Hotpoint NLLR113EVWW Specification

NLLR113EVWW - Hotpoint Large Capacity Dryer

Dryer Dimensions (in inches)

23-1/2 25-3/4
25-1/2
4-3/4
Side View
Specification Revised 8/99
27
42
11-3/4
36
2
5-1/2
2-1/2
Rear View
Best Performance
Maximum Length of 4"
Dia. Rigid Metal Duct
A
A
Exhaust Hood Type
4
Number Cat. No.
B
of WX8X59
90° (Preferred)
Domestic 2-1/2 Turns A
Dryer Models 4" Opening
0 90 ft.
1 60 ft.
Super & Extra-Large 2 45 ft.
Capacity Models 3 35 ft.
All Electric Dryers 4 25 ft.
0 45 ft.
Super & Extra-Large 1 35 ft.
Capacity Models 2 25 ft.
All Gas Dryers 3 15 ft.
0 60 ft.
1 52 ft.
Large Capacity 2 44 ft.
Electric and 3 32 ft.
Gas Dryers 4 28 ft.

Exhaust Options:

4-way via rear, right, left and bottom.

Circuit Requirements:

An individual, properly-grounded branch circuit, protected by a 30-amp circuit breaker or a time-delay
fuse, is required.

Electric Dryer Rating:

208/240V, 3-wire, 5600W, 60Hz, 30 Amp
Installation Information: For complete information, see installation instructions packed with product
for current dimensional data.
Maximum Length of 4"
Dia. Flexible Metal Duct
Exhaust Hood Type
Cat. No.
WX8X59
B
B (Preferred)
2-1/2" A 2-1/2"
Opening
Opening 4" Opening
60 ft. 55 ft. 45 ft.
45 ft. 40 ft. 30 ft.
35 ft. 30 ft. 20 ft.
25 ft. 20 ft. 15 ft.
15 ft. 15 ft. 10 ft.
30 ft. 30 ft. 15 ft.
20 ft. 20 ft. 10 ft.
10 ft. 10 ft. —
— — —
48 ft. 30 ft. 18 ft.
40 ft. 22 ft. 14 ft.
32 ft. 14 ft. 10 ft.
24 ft. — — ft.
16 ft. — — ft.
