has not been any interruption in the electricity supply, do not use the oven and call the After-sales Service. -
Page 14: Switching The Gas Grill On
1 Check there has been no interruption in the electricity supply; if so, stop cooking, switch off the grill and wait for the electricity to come. 2 If there has not been any interruption in the electricity supply, do not use the oven and call the After-sales Service. -
Page 15: Electronic Clock
- The timer counts backwards and stops automatically at 0 Sound signal - After the baking time has ended and the oven has been switched off, the clock gives a sound signal for 7 minutes. - Switch the sound signal off using button A. -
Page 16: Cleaning The Appliance
CLEANING THE APPLIANCE Always allow the appliance to cool down before cleaning to avoid a burn injury. Do not use caustic or abrasive agents, coarse wire wool or hard tools as these can damage the surface finishes. Normally, wiping with a soft cloth dampened with hot detergent is sufficient, but for stubborn marks the following is recommended: VITREOUS ENAMEL PARTS Use only a cleaner that is recommended for this type of material –... -
Page 17: Removing The Oven Door
REMOVING THE OVEN DOOR To facilitate cleaning inside the oven, the door can be removed as follows: Hinges “A” are provided with two movable bolts “B”. When bolt “B” is raised, the hinge is released from its housing. Having done this, the door must be lifted upwards and removed, sliding it towards the outside;... - Page 18 CLEANING THE SIDE GUIDES (fig. 2) The appliance can be equipped with side guides which have to be fixed on the oven sides. Slide oven shelves and trays on side guides. The side guides can be removed by a light downwards pressure on device A.
- Page 19 MAKE SURE THE KNOB GUARD IS ATTACHED BY PULLING IT OUTWARDS ATTENTION: During operation the knob guard gets very hot. Use kitchen gloves. INSTRUCTIONS FOR INSTALLING KNOB GUARD OPEN OVEN DOOR FASTEN KNOB GUARD ONTO FRONT BY MOVING IT TO THE RIGHT CLOSE OVEN DOOR...
- Page 20 This appliance is marked according to the European directive 2002/96/EC on Waste electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
- Page 21 Cod. 12300081940...
