Gefen GTV-HT-AUDPROCN User Manual

4x1 av processor with amp
Hide thumbs Also See for GTV-HT-AUDPROCN:
Table of Contents

Advertisement

Quick Links

Download this manual
4x1
3GSDI
GTV-HT-AUDPROCN
AV Processor
Audio
Embedder
with Amp
User Manual
Release A3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GTV-HT-AUDPROCN and is the answer not in the manual?

Questions and answers

Related Manuals for Gefen GTV-HT-AUDPROCN

Summary of Contents for Gefen GTV-HT-AUDPROCN

  • Page 1 AV Processor 3GSDI Audio Embedder with Amp GTV-HT-AUDPROCN User Manual Release A3...

  • Page 2: Important Safety Instructions

    4x1 AV Processor with Amp Important Safety Instructions GENERAL SAFETY INFORMATION Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this product near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

  • Page 3: Warranty Information

    Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notified within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications.
  • Page 4 4x1 AV Processor with Amp is a trademark of Gefen, LLC. Important Notice Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice. HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing in the United States and other countries.
  • Page 5 3GSDI Audio Embedder 4x1 AV Processor with Amp Operating Notes • The 4x1 AV Processor with Amp has 8 speaker outputs. A maximum of 5 discrete channels of audio can be output via these connectors. 2 additional connectors are available for optional bi-amping of the front left and right channels. •...
  • Page 6 4x1 AV Processor with Amp Features and Packing List Features • Supported HDMI Features: ► Resolutions up to 1080p Full HD ► HDCP compliant ► 12-bit Deep Color ► 3DTV pass-through ► Lip Sync pass-through • Supported audio formats: LPCM, Dolby® Pro Logic, Dolby® Pro Logic II, Dolby® Digital •...

  • Page 7: Packing List

    Packing List The 4x1 AV Processor with Amp ships with the items listed below. If any of these items are not present in your box when you first open it, immediately contact your dealer or Gefen. • 1 x 4x1 AV Processor with Amp •...

  • Page 8: Table Of Contents

    3GSDI Audio Embedder 4x1 AV Processor with Amp Table of Contents Getting Started Panel Layout ......................2 Front ......................2 Back ......................4 IR Remote Control Unit ..................6 Back ......................8 Installing the Battery ..................9 Setting the IR Channel .................. 9 Connecting the 4x1 AV Processor with Amp ..........
  • Page 9 4x1 AV Processor with Amp Table of Contents Appendix Menu System Layout................... 80 Main Menu ....................80 Speaker Size Menu ..................82 Speaker Level Menu ................... 83 Speaker Distance Menu ................85 Tone Control Menu ..................87 Audio Setup Menu ..................88 Misc Setup Menu ..................

  • Page 11: 01 Getting Started

    AV Processor with Amp 01 Getting Started Panel Layout ......................2 Front ......................2 Back ......................4 IR Remote Control Unit ..................6 Back ......................8 Installing the Battery ..................9 Setting the IR Channel .................. 9 Connecting the 4x1 AV Processor with Amp ..........10 Sample Wiring Diagram ................

  • Page 12: Panel Layout

    Getting Started Panel Layout Front Name Description This IR window receives commands from the included IR Remote Control Unit. Mute ► This button will cycles between Mute-On and Mute-Off modes. When the Mute-On mode is enabled, all audio output will be ceased. While in the Menu System this button will cycle through available options in the right direction when a feature has been selected...
  • Page 13 Getting Started Panel Layout Name Description Volume ▼ Press this button to decrease the volume level of the audio outputs. While in the Menu System, this button is used to scroll down through the current menu options. Using the Menu System for more information.

