Instructions for Installation and Use
50cm Free Standing Gas Cooker
51TGW
HW170GK
HW170GW
HW150GW
HW170GIK
HW170GIW
HW170LIK
HW170LIW
NOTE: This appliance is fitted with a battery powered
ignition system (the battery provided). Sholud the ignition
system start to spark slowly - or not at all, the
battery will need replacing. See the section on
battery replacement.
May explode or leak if recharged, disposed of
in fire, shortcircuited or improperly inserted.
0% MERCURY AND CADMIUM
To the Installer
Before installation fill in the product details on the back cover this book.
The information can be found on the rating plate.
To the User
You must read the instructions prior to installing and using the appliance and
then retain them for future reference.
Advertisement
Table of Contents
Related Manuals for Hotpoint 51TGW
Summary of Contents for Hotpoint 51TGW
- Page 1 Instructions for Installation and Use 50cm Free Standing Gas Cooker 51TGW HW170GK HW170GW HW150GW HW170GIK HW170GIW HW170LIK HW170LIW NOTE: This appliance is fitted with a battery powered ignition system (the battery provided). Sholud the ignition system start to spark slowly - or not at all, the battery will need replacing.
-
Page 2: Table Of Contents
Care and Cleaning / Battery Replacement Cooking Results Not Satisfactory? Something Wrong With Your Cooker? Technical Characteristics After Sales Service Hotpoint Guarantee Key Contacts You must read these instructions prior to using your appliance and retain them for future use. Back Cover... -
Page 3: Introduction
Introduction Your new appliance is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet. To help make best use of your cooking equipment, please read this booklet carefully. The cooker is designed specifically for domestic use and responsibility will not be accepted for use in any other installation. -
Page 4: Installation
Installation The appliance must only be installed by a competent person. In the UK, CORGI registered installers undertake to work to safe and satisfactory standards. Before moving your cooker check that it is cool, and switch off at the cooker control unit. Movement of your cooker is most easily achieved by lifting the front as follows: Open the grill door sufficiently to allow a comfortable grip on the underside front edge of the oven roof, avoiding any grill elements. - Page 5 Gas connection The cooker should be connected to the gas-supply by a corgi registered installer. During installation of this product it is essential to fit an approved gas tap to isolate the supply from the appliance for the convenience of any subsequent removal or servicing. Connection of the appliance to the gas mains or liquid gas must be carried out according to the prescribed regulation in force, and only after it is ascertained that it is adaptable to the type of gas to be used.
- Page 6 c) Minimum regulation of the hob burners: • turn the tap to minimum; • remove the knob and adjust the regulation screw, which is positioned in or next to the tap pin, until the flame is small but steady. N.B.: in the case of liquid gas, the regulation screw must be screwed in to the bottom. •...
- Page 7 • check that the burner does not turn off when you turn the knob from Max to Min and and when you open and close the oven door quickly. Adapting the gas grill to different types of gas Replacing the nozzle of the grill burner: •...
-
Page 8: Burner And Nozzle Specifications
Burner and Nozzle Specifications Table 1 Burner Diameter Thermal Power (mm) Nominal Fast (Large)(R) 2,60 only model 51TGW Fast 3,00 (Large)(R) Semi Fast 1,90 (Medium)(S) Auxiliary 1,00 (Small)(A) Oven 2,60 Grill 2,50 Nominal (mbar) Supply Minimum (mbar) Pressures Maximum (mbar) At 15°C and 1013 mbar- dry gas... -
Page 9: Safety Information
Safety Information When used properly your appliance is completely safe but as with any electrical product there are certain PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE. Always Remove all packing from inside the oven and grill compartments before switching on for the first time. Understand the controls prior to using the appliance. - Page 10 Safety Information Never Never line the interior of the oven with foil as this may cause the appliance to overheat. Never leave children unsupervised where a cooking appliance is installed as all surfaces will be hot during and after its use. Do not allow children or persons who are not familiar with the appliance to use it, without supervision.
