JBL HLS Center Technical Manual

Technical Manual
HLS Center
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency
SYSTEM COMPONENTS:
• Cabinet
• Grille
• Low Frequency Transducer* (2) 5 1/4" Polypropylene,
DC Resistance
• High Frequency Transducer*10mm Polycarbonate Dome
PACKAGING
End Pad (Left)
332728-001
Microfoam (2 pcs.)
Outer Carton
332730-001
JBL Consumer Products, Inc. 250 Crossways Park Dr., Woodbury, New York 11797
8 ohms
150 watts
80Hz - 20kHz (+3dB)
88 dB (1 watt @ 1 meter)
2800 Hz
HLS CENTER (Not for Sale)
332727-001
Shielded (332649-001)
3.8 ohms ±10%
(TW010B17/101829B)
Owner's Manual
332661-001
Warranty Card
331994-001
Survey Card
331384-001
End Pad (Right)
332728-001
SYSTEM COMPONENTS: (cont.)
DC Resistance
• Crossover Network
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
• Enclosure dimensions:
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.

WIRING DIAGRAM

High Frequency*
TW010B17/101829B
YEL
Low Frequency*
332649-001
– +
GRN/BLK
WHITE/BLK
WHITE
HLS CENTER SCHEMATIC
L1
1.22 mH
+IN
INPUT
0.64 mH
–IN
C3
2.7 uF
50V
5.5 ohms ±10%
332731-001
6.0V Input 80 Hz to 20 kHz
6.0V Input 70 Hz to 3 kHz
2.83V Input 2 kHz to 20 kHz
20 3/8 x 7 1/16 x 6 1/2"
(H x W x D) 518 x 179 x 165mm
15 lbs. (6.8kg) Each
Network
332731-001
YEL/BLK
– +
GRN
16" GREEN
C1
16" GREEN/BLK
10 mfd
50V
L2
16" WHITE
C2
15 uF, 50V
16" WHITE/BLK
9" YELLOW
L3
0.21mH
9" YELLOW/BLK
+
.250
.205
L.F.
.250 +
.205
+
.187
H.F.
.110
3-99
