- Page 1 Owner’s Manual ™ Electric Rechargeable Power Reel Mower (Model EM-2)
-
Page 2: Table Of Contents
Storage ..............10 Re-adjust Blade Clearance ..........10 Replace Battery ............12 Technical Data ..............13 ™ Sunlawn, Inc. 325 Garfield Street Fort Collins, CO 80524 Tel: 1-800-282-8850 FAX: 970-493-5202 For service inquiries, parts replacement, and maintenance tips, see www.sunlawn.com © 2006 by Sunlawn, Inc... -
Page 3: Welcome
Owner’s Manual — Sunlawn EM-2 WELCOME Congratulations on your purchase of a Sunlawn mower. This and our other Sunlawn products originate from our commitment to conscientious gardening solutions. Please use this manual as a reference. WARRANTY Sunlawn, Inc. (the Manufacturer) guarantees this product for private use for a period of 2 years from the date of purchase. -
Page 4: Assembly
Owner’s Manual — Sunlawn EM--2 ASSEMBLY PARTS LIST Handle top section 13. Reel blade 27. Motor assembly Handle grip 14. Catcher apron 28. Lower drive gear Handle mid 15. Roller assembly 29. Lower drive gear section 16. Roller screw (2) -
Page 5: Assemble Handle Section
Owner’s Manual — Sunlawn EM-2 CAUTION Always keep the battery cover locked. Failure to do so may allow batteries to fall out, causing damage to batteries, cables, and electric circuits. ASSEMBLE THE HANDLE SECTIONS 1. Set the cutting height to the highest setting as shown below. This will make it easier to attach the lower handle section. -
Page 6: Adjust Cutting Height
ADJUSTING THE CUTTING HEIGHT The cutting height of the EM-2 may be adjusted from approximately .4 inch up to approximately 2.2 inches. Actual height may vary according to the height of the turf. Adjust the mower to the desired height as... -
Page 7: Change Battery
Owner’s Manual — Sunlawn EM-2 1. Loosen the two large black knobs [Part # 9], one on each side of the mower body, to allow movement of the height adjustment arms [Part # 11]. (This is the same movement used to attach the handle.) NOTE: the handle is mounted to the height adjustment... -
Page 8: Operations
24 hours before the first use. NOTE: The sealed lead acid batteries of the EM-2 do not need to be fully discharged. The batteries will not develop a “memory.”... -
Page 9: Starting And Operating
Owner’s Manual — Sunlawn EM-2 STARTING AND OPERATING WARNING • Before starting the mower, check within the blade area for any foreign objects and remove them. • Do not operate the mower on areas other than turf surfaces. The mower should be sitting upright on a level part of the lawn before starting operation. -
Page 10: Overloading/Overheating
Owner’s Manual — Sunlawn EM--2 The grass catcher attaches at the grass catcher hooks on the mower and by the strap to the mower handle, as seen below. Mow using the same procedure as for normal mowing (described above). CAUTION Do not attach or remove the grass catcher while the motor is running. -
Page 11: Mowing: General Information
MAINTENANCE WARNING To avoid injury or damage to the unit do not clean the EM-2 using running water, a hose, or a high pressure stream. -
Page 12: Cleaning
Sharpening can only be done by a professional using a cylinder grinder and proper techniques. STORAGE 1. Store the EM-2, fully charged, in a cool, dry place. 2. The batteries need not be removed for winter storage unless they will be subject to sub-zero temperatures. - Page 13 5. Make the same adjustment at the other end of the cutting bar. 6. Now check the adjustment using the small 0.05mm/0.002 inch gauge (silver strip) [Part # 38] supplied with the EM-2 (or any 0.05mm/0.002 inch feeler gauge). If the gauge is held by the cylinder blades but the cylinder and cutting bar are not touching then the adjustment is correct.
-
Page 14: Replace Battery
Owner’s Manual — Sunlawn EM--2 REPLACING THE BATTERIES These instructions are for replacing the batteries if necessary. WARNING • Be careful to connect batteries correctly. Failure to do so may result in electric shock or damage to the electrical system of this mower. -
Page 15: Technical Data
Owner’s Manual — Sunlawn EM-2 TECHNICAL DATA Battery 2 x 12V / 7.2Ah Motor Drive 24V, 6A, 140W Charger Input: AC 100 – 240V 50 / 60 Hz 1.5A Output: _ _ _ _ 1500 mA UL listed Mower Cutting width:... - Page 16 Owner’s Manual — Sunlawn EM--2...
