  • Page 1 User Manual www.samsung.com...

  • Page 2: About This Manual

    For the latest version of the • P lease read this manual before using the computer to ensure manual, refer to the Samsung website, www.samsung.com . safe and proper use. • O ptional items, some devices and software referred to in the user manual may not be provided or subject to upgrades.
  • Page 3 About this manual Instructional icons and Copyright expressions © 2013 Samsung Electronics Co., Ltd. This manual is protected under international copyright laws. Warning: situations that could cause injury to yourself or No part of this manual may be reproduced, distributed, translated,...
  • Page 4 Trademarks HDMI, the HDMI logo, and the term High Definition Multimedia Interface are trademarks or • S amsung and the Samsung logo are trademarks or registered registered trademarks of HDMI trademarks of Samsung Electronics. Licensing LLC. • I ntel and Core are trademarks or registered trademarks of the Intel Corporation.

  • Page 5: Operating System And Software

    About this manual Caution for the data Product capacity representation Samsung Electronics shall not be liable for any data loss. Please Storage capacity representation take care to avoid losing any important data and back up your data to prevent any such data loss.

  • Page 6: Table Of Contents

    Wireless LAN Memory card 130 Regulatory compliance The Charms Mobile broadband External display statements Applications (Wireless WAN, optional) Slim security slot 147 WEEE symbol information Microsoft account 149 Samsung package Take- Store Back program 150 TCO certified (for corresponding models only)

  • Page 7: Getting Started

    Getting started Number/Name Description • T akes photos or videos. • U se the camera application on Camera the Start screen to take photos or Layout videos. • T his sensor detects the ambient • F eatures or options may differ depending on the model. illumination of the computer.
  • Page 8 Getting started Number/Name Description • P ress to turn the computer on. Power button • M ove the cursor and click options. Touchpad • W orks actions as those of a mouse. • P ress keys to enter data. Keyboard Microphone •...
  • Page 9 Getting started Operating indicator light Number/Name Description • T urns on when the computer is Power LED turned on. • S hows the battery’s charging status. – Red or Orange: While charging is in progress – Green: When charging is Charge status complete or the battery is not installed...

  • Page 10: Right View

    Getting started Right view Number/Name Description • C onnect external display devices that support a 15-pin analog connector. Monitor port • Y ou can connect a VGA adapter (optional). Ear-set/Headset • C onnect a headset or ear-set. jack •...

  • Page 11: Left View

    Getting started Left view Number/Name Description • C onnect the AC adapter to supply DC jack the power to the computer. Chargeable USB 3.0 port (optional) • C onnect and charge a USB device. • C onnect external display devices Micro HDMI port that support HDMI.
  • Page 12 Getting started About the chargeable USB port • I t may take longer to charge the battery when charging a USB device. • T he battery power level may be reduced when charging a USB device while the computer is powered by the battery. •...

  • Page 13: Bottom View

    • E mits sound from the computer. Speaker After replacing the bottom of the computer, the model name, serial number and some logos on will no longer be present. For more information, contact the Samsung Service Center to request assistance.

  • Page 14: Charging The Battery

    Charge the battery before using it for the first time. Use the AC adapter to charge the battery. • U se only Samsung-approved AC adapters, batteries, and cables. Unapproved adapters or cables can cause the battery to explode or damage the computer.
  • Page 15 The battery is not user-serviceable or user-replaceable. • T o have battery removed or replaced safely, take the device to a Samsung Service Center. You will be charged for this service. • Y ou can use the computer while it is charging, but the battery charging time may increase.

  • Page 16: Battery Status

    Getting started Battery status Battery usage time Move the cursor over the battery icon on the taskbar to view the Batteries are replacement items and over time the battery’s current battery charge when disconnecting the AC adapter from capacity to hold a charge and its power level is reduced. If a the computer.

  • Page 17: Turning The Computer On And Off

    Getting started Turning the computer on and off Press the Power button. The Power LED turns on. Turning on Before turning on the computer, charge the battery. Open the LCD panel. Activate Windows by following the on-screen instructions. The Windows activation screen appears only when turning on the computer for the first time.
  • Page 18 Getting started • S ave all the data before turning off the computer. Turning off • S ince the procedures to turn the computer off may differ depending on the installed operating system, To open the Charms, do one of the following: please turn the computer off according to the •...

  • Page 19: Unlocking The Screen

    Getting started Unlocking the screen Turning off on the desktop To select the Start button, do one of the following: To unlock the lock screen, do one of the following: • T ouch screen: Swipe the lock screen from bottom to top. •...