  • Page 14: Back

    Getting Started Panel Layout Back Name Description Bi-Amp FR, FR, Bi-Amp FL, These speaker binding posts will accept FL, SR, SL, C spade lug, banana plug, dual banana plug, bare wire, and pin style connections. The Front Left and Front Right speakers can be “bi-amped”...
  • Page 15 HD Out Connect an HDMI cable between this connector and a HDTV display. IR Ext Connect an IR Extender (Gefen part no. EXT-RMT-IREXT) to this port to extend the range of the IR remote control unit. Trigger (Out / In) These Phoenix connectors provide 11.5V...

  • Page 16: Ir Remote Control Unit

    Getting Started IR Remote Control Unit Front Name Description MUTE Press this button to mute / un-mute the audio output signal. MODE Press this button to cycle through each of the available audio modes. These buttons are the equivalent of the A/S/D/W/ ENTER Input ◄, Volume ▼, Mute ►, Volume ▲,...
  • Page 17 Getting Started IR Remote Control Unit Name Description COAX Press this button to select the S/PDIF audio input source. POWER Press this button to toggle between power ON and standby mode . The Power LED indicator will indicate the current power state. Standby Mode / Powering the 4x1 AV Processor with Amp for more information.

  • Page 18: Back

    Getting Started IR Remote Control Unit Back (shown with cover removed) Name Description DIP switch bank Use these DIP switches to set the IR channel of the remote. See Setting the IR Channel for details. Primary battery slot Holds the battery for operating the remote. (shown without battery) Use only 3V CR2032-type batteries.

  • Page 19: Installing The Battery

    Getting Started IR Remote Control Unit Installing the Battery The IR remote control unit ships with two batteries. Only one battery is required for operation. The second battery is a spare. Use only 3V CR2032-type batteries. Remove the back cover the IR Remote Control unit. Insert the included battery into the primary battery slot.

  • Page 20: Connecting The 4X1 Av Processor With Amp

    Analog Audio Source HD Source Low Pass 4x1 AV Processor w/Amp Passive Crossover* HD Display High Pass Passive Crossover* R Mid-woofer* *For use with Bi-amping only Powered Subwoofer Low Pass GTV-HT-AUDPROCN Passive Crossover* Using built-in amplification L Mid-woofer* page | 10...

  • Page 23: Operating The 4X1 Av Processor With Amp

    AV Processor with Amp 02 Operating the 4x1 AV Processor with Amp Front Panel Controls ................... 14 Home Screen ....................14 Standby Mode / Powering the 4x1 AV Processor with Amp ...... 14 Selecting the Input Source ................15 Adjusting the Volume .................. 16 Muting the Audio Output ................

  • Page 24: Front Panel Controls

    Operating the 4x1 AV Processor with Amp Front Panel Controls Home Screen The home screen displays information regarding the current settings of the 4x1 AV Processor with Amp. The home screen is also used in conjunction with navigating the built-in Menu System. After powering on the 4x1 AV Processor with Amp, the home screen will be displayed.

  • Page 25: Selecting The Input Source

    Operating the 4x1 AV Processor with Amp Front Panel Controls Selecting the Input Source Press the Input ◄ button to cycle through each input source. The table below lists which inputs are active for each selection. A/V Input Displays the currently selected A/V input H1 HD -30db...

  • Page 26: Adjusting The Volume

    Operating the 4x1 AV Processor with Amp Front Panel Controls Adjusting the Volume Use the Volume ▲ and Volume ▼ buttons to increase or decrease the audio output gain. The ▲ or ▼ buttons on the IR Remote Control can also be used to control the audio output gain.

  • Page 27: Changing The Audio Processing Mode

    Operating the 4x1 AV Processor with Amp Front Panel Controls Changing the Audio Processing Mode Successively press the Mode / OK button on the front panel to cycle through the different audio processing modes. The Mode button on the IR Remote Control can also be used to cycle through the audio modes.

  • Page 28: Using The Menu System

    Operating the 4x1 AV Processor with Amp Using the Menu System The 4x1 AV Processor with Amp comes with a built-in menu system which provides control over additional audio features. The following examples demonstrate some of the more common features of the 4x1 AV Processor with Amp. Setting the Speaker Size Speaker size is determined by the ability of a speaker to reproduce low frequencies.

