MMA
™
SERIES
MODULE AUX
Auxiliary Preamp Input
Module With Muting
SPECIFICATIONS
INSTALLATION:
The module installs at the rear panel of products
accepting the standard 6-pin card-edge module
connection. Align card-edge connector with top and
bottom circuit board guides. Snap module into card-
edge socket, push flush with rear panel and install
(furnished) mounting screws.
Gain:
Input Sensitivity:
Frequency Response:
E
C
I
F
2
™
0 to -60 dB
100 mV to 6.3 V
(-17.8 dBu to 14 dBu)
20 Hz to 20 kHz ±0.5 dB
I
C
A
T
S/N Ratio:
Muting Level:
Power:
Control:
Mounting:
Weight:
Dimensions:
Load Impedance:
I
O
N
Controls overall
output level of
the module
RCA phono input
jacks
Screw terminal
input panel
90 dB
60 dB
+24 V DC
Gain
Edge card connector
2.5 oz
3.07" H x 1.38" W x 3.70" D
10k ohm
ARCHITECTURAL ACOUSTICS
