Summary of Contents for Hip Street MP3 VIDEO PLAYER

  • Page 1: User Manual

    MP3 VIDEO PLAYER User Manual...
  • Page 2 MP3 Video Player Manual Support: Thank you for purchasing the Hip Street MP3 Video Player and we hope you enjoy using it. Please visit our website at www.hipstreetonline.com. We have a Frequently Asked Questions (FAQ) section where you will find answers to most of your questions. If you do not find an answer there, please use the option to contact our technical support department or kindly send us an email detailing your question and we will get back to you promptly.
  • Page 3 MP3 Video Player Manual IMPORTANT: If you need basic help with this product to load songs/photos onto this player, please visit our website at www.hipstreetonline.com or review the Interactive Product Tutorial (IPT) located on the CD that accompanied this product.
  • Page 4 MP3 Video Player Manual CONTENT ............................5 ..............................6 ............................10 ................................11 ............................12 ................................15 ............................17 1. T ROUBLE SHOOTING 2. S PECIFICATIONS...
  • Page 5 MP3 Video Player Manual Menu Prev/Vol- Next/Vol+ Play/Pause/Power On/Power Off When the battery is fully charged, slide the master power switch to the “ON” position located on the bottom of the unit and the player will be turned on automatically. Press [...
  • Page 6 MP3 Video Player Manual Select the Music mode from the main menu, then press the [MENU] button access to the relative playback interface. To return to the main menu, press and hold the [MENU] button and it will return to the main menu.
  • Page 7 MP3 Video Player Manual Volume control When music in play, press the [VOL] button and the volume icon [ ] will turn to red. Press [ ] / [ button to turn the volume up and down. Lyric Synchronization This player supports “*.LRC” files and synchronizes lyrics on the display. Make sure to keep the lyric file name the same as the song name, and save both lyric file and music file under the same directory.
  • Page 8 MP3 Video Player Manual your desired setting. There will be a corresponding icon displayed on the interface, for example: File Browser In the playback setting submenu, press the [ ] / [ ] button to choose the “File” mode” and you can browse all audio files.
  • Page 9 MP3 Video Player Manual Select the “Video” option from the main menu, press [MENU] button to display the video list, press the [ ] button and it will exit from the current interface. In the video list, press the [MENU] button and it will play the selected video file.
  • Page 10 MP3 Video Player Manual While playing video files, press the [Menu] button to set the repeat mode. In the video playing list, press the [ ] button to return to the main menu. Note: Please use the conversion software provided on the Driver CD to convert your video files to the .mtv format.
  • Page 11 MP3 Video Player Manual In the main menu, select the “e-Book” mode by pressing the [MENU] button. When an e-Book file is selected, press the [MENU] button to start eBook reading. Press the [ ] / [ ] button to scroll up and down. Press the [ ] button to return to the eBook list interface.
  • Page 12 MP3 Video Player Manual Record In the main menu, select the “Record” mode by pressing the [MENU] button. Press the [MENU] button again to start voice recording in WAV format (as shown in below image). Press the [ ] button to pause the recording. Press and hold the [Menu] button to save the recorded file and...
  • Page 13 MP3 Video Player Manual During the process of recording, short press [ ] button will pause/ start recording, long press [Menu] button to save the recorded file and return to the playing interface. Playback In the main menu, select the “Playback” mode by pressing the [MENU] button.
  • Page 14 MP3 Video Player Manual Volume control In the playback interface, press the [VOL] button and the volume icon [ ] will turn to red. Press the [ ] button to turn the volume up and down. Fast-forward/ Rewind In the playback interface, press and hold [ ] / [ ] button to fast-forward or rewind.
  • Page 15 MP3 Video Player Manual In the main menu, select the “Setup” mode by pressing the [MENU] button. In the Setup mode, select the option desired by pressing the [MENU] button. 1 Power: You can set the length of inactivity time in minutes before the player automatically turns off. In the state of play, it can be set at 15 minutes, 30 minutes, 60 minutes, 90 minutes and 120minutes, or you can choose “Disable”.
  • Page 16 MP3 Video Player Manual turn off automatically after 120 minutes of inactivity time. 2 Language: You can set the language to your preference. Currently the player supports 10 languages, which includes: English, French, German, Italian, Spanish, Portuguese, Polish, Russian, Simplified Chinese, and Traditional Chinese.
  • Page 17: Troubleshooting