  • Page 29: Speaker Size

    Operating the 4x1 AV Processor with Amp Using the Menu System Press the Exit button to save the changes and return to the Speaker Size menu. Press the Exit button a second time to return to the home screen. H1 HD -30DB NONE DIRECT...

  • Page 30: Setting The Speaker Levels

    Operating the 4x1 AV Processor with Amp Using the Menu System Setting the Speaker Levels When using the IR Remote Control, the INFO | TEST TONE button is used to produce a test tone to adjust the output level of each channel. The test tone can also be enabled or disabled using the TEST command.

  • Page 31: Setting The Speaker Distance

    Operating the 4x1 AV Processor with Amp Using the Menu System Setting the Speaker Distance Setting the correct speaker distance is required to make sure that the sounds from each speaker reach your ear at precisely the same time. The distance for each speaker can be set in 1.5 foot (0.5 meter) increments within a range of 0 feet - 33 feet (10 meters).

  • Page 32: Speaker Distance

    Operating the 4x1 AV Processor with Amp Using the Menu System Using the IR Remote Control From the home screen, press the MENU button. Use the ▲ or ▼ buttons to navigate to the Speaker Distance menu: MAIN MENU SPEAKER DISTANCE Press the ENTER button.

  • Page 33: Adjusting The Tone Control

    Operating the 4x1 AV Processor with Amp Using the Menu System Adjusting the Tone Control The Tone Control menu provides the ability to adjust the bass and treble to personal preference. Treble and bass can be increased or decreased in 1 dB intervals, within a range of -12 dB to +12 dB.
  • Page 34 Operating the 4x1 AV Processor with Amp Using the Menu System Using the IR Remote Control From the home screen, press the MENU button. Use the ▲ or ▼ buttons to select the Tone Control menu: MAIN MENU TONE CONTROL Press the ENTER button.

  • Page 35: Setting The Audio Processing Mode

    Operating the 4x1 AV Processor with Amp Using the Menu System Setting the Audio Processing Mode The 4x1 AV Processor with Amp, allows any of five audio processing modes to be associated with a selected input. For example, you may want to select the Multichannel Stereo audio processing mode with the optical (TOSLINK) input.

  • Page 36: Audio Setup

    Operating the 4x1 AV Processor with Amp Using the Menu System Using the front panel buttons Example 1: Assigning the optical (TOSLINK) input with the Multichannel Stereo audio processing mode: From the home screen, press the Menu button. Use the Volume ▲ or Volume ▼ buttons to navigate to the Audio Setup menu: MAIN MENU AUDIO SETUP...
  • Page 37 Operating the 4x1 AV Processor with Amp Using the Menu System Example 2: Assigning the analog L/R inputs with the Dolby Pro Logic II audio processing mode: Starting from Step 5, on the previous page, use the Volume ▼ button to select the analog L/R option: AUDIO SETUP AUD LR...
  • Page 38 Operating the 4x1 AV Processor with Amp Using the Menu System Using the IR Remote Control Example 1: Assigning the optical (TOSLINK) input with the Multichannel Stereo audio processing mode: From the home screen, press the MENU button. Use the ▲ or ▼ buttons to select the Audio Setup menu: MAIN MENU AUDIO SETUP...
  • Page 39 Operating the 4x1 AV Processor with Amp Using the Menu System Using the IR Remote Control (continued) Example 2: Assigning the analog L/R inputs with the Dolby® Pro Logic II audio processing mode: Starting from Step 5, on the previous page, use the ▼ button to select the analog L/R option: AUDIO SETUP AUD LR...

