Summary of Contents for Accton Technology USB Ethernet Adapter
- Page 1 USB Ethernet Adapter Quick Installation Guide...
-
Page 2: Package Checklist
USB Ethernet Adapter Introduction Accton’s USB family of products offers a convenient and cost-effective means of bringing straight-forward peripheral connectivity to the desktop based on the Universal Serial Bus (USB). These products feature true plug-and-play connection of PC peripherals “outside the box” and mark a significant advance in desktop cable management. -
Page 3: Installation
When the installation process is complete, remove the diskette from your drive and follow the instructions for restarting your PC. After rebooting your system, the USB Ethernet Adapter will appear to the system as a normal Ethernet network adapter card. For the LED definitions, see "LED functions"... -
Page 4: Led Functions
USB Ethernet Adapter LED Functions The Ethernet Adapter contains two LED's on the side panel of the RJ-45 connector. The left Green LED is LINK and the right Orange LED is Receive/Transmit activity. The operational status of the adapter is indicated by the LED conditions listed below. -
Page 5: Canadian Standards Association (Csa) Statement
Quick Installation Guide EMI Warning FCC Class B Certification Accton Technology Corporation Model Numbers: USB220-EC FCC ID: HED1045USB This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2. -
Page 6: Vcci Class B Compliance (Japan)
USB Ethernet Adapter VCCI Class B Compliance (Japan) EN55022 Declaration of Conformance This is to certify that the Accton USB220-SC is shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by the application of EN55022:1987 Class B (CISPR 22:1985/BS 6527:1988). -
Page 7: Product Specifications
Quick Installation Guide Product Specifications Standards Conformance USB Specification 1.0 (for USB low-power device) System Requirements A PC that supports the Universal Serial Bus (Windows 98) Also requires device driver (included) Ports 1 USB B-Type receptacle for downstream (device) connections RJ-45 Ethernet port for 10BASE-T, 10Mbps connections Cable Wiring USB port: 90 shielded USB cable, 5 m (16 ft) max. -
Page 8: Warranty
Copyright © 1999 by Accton Technology Corporation. All rights reserved. No part of this document may be copied or reproduced in any form or by any means without the prior written consent of Accton Technology Corporation. Accton makes no warranties with respect to this documentation and disclaims any implied warranties of merchantability, quality, or fitness for any particular purpose.