    MP3 Video Player Manual 1. Trouble-shooting The player will not start Please make sure the master power switch is turned on. No sound heard from the Please make sure the volume is not set at 0 and earphone earphone connection is securely in place.
  • Page 18: Specifications

    MP3 Video Player Manual 2. Specifications Display screen 1.8” (128 x160) color display screen USB specification USB2.0 Memory Flash: Power Source Sampling rate 8KHz Record Record format Headphone maximum output MP3 bit rate WMA bit rate MP3, WMA Frequency response...
  • Page 19 Lecteur vidéo MP3 Guide d’utilisation...
  • Page 20 Guide d’utilisation - Lecteur vidéo MP3 Assistance à la clientèle : Merci d’avoir acheté le lecteur vidéo MP3 Hip Street, nous espérons que vous aimerez utiliser cet appareil. Visitez notre site Web à www.hipstreetonline.com. Vos y trouverez une section réservée à une foire aux questions où...
  • Page 21 Guide d’utilisation - Lecteur vidéo MP3 IMPORTANT : Si vous avez besoin d’aide pour télécharger des fichiers musicaux et de photos dans cet appareil, veuillez visiter notre site Web à www.hipstreetonline.com consultez le tutoriel interactif IPT (Interactive Product Tutorial) que vous trouverez sur le CD accompagnant ce lecteur.
  • Page 22 Guide d’utilisation - Lecteur vidéo MP3 TABLE DES MATIÈRES CHAP CHAP CHAP CHAPITRE ITRE ITRE ITRE 1 1 1 1 - - - - DESCRIPTION DE L DESCRIPTION DE L DESCRIPTION DE L’APPAREIL DESCRIPTION DE L ’APPAREIL ’APPAREIL ’APPAREIL ......................5 CHAP CHAP CHAP...
  • Page 23: Description De L'appareil

    Guide d’utilisation - Lecteur vidéo MP3 Chap Chap Chap Chapitre itre itre itre 1 1 1 1 Description de l’appareil Description de l’appareil Description de l’appareil Description de l’appareil Menu Précédent/Vol- Suivant/Vol+ Lecture/Pause/Marche/Arrêt Lorsque la pile est entièrement chargée, glissez l’interrupteur principal, se trouvant sous l’appareil, à la position ON et le lecteur se mettra automatiquement en marche.
  • Page 24 Guide d’utilisation - Lecteur vidéo MP3 Chap Chap Chap Chapitre itre itre 2 2 2 2 itre Lecture de fichiers musicaux Lecture de fichiers musicaux Lecture de fichiers musicaux Lecture de fichiers musicaux Sélectionnez le mode musique (Music) dans le menu principal, puis appuyez sur la touche MENU pour accéder à...
  • Page 25 Guide d’utilisation - Lecteur vidéo MP3 Lecture / Pause Pendant la lecture d’un fichier musical, appuyez sur la touche [ ] pour effectuer une pause dans la lecture. Appuyez de nouveau sur cette touche pour poursuivre la lecture. Réglage du volume Pendant la lecture d’un fichier musical, appuyez sur la touche VOL et le symbole du volume [ apparaîtra en rouge à...
  • Page 26 Guide d’utilisation - Lecteur vidéo MP3 Égaliseur de fréquences (EQ) Dans le sous-menu de configuration de lecture, utilisez les touches [ ] / [ ] pour sélectionner l’option EQ (égaliseur de fréquences) et appuyez sur la touche MENU pour confirmer. Vous avez ici le choix entre les réglages suivants : normal, pop, rock, classique (Classical), jazz et basses (Bass).
  • Page 27: Lecture De Fichiers Vidéo