  • Page 40: Dynamic Range Compression

    Operating the 4x1 AV Processor with Amp Using the Menu System Dynamic Range Compression Dynamic Range Compression (DRC) applies compression to the output signal, preventing the signal from becoming too loud. The default setting for Dynamic Range Compression is OFF. Using the front-panel buttons From the home screen, press the Menu button.
  • Page 41 Operating the 4x1 AV Processor with Amp Using the Menu System Using the IR Remote Control From the home screen, press the MENU button. Use the ▲ or ▼ buttons to navigate to the Audio Setup menu. MAIN MENU AUDIO SETUP Press the ENTER button.

  • Page 42: Audio Enhancement Modes

    Operating the 4x1 AV Processor with Amp Using the Menu System Audio Enhancement Modes The 4x1 AV Processor with Amp provides four distinct audio enhancement modes. Each of these modes provide a different audio listening experience. Available Modes Mode (LCM display) Description NIGHT Increases the volume of quiet passages, while decreasing the...
  • Page 43 Operating the 4x1 AV Processor with Amp Using the Menu System Press the ◄ or ► button to change to change the audio enhancement mode. In the illustration below, the audio enhancement mode has been set to Night mode: AUDIO SETUP ENHA.

  • Page 44: Setting The Unit Of Measurement

    Operating the 4x1 AV Processor with Amp Using the Menu System Setting the Unit of Measurement When adjusting the speaker distance, either feet or meters can be specified. Using the front-panel buttons From the home screen, press the Menu button. Use the Volume ▲ or Volume ▼ buttons to navigate to the Misc Setup menu.
  • Page 45 Operating the 4x1 AV Processor with Amp Using the Menu System Using the IR remote control From the home screen, press the MENU button. Use the ▲ or ▼ buttons to select the Misc Setup menu. MAIN MENU MISC SETUP Press the ENTER button.

  • Page 46: Setting The Edid Mode

    Operating the 4x1 AV Processor with Amp Using the Menu System Setting the EDID Mode The 4x1 AV Processor with Amp has three EDID modes (INT, EXT, and MIX). • INT Mode The internal (local) EDID is used instead of the EDID from the display device. EDID features newer than HDMI 1.3 are removed from the EDID data structure when the display is read.
  • Page 47 Operating the 4x1 AV Processor with Amp Using the Menu System Using the IR Remote Control To set the EDID mode, press the MENU button from the home screen. Use the ▲ or ▼ buttons to navigate to the Misc Setup menu. MAIN MENU MISC SETUP Press the ENTER button.

  • Page 48: Setting The Ir Channel

    Operating the 4x1 AV Processor with Amp Using the Menu System Setting the IR Channel When controlling the 4x1 AV Processor with Amp using the IR Remote Control Unit, the IR channel on the 4x1 AV Processor with Amp must be the same as the IR channel set on the IR Remote Control Unit.

  • Page 49: Resetting To Factory-Default Settings

    Operating the 4x1 AV Processor with Amp Using the Menu System Resetting to Factory-Default Settings If the 4x1 AV Processor with Amp needs to be reset for any reason or if you need to set the unit to factory (default) settings, follow the instructions below. Using the front-panel buttons From the home screen, press the Menu button.
  • Page 50 Operating the 4x1 AV Processor with Amp Using the Menu System Using the IR remote control From the home screen, press the MENU button. Use the ▲ or ▼ buttons to navigate to the Misc Setup menu. MAIN MENU MISC SETUP Press the Mode / OK button.

  • Page 51: Hdcp Setup

    Operating the 4x1 AV Processor with Amp Using the Menu System HDCP Setup The HDCP Setup submenu provides the option to disable HDCP detection on the selected input. Some sources (such as computers) will enable HDCP if an HDCP-compliant display is detected.
  • Page 52 Operating the 4x1 AV Processor with Amp Using the Menu System Using the IR remote control From the home screen, press the MENU button. Use the ▲ or ▼ buttons to navigate to the Misc Setup menu. MAIN MENU MISC SETUP Press the ENTER button.

  • Page 55: 03 Advanced Operation

    AV Processor with Amp 03 Advanced Operation RS-232 Configuration ..................46 RS-232 Interface ..................46 RS-232 Settings ..................46 RS-232 Commands ..................... 47...

