2
Connecting and Using a Source Device

2.2.2 Connection Using the HDMI-DVI Cable

Do not connect the power cable before connecting all other cables.
Ensure you connect a source device first before connecting the power cable.
1
Connect the HDMI-DVI cable to the [HDMI IN 1] or [HDMI IN 2] port on the back of the product and
the DVI port on the PC.
2
Connect the DC power adapter to the product and a power socket.
Next, turn on the power switch on the PC. (For details, refer to "2.2.5
3
Change the input source to
source is not set.
Provided ports may vary depending on the product.

2.2.3 Connection Using the DP Cable

Do not connect the power cable before connecting all other cables.
Ensure you connect a source device first before connecting the power cable.
1
Connect the DP cable to the [DP IN] port on the back of the product and the DP port on the PC.
2
Connect the DC power adapter to the product and a power socket. Next, turn on the power switch
on the PC. (For details, refer to "2.2.5
3
Change the input source to
is not set.
Provided ports may vary depending on the product.
HDMI IN 1 / HDMI IN 2
HDMI 1 or HDMI 2 controlling the JOG button UP/DOWN, when input
DP IN
Connecting the Power".)
DisplayPort controlling the JOG button UP/DOWN, when input source
2 Connecting and Using a Source Device
Connecting the Power".)
29