    Guide d’utilisation - Lecteur vidéo MP3 Chap Chap Chap Chapitre itre itre itre 3 3 3 3 Lecture de fichiers vidéo Lecture de fichiers vidéo Lecture de fichiers vidéo Lecture de fichiers vidéo Sélectionnez l’option vidéo (Video) dans le menu principal puis, appuyez sur la touche MENU pour faire apparaître à...
  • Page 28 Guide d’utilisation - Lecteur vidéo MP3 Pendant la lecture de fichiers vidéo, appuyez sur la touche MENU pour activer le mode de lecture répétée. Lorsque la liste des fichiers vidéo apparaît à l’écran, appuyez sur la touche [ ] pour revenir au menu principal.
  • Page 29 Guide d’utilisation - Lecteur vidéo MP3 Chapitre Chapitre Chapitre Chapitre 5 5 5 5 C C C C yberlivre yberlivre yberlivre yberlivre À partir du menu principal, appuyez sur la touche MENU pour sélectionner le mode cyberlivre (e-Book). Une fois qu’un fichier du cyberlivre a été sélectionné, appuyez sur la touche MENU pour démarrer la lecture du fichier en question.
  • Page 30 Guide d’utilisation - Lecteur vidéo MP3 Chap p p p itre itre itre itre 6 6 6 6 Enregistre Enregistreur ur ur ur vocal vocal Enregistre Enregistre vocal vocal Enregistrement À partir du menu principal, sélectionnez le mode d’enregistrement (Record) en appuyant sur la touche MENU.
  • Page 31 Guide d’utilisation - Lecteur vidéo MP3 Lorsque l’enregistrement est en cours, appuyez brièvement sur la touche [ ] pour effectuer une pause puis poursuivre l’enregistrement. Si vous appuyez longuement sur la touche MENU, le fichier d’enregistrement sera sauvegardé et l’interface d’enregistrement reviendra à l’écran. Lecture À...
  • Page 32 Guide d’utilisation - Lecteur vidéo MP3 Enregistrement précédent / suivant Dans l’interface de lecture, appuyez sur la touche [ ] ou [ ] pour passer à l’enregistrement précédent ou suivant. Réglage du volume Dans l’interface de lecture, appuyez sur la touche VOL et le symbole du volume [ ] apparaîtra en rouge à...
  • Page 33 Guide d’utilisation - Lecteur vidéo MP3 Chap Chap Chap Chapitre itre itre 7 7 7 7 itre Configuration Configuration Configuration Configuration À partir du menu principal, sélectionnez le mode de configuration (Setup) en appuyant sur la touche MENU. En mode configuration, sélectionnez l’option de votre choix en appuyant sur la touche MENU.
  • Page 34 Guide d’utilisation - Lecteur vidéo MP3 Alimentation (Power) : Vous pouvez programmer le nombre de minutes d’inactivité requises avant que le lecteur ne s’éteigne automatiquement. En mode de lecture, cette durée peut être réglée à 15, 30, 60, 90 ou 120 minutes. Vous pouvez également désactiver l’arrêt automatique du lecteur toutefois, lorsque celui-ci est en mode de veille, il s’éteint automatiquement après 120 minutes d’inactivité.
  • Page 35 Guide d’utilisation - Lecteur vidéo MP3 Chap Chap Chap Chapitre itre itre itre 8 8 8 8 À l’intention de l’utilisateur À l’intention de l’utilisateur À l’intention de l’utilisateur À l’intention de l’utilisateur 1. Guide de dépannage Le lecteur ne démarre L’interrupteur principal doit être place à...
  • Page 36: Fiche Technique

    Guide d’utilisation - Lecteur vidéo MP3 2. Fiche technique Écran Écran couleur de 1,8 pouces (128 x160) Connexion USB USB 2.0 Flash : 2 Go ~ 4 Go (selon le modèle) Mémoire Lecture de fichiers musicaux 8 h et fichiers vidéo 4 h (environ) Autonomie de la pile Taux d’échantillonnage 8 KHz...