  • Page 56: Configuration

    Advanced Operation RS-232 Configuration RS-232 Interface DE-9 DA-15 RS-232 Controller AV Processor DB-25 Only TXD, RXD, and GND pins are used. DC-37 RS-232 Settings Description Setting 19200 Baud rate DD-50 Data bits None Parity Stop bits None Hardware flow control IMPORTANT: When sending RS-232 commands, a carriage return must be included at the end of the command.

  • Page 57: Commands

    Advanced Operation RS-232 Commands Command Description AUDIO Selects between S/PDIF, TOSLink, or Analog audio input BASS Increases or decreases the bass Sets the size of the Center speaker Sets the distance for the Center speaker Sets the distance for the Front Left speaker DFLT Sets the 4x1 AV Processor with Amp to factory (default) settings Sets the distance for the Front Right speaker...
  • Page 58 Advanced Operation RS-232 Commands AUDIO The AUDIO command selects between S/PDIF, TOSLINK, or analog audio inputs. The currently selected video input is unaffected. Syntax: AUDIO param1 Parameters: Value [0 ... 3] param1 Value Description HDMI S/PDIF (coax) TOSLINK (optical) Analog L/R To return the current audio input, use the following command syntax: AUDIO ? Note:...
  • Page 59 Advanced Operation RS-232 Commands BASS The BASS command sets the bass level. Syntax: BASS param1 Parameters: param1 Value (dB) [-12 ... 12] To return the current audio input, use the following command syntax: BASS ? Note: The + or - character can also be used, instead of specifying a value, in order to increase or decrease the bass level by 1 dB.
  • Page 60 Advanced Operation RS-232 Commands The CT command sets the size of the Center speaker. Syntax: CT param1 Parameters: param1 Value [0 ... 2] Value Description Small Large Off (disable Center speaker) To return the current size setting for the Center speaker, use the following command syntax: CT ? Examples:...
  • Page 61 Advanced Operation RS-232 Commands The DC command sets the distance of the Center speaker. Syntax: DC param1 Parameters: param1 Distance (feet) [0 ... 20] To return the current distance setting of the Center speaker, use the following command syntax: DC ? Examples: DC 5 >...
  • Page 62 Advanced Operation RS-232 Commands The DFL command sets the distance of the Front Left speaker. Syntax: DFL param1 Parameters: param1 Distance (feet) [0 ... 20] To return the current distance setting of the Front Left speaker, use the following command syntax: DFL ? Examples: DFL 10...
  • Page 63 Advanced Operation RS-232 Commands DFLT The DFLT command sets the 4x1 AV Processor with Amp to the factory-default settings. Syntax: DFLT 1 Parameters: The value of 1 must be specified as part of this command. No return value is available. Example: DFLT 1 >...
  • Page 64 Advanced Operation RS-232 Commands The DFR command sets the distance of the Front Right speaker. Syntax: DFR param1 Parameters: param1 Distance (feet) [0 ... 20] To return the current distance setting of the Front Right speaker, use the following command syntax: DFR ? Examples: DFR 10...
  • Page 65 Advanced Operation RS-232 Commands The DRC command enables / disables Dynamic Range Control. Syntax: DRC param1 Parameters: param1 Value [0 ... 1] Value Description DRC Off DRC On To return the current DRC state, use the following command syntax: DRC ? Example: DRC 0 >...
  • Page 66 Advanced Operation RS-232 Commands The DSB command sets the distance of the Subwoofer. Syntax: DSB param1 Parameters: param1 Distance (feet) [0 ... 20] To return the current distance setting of the Subwoofer, use the following command syntax: DSB ? Examples: DSB 6 >...
  • Page 67 Advanced Operation RS-232 Commands The DSL command set the distance of the Surround Left speaker. Syntax: DSL param1 Parameters: param1 Distance (feet) [0 ... 20] To return the current distance setting of the Surround Left speaker, use the following command syntax: DSL ? Examples: DSL 2...
  • Page 68 Advanced Operation RS-232 Commands The DSR command set the distance of the Surround Right speaker. Syntax: DSR param1 Parameters: param1 Distance (feet) [0 ... 20] To return the current distance setting of the Surround Right speaker, use the following command syntax: DSR ? Examples: DSR 2...
  • Page 69 Advanced Operation RS-232 Commands EDID The EDID command sets the EDID mode. The 4x1 AV Processor with Amp will automatically power-cycle after the command has been executed. Syntax: EDID param1 Parameters: Mode [0 ... 2] param1 Value Description EDID Mix Internal EDID External EDID To return the current distance setting of the Surround Right speaker, use the following...
  • Page 70 Advanced Operation RS-232 Commands The ENH command set the audio enhancement mode. See Audio Enhancement Modes more information on this feature. Syntax: ENH param1 Parameters: Mode [0 ... 3] param1 Value Description Night Mode Voice Mode Volume Mode To return the current audio enhancement mode setting, use the following command syntax: ENH ? Examples: ENH 3...
  • Page 71 Advanced Operation RS-232 Commands The FLR command sets the size of the Front Left / Front Right speakers. Syntax: FLR param1 Parameters: param1 Value [0 ... 1] Value Description Small Large To return the current size setting for the Front Left / Front Right speakers, use the following command syntax: FLR ? Examples:...
