CM7000 Master Guide
1
2
3
4
5
6
7
8
Feature
Programmable
Output Connector
1 POC #1
2 POC #2
3 POC #3
4 POC #4
5 POC #5
6 POC #6
7 POC #7
8 POC #8

Option Menu Descriptions

FO = Feature Option
1-01 Unlock before, Lock after:
FO1 - Off
FO2 - On: Sends an unlock command as soon as the remote start sequence is triggered then send a
relock command as soon as the CM7 has confirmed remote start success.
FO3 - Lock after start only: Sends a lock command after the CM7 has confirmed remote start
success.
FO4 - Lock after shutdown only: will send a lock command only after the CM7 has successfully
shut down. Note: It will not provide an output if the CM7 is shut down with an
emergency override input. (i.e. hood pin, or foot brake input)
Copyright 2014 Firstech, LLC.
Special Option Group 1
Feature
Diesel Timer - DISL
AUX1 output time
AUX2 output time
AUX3 output time
AUX4 output time
AUX5 output time
AUX6 output time
AUX7 output time
Special Option Group 2
0 - Default Setting
(-) Starter Kill (Blue/White)
(-) Auxiliary 1 (White)
(-) Lock (Blue/Black)
(-) Unlock (Blue)
(-) Disarm (Orange/White)
(-) Rearm (Orange)
(-) Trunk (Violet/White)
(-) Status (Black)
Alarm and Starter System
Setting Value (Seconds)
Setting and OP500 Value
1~28 – Optional Settings
2nd Light - [1] 2nd Start - [2]
2nd Acc - [4] Status Out - [5] Rearm Out - [6]
Disarm Out - [7] Horn Out - [8] Dome Light - [9]
Aux 1 Out - [10] Aux 2 Out - [11] Aux 3 - [12]
Aux 4 Out - [13] Aux 5 Out - [14] Aux 6 Out - [15]
Aux 7 Out – [16] Defrost - [17] GWA - [18]
Status 2 For Manual Trans. - [19] Siren 2 - [20]
Defrost 2 - [21] VAC - [22] PTS Button - [23]
Aux 3 (EZGO Unlock) - [24] Lock - [25] Unlock - [26]
2nd Unlock (Driver's Priority) - [27] Trunk Release - [28]
techfeed.compustar.com
3 ~ 99
1 ~ 100
1 ~ 100
1 ~ 100
1 ~ 100
1 ~ 100
1 ~ 100
1 ~ 100
2nd IG1 - [3]
Page 28
