Yaesu MD-200A8X Technical Supplement

D D
ESKTOP
MD-200
Technical Supplement
©2001 VERTEX STANDARD CO., LTD. Printed in Japan.
Introduction
The Desktop Microphone is designed for base station op-
eration with the latest generation of Yaesu HF transceivers, includ-
ing those with VHF/UHF capability. Designed especially for ultra-
low distortion and the highest fidelity, the
technology "Variable Side Pressure Control" (VSPC), which allows
precise adjustment of the microphone's audio response without re-
sorting to "active" equalization circuits that can introduce distortion
and/or degrade signal-to-noise ratio.
Servicing this equipment requires expertise in handling surface mount
chip components. Attempts by unqualified persons to service this
equipment may result in permanent damage not covered by war-
ranty.
While we believe the technical information in this manual is correct,
VERTEX STA N D A R D assumes no liability for damage that may oc-
cur as a result of typographical or other errors that may be present.
Your cooperation in pointing out any inconsistencies in the technical
information would be appreciated.
VERTEX STA N D A R D reserves the right to make changes in this trans-
ceiver and the alignment procedures, in the interest of technological
improvement, without notification of owners.

Specifications

Microphone Element Type: Dynamic
Frequency Range:
Sensitivity:
Impedance:
Dimensions (WHD):
Weight:
Specifications are subject to change without notice or obligation.
M
YNAMIC ICROPHONE
A8X
30 - 17000 Hz
–62 dB (1 kHz, 0 dB = 1 V/1 pa)
600 Ohms
4.7" x 11.4" x 4.9"
(120 x 290.5 x 124.5 mm)
Approx. 2.2 lb. (1 kg.)
