GSi GS-405 IRVC Specifications

GOLDEN STATE INSTRUMENT CO.
This camera uses P.O.D. (Precision OSD DSP) technology. This
technology enables the user to precisely fine tune all the camera
functions according to the application. No matter what the
conditions are, you will be able to achieve optimum picture quality.
Using Sony Super HAD II CCD with Sony's HQ1 DSP this camera
achieves amazing low light performance and color reproduction.
With an Ultra High 550 TVL of color resolution gives this camera
superior image quality unmatched by others. The 3 axis mount
makes this a very versatile camera that can be placed on ceilings or
walls with very little effort. DWDR (Digital Wide Dynamic
Range) provides excellent picture under tough lighting conditions.
Features:

1/3" SONY Super HAD II CCD

High 550 TVL Color Resolution

Super BLC (Back Light Compensation)

DWDR (Digital Wide Dynamic Range)

HLC (High Light Compensation)

4-9mm Varifocal Lens (External Controls)

36 IR LED's (65-100ft Illumination)

Built-in new 20 bit DSP (Digital Signal Processing)
Specifications:
Signal System
Image Sensor
Series
Effective Pixels
Scanning System
Scanning Frequency (V)
Resolution
Min. Illumination
Light Compensation
S/N Ratio
Shutter Speed
Video Output
Sync System
Voltage
Power Consumption
Dimensions
Weight
Operating Temperature
3002 Dow Ave Suite 228
Tustin, CA 92780 USA
Infrared LED Dome Camera
NTSC
1/3" SONY Super HAD II
P.O.D.
768(H) x 494(V)
2:1 Interlace
59.94Hz
Ultra High 550 TVL
0.01 LUX (LED Off) | 0 LUX (LED On)
DWDR, BLC, HLC
More than 52dB (AGC OFF)
1/60 ~ 1/1000,000 sec.
1.0 Vp-p (75Ω)
Internal
12VDC
120 mA (LED's OFF) | 500mA (LED's ON)
4.75" Diameter 4.5" Height
1.8 lbs
-20°C to 50°C
www.goldenstateinst.com
GS-405 IRVC
Vandal Dome X-Y-Z Axis Mount
4-9mm External Varifocal Lens
550 TVL Day/Night Color Camera

Vandal Proof Ball Glove Dome

X-Y-Z, 3 Axis Mount

12VDC

OSD (On Screen Display) Menu Controls

Turbo AGC (Automatic Gain Control)

DNR (Digital Noise Reduction)

Sharpness and Mirror Functions

IP66 Weather Rating
WARNING:
Do Not Point Camera Directly
into the sun.
Do Not cut video or power
wires
Observe Correct Voltage and
Polarity
Failure to Observe Warnings
May Void Warranty
Sales : 800-227-2330
Tech Support: 888-808-0909
Email : gsi@goldenstateinst.com
