SecurityMan SM-302R Specifications

Add-on 900mhz wireless receiver

Advertisement

Quick Links

Add-on 900MHz wireless receiver (FreeCam2)

Package Contents

• 1 x SM-302R receiver (with antenna)
• 1 x Power adapter
• 1 x AV cable

Product Basics

Installation Diagram

1)
Connect the receiver to a monitor/TV with AV cable (yellow for video and red audio). Turn on
the monitor/TV and select AV mode.
2)
Connect the power jack of adapter (DC 7.5V 300mA) to receiver. Press the Power ON/OFF button
and the channel indicator lights up green.
Specifications of Receiver (SM-302R)
Transmission Frequency
Channel Options
Channel Selection and Control
Channel Indication
Frequency Stability
Local Oscillator Leakage
Receiving Sensitivity
Differential Phase
S/N
Video Output Impedance
Audio Output Voltage
Audio Carrier
Audio Frequency Band
Audio Output Impedance
Audio Output Impedance
Audio S/N
Antenna Type
RF Input Impedance
Power Consumption
Power
Power Switch
A/V Output (To Monitor/TV)
SecurityMan
902~928MHz
2 Channels Selection_906MHz/924MHz
Three dip switches (Ch1/Ch2/auto-loop)
2 Green LED
±100KHz
<-55 dBm
<-85 dBm
10Deg.
38dB
75ohm
1.0±0.2Vp-p(Standard value:1Vp-p)
4.5MHz
100_20KHz
10Kohm
1.2±0.4Vp-p(Standard value:1Vp-p)
50dB
SMA
50ohm
180mA(MAX.)
7.5V 300mA(Positive in and negative out)
Touch Button
®