  • Page 72 Advanced Operation RS-232 Commands HDMI The HDMI command sets the active HDMI input. This command does not affect the current audio input. Syntax: HDMI param1 Parameters: Value [1 ... 4] param1 Value Description HDMI In 1 HDMI In 2 HDMI In 3 HDMI In 4 To return the current video input, use the following command syntax: HDMI ?
  • Page 73 Advanced Operation RS-232 Commands HELP The HELP command displays a list of the available RS-232 commands. Syntax: HELP ? Parameters: The ? character must be specified as part of this command. Example: HELP ? > COMMAND LIST :PWR AUDIO BASS DFLT EDID HDMI...
  • Page 74 Advanced Operation RS-232 Commands INFO The INFO command returns the current hardware and firmware version. Syntax: INFO ? Parameters: The ? character must be specified as part of this command. Example: INFO ? > FW 2.1D page | 64...
  • Page 75 Advanced Operation RS-232 Commands INTYPE The INTYPE command returns the current audio input format. Syntax: INTYPE ? Parameters: The ? character must be specified as part of this command. Return values: Value Description None (no signal) Linear PCM 2.1 Linear PCM 5.1 Dolby®...
  • Page 76 Advanced Operation RS-232 Commands The IR command sets the IR channel for the 4x1 AV Processor with Amp. Syntax: IR param1 Parameters: param1 Value [0 ... 3] Value Description IR channel 1 IR channel 2 IR channel 3 IR channel 4 To return the current IR channel, use the following command syntax: IR ? Examples:...
  • Page 77 Advanced Operation RS-232 Commands The MD command sets the audio mode. See Setting the Audio Processing Mode for more information on this feature. Syntax: MD param1 Parameters: Value [0 ... 4] param1 Value Description Dolby® Pro Logic Surround Direct Input Downmix to Stereo L/R Multichannel Surround Downmix to Mono...
  • Page 78 Advanced Operation RS-232 Commands MUTE The MUTE command mutes / un-mutes the audio output. This command also Syntax: MUTE param1 Parameters: param1 Value [0 ... 2] Value Description Disable muting Enabling muting Mute toggle (from previous state) To return the current muting state, use the following command syntax: MUTE ? Examples: MUTE 1...
  • Page 79 Advanced Operation RS-232 Commands The PWR command is used to power-on or place the 4x1 AV Processor with Amp in standby mode. Syntax: PWR param1 Parameters: Value [0 ... 2] param1 Value Description Standby mode Power On Toggle power (from previous state) To return the current power state, use the following command syntax: PWR ? Note:...
  • Page 80 Advanced Operation RS-232 Commands The SLR command sets the size of the Surround Left / Surround Right speakers. Syntax: SLR param1 Parameters: param1 Value [0 ... 2] Value Description Small Large Off (disable Surround speakers) To return the current size setting for the Surround Left / Surround Right speakers, use the following command syntax: SLR ? Examples:...
  • Page 81 Advanced Operation RS-232 Commands STAT The STAT command enables / disables the feedback when using RS-232 commands. Syntax: STAT param1 Parameters: param1 Value [0 ... 1] Value Description Disable feedback Enable feedback To return the current feedback state, use the following command syntax: STAT ? Examples: STAT 0...
  • Page 82 Advanced Operation RS-232 Commands The SUB command enables / disables the Subwoofer. Syntax: SUB param1 Parameters: param1 Value [0 ... 1] Value Description Disable Subwoofer Enable Subwoofer To return the current state of the Subwoofer, use the following command syntax: SUB ? Examples: SUB 0...
  • Page 83 Advanced Operation RS-232 Commands SUBV The SUBV command sets the audio gain of the Subwoofer. Syntax: SUBV param1 Parameters: param1 Value (dB) [-12 ... 12] To return the current audio gain of the Subwoofer, use the following command syntax: SUBV ? Examples: SUBV 4 >...
  • Page 84 Advanced Operation RS-232 Commands TEST The TEST command sends a test tone to the specified speaker. Only one speaker can play the test tone at a time. Syntax: TEST param1 Parameters: Value [0 ... 6] param1 Value Description Front Left Center Front Right Surround Right...
  • Page 85 Advanced Operation RS-232 Commands TREB The BASS command sets the treble level. Syntax: TREB param1 Parameters: param1 Value [-12 ... 12] To return the current audio input, use the following command syntax: TREB ? Note: The + or - character can also be used, instead of specifying a value, in order to increase or decrease the treble level by 1.
  • Page 86 Advanced Operation RS-232 Commands TVTYPE The TVTYPE command sets the video broadcast format. Syntax: TVTYPE param1 Parameters: param1 Value [0 ... 1] Value Description NTSC To return the current format setting, use the following command syntax: TVTYPE ? Examples: TVTYPE 0 >...
  • Page 87 Advanced Operation RS-232 Commands The VOL command sets the audio output volume. Syntax: VOL param1 Parameters: param1 Value (dB) [-60 ... 12] To return the current volume setting, use the following command syntax: VOL ? Note: The + or - character can also be used, instead of specifying a value, in order to increase or decrease the volume level by 1 dB.

