Bosch VDC?480 Series Specifications

CCTV | VDC‑480 Series Dome Cameras FlexiDome XF Indoor
VDC‑480 Series Dome Cameras
FlexiDome XF Indoor
XF
The FlexiDome Indoor series are the ultimate solutions for
virtually any indoor surveillance application. These units
contain full-featured color cameras, with a 1/3-inch CCD
and integral varifocal lenses.
Installation is quick and easy, since the cameras come
completely assembled and ready to use. Using the
proprietary pan/tilt/rotation mechanism, installers can
select the exact field of view. Mounting options are
numerous, including surface, 4S (USA), wall, corner, and
suspended ceiling.
The VDC-480 series dome cameras are an ideal solution for
many surveillance applications, especially where
backlighting may be a concern. Their compact, sleek design
and virtually flush-mount appearance will complement any
decor.
Functions
Technology
The VDC-480 series incorporates the latest technology
adopted from the high-performance Dinion
cameras. This technology ensures the highest possible
image quality at all times and under all conditions. Based
on a unique combination of 15-bit digital video processing
and XF-dynamic, these cameras provide excellent
▶ Indoor polycarbonate dome
▶ XF-Dynamic for wide dynamic range
▶ NightSense
▶ 15-bit DSP technology
▶ 540 TVL color resolution
▶ SensUp 10 x extended sensitivity
▶ Bilinx bi-directional communication
▶ Patented dome shape for 90º vertical view
sensitivity, with up to 32 x extended dynamic range. This
delivers a sharper, more detailed image with outstanding
accuracy in color reproduction.
Operation
All cameras feature video motion detection, auto black,
default shutter, and back light compensation for optimum
performance in all lighting conditions. The lens wizard and
focus aid make lens adjustment easy and straightforward,
and ensure proper focus throughout the 24-hour cycle. All
cameras incorporate Bilinx, a technology that allows
technicians to set up, control the camera settings, and even
update firmware remotely over the video cable.
Controls and Indicators
•
•
Interconnections
•
•
Certifications and Approvals
XF
Color
Region
Europe
USA
OSD
5-key operation
Video connection BNC on flying lead
Power connection on flying leads
Certification
CE Declaration of Conformity
FCC Declaration of Conformity
