Specifications

Dimensions
Output Power
Fan Type
Connectors
Connectors
MTBF
Safety Approvals
AC Input
DC Output
Instruction Manual
5.9 x 3.35 x 5.5 inches (150 x 85 x 140mm)
330W
12 cm ball-bearing
FCC, UL, CSA, CE, TUV, CB
6 x 4-pin-LP4 (Hard drive)
2 x 4-pin SP4 small internal power (Floppy drive)
1 x 20-pin ATX motherboard adapter
1 x 4-pin extended ATX power 12V plug
2 x 15-pin Serial ATA
1 x TX3 fan sensor
100,000 hrs. @ 25ºC
TUV, UL, CSA, CE, FCC, CB
Voltage 115V~ Current 8A
Voltage 230V~ Current 4A
Frequency 50~60Hz
+3.3V (28A)
+5V (35A)
+12V (15A)
-5V (0.5A)
-12V (0.8A)
+5V Standby (2.5A)