  • Page 89: 04 Appendix

    AV Processor with Amp 04 Appendix Menu System Layout................... 80 Main Menu ....................80 Speaker Size Menu ..................82 Speaker Level Menu ................... 83 Speaker Distance Menu ................85 Tone Control Menu ..................87 Audio Setup Menu ..................88 Misc Setup Menu ..................90 Specifications ......................

  • Page 90: Menu System Layout

    Appendix Menu System Layout Main Menu H1 HD -01db None direct Menu ▲ MAIN MENU SPEAKER size ▲ Exit ▲ MAIN MENU SPEAKER LEVEL ▲ Exit ▲ MAIN MENU SPEAKER DISTANCE ▲ Exit ▲ MAIN MENU TONE CONTROL ▲ Exit ▲...
  • Page 91 Appendix Menu System Layout Exit ▲ main menu misc ▲ Exit ▲ main menu EXIT Exit ▲ page | 81...

  • Page 92: Speaker Size Menu

    Appendix Menu System Layout Speaker Size Menu MAIN MENU SPEAKER SIZE Mode / OK ▲ SPEAKER SIZE FRONT L/R(SMALL) ▲ Exit ▲ SPEAKER SIZE CENTER (SMALL) ▲ Exit ▲ SPEAKER SIZE SURR L/R (SMALL) ▲ Exit ▲ SPEAKER SIZE (ONSUB) ▲...

