Nature Power 60 LED Instruction Manual

60 led solar security light

Version 1.1

Product Description

Thank you for purchasing the 60 LED Solar Security Light. Please read this

instruction manual carefully to obtain the best results from your purchase.

Item Number: 22050

Parts List

1. Lamp

2. Solar Panel (5M Wire)

3. Expansion Screw

4. 60 LEDs

5. Battery Housing

6. Motion Detector head

7. U-Shaped Mounting Plate

60 LED Solar Security Light

Instruction Manual

8. ON/OFF/AUTO Switch

9. Battery Housing Outlet

10. Solar Panel Mounting Bracket

11. LUX Adjusting Dial (Shown in Fig 7)

12. SENS Adjusting Dial (Shown in Fig 7)

13. Time Adjusting Dial (Shown in Fig 7)

14. NI-HM Battery (Not Shown)

Table of Contents

Need help?

Do you have a question about the 60 LED and is the answer not in the manual?

Page 1 Version 1.1 60 LED Solar Security Light Instruction Manual Product Description Thank you for purchasing the 60 LED Solar Security Light. Please read this instruction manual carefully to obtain the best results from your purchase. Item Number: 22050 Parts List 1.
Page 2 Version 1.1 Assembly Solar Panel Wall or Deck Mounted 1. Secure bracket to solar panel with screw provided as shown in Fig 5. 2. Set bracket on surface and secure in place with larger screws provided as shown in Fig 6. 3.
Page 3: Operation
‘Off’ - When the switch is in the ‘Off’ position the light will remain off and will not detect any movement. 2. Allow 60 LED Solar Security Light to charge for at least 3 days with the switch in the ‘Off’ position. How to use Control Dials (See Fig 7) The 60 LED Solar Security Light has 3 different control dials which allow you to adjust the settings.
Page 4: Troubleshooting
Version 1.1 Troubleshooting If 60 LED Solar Security Light does not illuminate when movement in front of the sensor is obvious please observe the following.  Ensure the solar panel is in a location where it will receive maximum sunlight during daytime hours.
Page 5 Version 1.1...