-
Page 11: Features 1
Features 1900W GRILL/MEAT PAN WITH REMOVABLE HANDLE AND WIRE FOOD SUPPORT GRILL GRILL DOOR REMOVABLE INNER GLASS DOOR OR BLIND DOOR HOB VENTILATION SLOTS 1000W BATTERY 1900W 3000W CONTROL PANEL MAIN OVEN W I R E W O R K SHELF SUPPORTS MODEL &... -
Page 12: Control Panel 1
Control Panel MAIN GRILL OVEN Control Knobs The position of the gas burner controlled by each one of the knobs is shown by a solid ring •. To light one of the burners, hold a lighted match or lighter near the burner and, at the same time, for the gas burners press down and turn the corresponding knob counter clockwise to the maximum... -
Page 13: Use Of Hotplates 1
Use of Hotplates Practical Advice on Using the Burners To use the burners as efficiently as possible, some basic guidelines should be followed: • Use cookware that is the right size for each burner (see table) in order to prevent the flame from spreading beyond the bottom of the cookware. -
Page 14: Grilling 1
Grilling CAUTION: ACCESSIBLE PARTS WILL BECOME HOT WHEN THE GRILL To operate the grill proceed as follows: Open the grill door and remove the grill pan. Press the ignition button and then push in and turn the grill control knob anti-clockwise to the large flame symbol. -
Page 15: Oven 1
Oven The oven has different heat zones - the thermostat settings refer to the temperature on the middle shelf; above this shelf it is hotter and below it is cooler. Two shelves enable full use of the temperatures inside the oven. Each shelf has a safety stop to prevent if from being pulled out too far when attending to food. -
Page 16: Oven Cooking Charts 1
Oven Cooking Chart The following times and setting are for guidance only. You may wish to alter the setting to give a result more to your satisfaction. When a different setting to that shown below is given in a recipe, the recipe instructions should be followed. -
Page 17: Care And Cleaning / Battery Replacement 1
Care and Cleaning Grill Remove the grill pan and the wire grid food support, it is best to wash these items immediately after use to prevent stains from being burnt on when used again. Wipe out the Grill compartment, use a fine steel wool soap pad to remove stubborn stains from the grill runners and the floor of the compartment. -
Page 18: Cooking Results Not Satisfactory? 1
Cooking Results Not Satisfactory? Problem Grilling Uneven cooking front to back Fat splattering Oven Baking Uneven rising of cake Sinking of cakes Over/Under cooking Fast/Slow cooking Uneven cooking of cakes Uneven rising of cake Food is taking too long to cook Check Ensure that the grill pan is positioned centrally below the grill element. -
Page 19: Something Wrong With Your Cooker? 1
Something Wrong with your Cooker? Before contacting your nearest Service Centre/Installer, check the problem guide below; there may be nothing wrong with your cooker. Problem Ignition does not work Top Cavity Hob Top Oven or Grill will not stay lit when the control knob is released Control Panel Oven Temperature seems too... -
Page 20: Technical Characteristics 2
Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance. Mains frequency and voltage of the electric section and characteristics of the gas section Model Class 51TGW HW170GW HW170GK HW150GW II2H3+ HW170LIK... -
Page 22: After Sales Service 2
Hotpoint appliance than us - the manufacturer" As part of our commitment to you, all Hotpoint appliances have the added benefit of a fully inclusive parts and labour guarantee for the first 12 months. In addition to this you also have the advantage of free replacement parts for the first 5 years when fitted by a Hotpoint engineer. - Page 23 All Hotpoint appliances carry a fully inclusive 12 month parts and labour guarantee as well as free replacement parts for the first 5 years (except microwaves, selected integrated appliances and cooker hoods, which have a one year guarantee) provided that they are fitted by a Hotpoint engineer.
-
Page 24: Key Contacts