  • Page 93: Speaker Level Menu

    Appendix Menu System Layout Speaker Level Menu MAIN MENU SPEAKER LEVEL Mode / OK ▲ SPEAKER LEVEL FRONT L (+00db) ▲ Exit ▲ SPEAKER LEVEL CENTER (+00db) ▲ Exit ▲ SPEAKER LEVEL Front R (+00db) ▲ Exit ▲ SPEAKER LEVEL SURR R (+00db) ▲...
  • Page 94 Appendix Menu System Layout Exit ▲ SPEAKER LEVEL (+10db) ▲ Exit ▲ SPEAKER LEVEL EXIT Exit ▲ page | 84...

  • Page 95: Speaker Distance Menu

    Appendix Menu System Layout Speaker Distance Menu MAIN MENU SPEAKER DISTANCE Mode / OK ▲ SPEAKER DISTANCE FRONT L (03.0m) ▲ Exit ▲ SPEAKER DISTANCE CENTER (02.0M) ▲ Exit ▲ SPEAKER DISTANCE Front R (03.0m) ▲ Exit ▲ SPEAKER DISTANCE SURR R (02.0m) ▲...
  • Page 96 Appendix Menu System Layout Exit ▲ SPEAKER DISTANCE (03.0m) ▲ Exit ▲ SPEAKER DISTANCE EXIT Exit ▲ page | 86...

  • Page 97: Tone Control Menu

    Appendix Menu System Layout Tone Control Menu MAIN MENU TONE CONTROL Mode / OK ▲ TONE CONTROL BASS (+05db) ▲ Exit ▲ TONE CONTROL TREBLE (+00db) ▲ Exit ▲ TONE CONTROL EXIT Exit ▲ page | 87...

  • Page 98: Audio Setup Menu

    Appendix Menu System Layout Audio Setup Menu MAIN MENU AUDIO SETUP Mode / OK ▲ AUDIO SETUP COAXIAL FAV PROC ▲ Exit ▲ AUDIO SETUP OPTICAL FAV PROC ▲ Exit ▲ AUDIO SETUP AUD LR FAV PROC ▲ Exit ▲ AUDIO SETUP HDMI 1 FAV PROC...
  • Page 99 Appendix Menu System Layout Exit ▲ AUDIO SETUP HDMI 3 FAV PROC ▲ Exit ▲ AUDIO SETUP HDMI 4 FAV PROC ▲ Exit ▲ AUDIO SETUP ( OFF ) ▲ Exit ▲ AUDIO SETUP ENHA. ( NIGHT+) ▲ Exit ▲ AUDIO SETUP EXIT Exit...

  • Page 100: Misc Setup Menu

    Appendix Menu System Layout Misc Setup Menu MAIN MENU MISC SETUP Mode / OK ▲ MISC SETUP DIST.UNIT(METER) ▲ Exit ▲ MISC SETUP EDID ADJ.(INT) ▲ Exit ▲ MISC SETUP IR ChANNEL ( 1 ) ▲ Exit ▲ MISC SETUP Factory Default ▲...
  • Page 101 Appendix Menu System Layout Exit ▲ MISC SETUP EXIT Exit ▲ page | 91...

  • Page 102: Specifications

    Appendix Specifications Supported Formats Audio (5.1 channels max.) • Dolby® Digital • Dolby® Pro Logic • Dolby® Pro Logic II • LPCM Electrical Maximum Pixel Clock • 225 MHz Power Amplifier Channels • Connectors Video Inputs • 4 x HDMI Type A, 19-pin, female Video Output •...
  • Page 103 Appendix Specifications Physical Dimensions (W x H x D) • 14.75” x 2.5” x 6.9” (375mm x 64mm x 175mm) Unit Weight • 6 lbs page | 93...
