ikross IKBT11 User Manual

Bluetooth speakerphone hands-free car kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

IKBT11 Bluetooth Speakerphone
Brief introduction........................................................1
2. About IKBT11..........................................................1
Before use..................................................................2
1. Overview...................................................................2
2. Charging the battery of IKBT11.....................................2
Using the hands-free kit................................................3
1. Switching on/off IKBT11.............................................3
3. Installation.................................................................5
4. Making calls with IKBT11...........................................6
5. Re-connecting with a Bluetooth device................................7
6. Automatic switching off................................................8
7. LED indicator and indication tone.....................................8
Care and maintenance.................................................8
FAQs.......................................................................9
Specifications............................................................9
User's manual
Hands-Free Car kit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IKBT11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ikross IKBT11

Summary of Contents for ikross IKBT11

  • Page 1: Table Of Contents

    1. Overview……………………………………………………..…2 2. Charging the battery of IKBT11……………………………….2 Using the hands-free kit……………………………..………….3 1. Switching on/off IKBT11……..…………………………….…3 2. Pairing IKBT11 with a Bluetooth cell phone………..……...…4 3. Installation………………………………………………..……...5 4. Making calls with IKBT11………………………………….…6 5. Re-connecting with a Bluetooth device…….………………..…..7 6. Automatic switching off…………………………………………8 7.

  • Page 2: Brief Introduction

    Welcome to use this Bluetooth hands-free kit, IKBT11. Please read this user’s manual carefully before use. Brief introduction 1. Bluetooth wireless communication technology Bluetooth is a standard of close range radio-communication technology that was drawn up by Ericsson, IBM, Intel, Nokia and Toshiba. With Bluetooth technology, we can achieve the highest transmission rate among cell phones, computers, printers, PDAs and other devices.

  • Page 3: Before Use

    Charging port Magnet Clip 2. Charging the battery of IKBT11 First use—you must charge its rechargeable battery fully before first use. Low power—when you hear three “Dong” tones every 10 seconds or see the red LED flashing twice, the battery is low power and needs to be charged.

  • Page 4: Using The Hands-Free Kit

    When charging has completed, the red LED will switch off. Remarks: 1) The battery will dry up if you don’t use IKBT11 for a long time. If this happens you have to charge IKBT11 for about 30 minutes before the LED indicator will be on.

  • Page 5: Pairing Ikbt11 With A Bluetooth Cell Phone

    LEDs flash alternately Remark: Pairing mode will last 2 minutes. IKBT11 will switch to standby mode automatically if it can’t be connected to any device after 2 minutes. If you want to continue pairing IKBT11 with a Bluetooth device, please switch off IKBT11 first and enter pairing mode again.

  • Page 6: Installation

    You can use IKBT11 in your car, at home or in an office environment. a) In-car usage First attach the metal clip to the sun visor and stick IKBT11 to the clip using the magnet. At last, adjust the angle of IKBT11 to align the microphone towards the user’s mouth to get the best conversation quality.
  • Page 7 Continuous short There are press button indication tones twice. When Mute the During a call microphone is microphone mute, IKBT11 will sound 2 tones every 5 seconds During a call Continuous short There are Cancel (microphone press button indication tones...

  • Page 8: Re-Connecting With A Bluetooth Device

    5. Re-connecting with a Bluetooth device 1) Automatic connecting Every time IKBT11 is switched on, it will connect to the last connected device automatically. 2) Connecting manually When IKBT11 gets disconnect from the Bluetooth device, short press button once, it will connect to the last connected device again.

  • Page 9: Led Indicator And Indication Tone

    Care and maintenance Read the following recommendations before using IKBT11. Following these you will be able to enjoy our product for many years. Keep it dry and don’t put it in the damp place to avoid the product’s internal circuit being affected.

  • Page 10: Faqs

    Ensure the volume has already been properly adjusted. 2. What to do when my cell phone can’t find IKBT11? If IKBT11 is not in paring mode, your cell phone can’t find it. Please ensure IKBT11 is in pairing mode and in the effective working range.
  • Page 11 Charging time Approx. 2.5 hours Working temperature -10～45℃ Storage temperature -20~60℃ Dimensions 90×47×17mm Weight Note: 1. Operation is subject to the following two conditions: (1) This Bluetooth hands-free kit may not cause harmful interference, and (2) it must accept any interference received, including interference that may cause undesired operation.

Table of Contents
