Lorex SG7555P Series Specifications

Weatherproof CoLor Night VisioN CaMera
f e a t u r e s
High Resolution Image Sensor - Produces Sharp and Clear Video with 420 TV Lines
ß
24 IR LEDs Provide Night Vision Range of 50ft/15m*
ß
Advanced Day/Night mode: Picture Automatically Switches to B&W Delivering Better Clarity in
ß
Low Light Conditions
Weatherproof Design: Ideal for Outdoor and Indoor applications (IP66**)
ß
Built-in microphone provides one way audio from camera to the system
ß
100ft DIN extension cable included per camera
ß
Easy Connect Cameras: all-in-one camera cable (providing video, audio & power) plugs
ß
directly to the monitor and eliminates the need for a separate power adaptor
Universal connections supporting 6 pin DIN and Industry Standard BNC (included with
ß
SG7555BP only)
Ceiling or Wall Mountable Cameras with versatile stand provides flexible mounting options
ß
s p e C i f i C a t i o N s
Image Sensor: 1/4" Color Image Sensor
Video Format: PAL
Effective Pixels: H: 512, V: 582
Resolution: 420 TV Line
Scan System: 2:1 Interlace
Sync System: Internal
S/N Ratio: More than 48dB
Iris: AES
AES Shutter Speed: 1/60~1/50,000 Sec
Mini Illumination: 3.0 Lux without IR LED, 0 Lux with IR LED
Video Output: 1.0Vpp @ 75 ohm
Lens/ Lens Mount: 3.6mm F 1.8/ Fixed
FOV (Diagonal): 70 degree
Termination: 6 pin DIN
IR LED/ Night Vision Range: 24 pieces / 850 nm / 50ft/15m
Power Requirement: 12Vdc
Power Consumption: 330 mA
Operating Temp Range: -10° ~ 50° C
Environmental Rating: IP 66
* IR illumination range up to 50 ft (15M) under ideal conditions. Objects at or beyond this
range may be partially or completely obscured, depending on the camera application.
**Not recommended for submersion in water
d i M e N s i o N s
2.55" /
2.9" /
65mm
73mm
6.5" /
165mm
sg7555p series
Lorex Technology Inc.
300 Alden Road, Markham,
3700 Koppers Street
Ontario L3R 4C1
Baltimore, Maryland 21227,
Canada.
USA.
B U S I N E S S A N D H O M E S E C U R I T Y
p r o d u C t i N f o r M a t i o N
SG7555BP
UPC: 7-78597-27555-1
Package Weight: 1.3KG / 2.86LBS
Package Dimensions: 200mm/7.9" (w) x 145mm/5.7" (d)
x 125mm/4.9" (h)
Package Cube: 0.1CBF / 0.003CBM
SG7555PK4P
UPC: 7-78597-37555-8
C o N t e N t s
SG7555BP
1 x Camera with stand,
1 x 100ft DIN Cable, 1 x Power
Adaptor, 1 x DIN to BNC/RCA/
Power cable, 1 x BNC to RCA
coupler
SG7555PK4P 4 x Camera with stand,
4 x 100ft DIN cable
w w w . l o r e x c c t v . c o m
As our product is subject to continuous improvement, Lorex Technology & subsidiaries reserve
the right to modify product design, specifications & prices without notice and without incurring
With audio
©2008 Lorex Technology Inc.
any obligation. E&OE
1-16022007