  • Page 20: Windows

    Windows Help To access the help, do one of the following: • K eyboard: Press the F1 key. • T ouch screen: Swipe inward from the right edge of the touch About Windows screen to open the Charms and select the Settings charm → Help.
  • Page 21 Windows Help+Tips You can control Windows menus with the mouse or with gestures. On the Start screen, select Help+Tips. Start...
  • Page 22 Windows Screens in Windows 8.1 The following two screens are provided: the Start screen and the desktop. Start 10:00 AM 1/1/2014 Start screen Desktop...

  • Page 23: Start Screen

    Windows Start screen Number/Name Description • O pens the Charms that are hidden at Launch applications on the Start screen. When the computer is the right of the screen. turned on, the Start screen is displayed first. • T o open the Charms, do one of the following: Open the Start...
  • Page 24 Windows Number/Name Description • T he Start button can be accessed only with the mouse. Move the cursor to the lower-left edge of the screen to view the Start button ( ). Click the button to switch to the most recent Start button application screen or the desktop.

  • Page 25: Desktop

    Windows Desktop Number/Name Description • O pens the Charms that are hidden at The desktop provides a layout that is similar to earlier versions of the right of the screen. Windows. • T o open the Charms, do one of the On the Start screen, select Desktop from the tiles.
  • Page 26 Windows Using the Start button Number Name Touch and hold or right-click the Start button ( ) to quickly and • C ontrol Panel conveniently access various features of Windows. • F ile Explorer • P ower menu •...

  • Page 27: The Charms

    Windows The Charms • K eyboard: Hold down the Windows key ( ) and press the C key. The Charms let you search, share links and photos, connect devices, and change settings. The Charms functions available may differ between the Start screen and the desktop or applications. Opening the Charms •...
  • Page 28 Windows Learning about the Charms • T ouch screen: Swipe inward from the right edge of the touch screen. Use the following Charms to control the computer: Start Start Charm Description • S earch for applications, files, or Search websites by entering keywords.
  • Page 29 Windows Settings charm To configure the computer, open the Charms and then select the Settings charm → an option. Option Description • C onnect the computer to a Network network to use the Internet or share files with other devices. •...

  • Page 30: Applications

    Windows Applications Closing an application Running multiple applications at the same time can slow down the performance of some applications or consume the battery Opening or closing applications power fast. Close applications not in use to save battery power and maintain performance. On the Start screen, select an application icon to open it.
  • Page 31 Windows App tiles Opening recent applications On the Start screen, place the cursor in the upper-left corner Tile position of the screen until a small application image appears. To change the position of an app tile on the Start screen, select Swipe from the left edge of the touchpad or screen towards and hold the tile and then drag it to a new position.
  • Page 32 Windows Grouping tiles Naming a group To group tiles, select and hold a tile and drag it to an open space. To open menu items, do one of the following: Then, drag other tiles to the new group. • T ouch screen: On the Start screen, swipe upwards from the bottom edge of the touch screen.
  • Page 33 Windows Using split screens Drag the Screen Split Bar to change the screen split ratio. Weather app On the Start screen, select an application. Screen Split Bar Store app To enter the split mode, do one of the following: • T ouch screen: Put your finger on the top edge of the screen, and swipe to the left or right.
  • Page 34 Windows Adding or removing an application on the Using the camera application Start screen Use the camera application provided by Windows to take photos or videos or edit photos. To move to the applications screen, do one of the following: On the Start screen, select Camera ( ).
  • Page 35 Windows Viewing photos or videos Editing photos To view photos or videos, do one of the following: Select a photo. • T ouch screen: Swipe from the left edge of the screen to the right. Swipe downward or upward from the edges of the screen. •...

  • Page 36: Microsoft Account

    Windows Microsoft account Store Some Microsoft services, such as the Store, require a Microsoft Purchase and download applications for the computer. Create a account. Create a Microsoft account to get the most from the Microsoft account to use this feature. See Microsoft account. computer.

  • Page 37: Basics

    Basics • T o open the most-recently used application, swipe from the left edge of the touch screen to the middle. Start Touch screen Only use fingers to use the touch screen. Touch screen gestures • T o bring up the app commands, swipe downwards from the Swiping top edge of the touch screen or swipe upwards from the •...

  • Page 38: Touch Screen

    Basics • T o view all installed applications, swipe upwards on the Start • T o close an application, swipe downward from the top edge screen. to the bottom edge of the touch screen. Start • T o switch from the applications screen to the Start screen, swipe downward on the applications screen.

  • Page 39: Keyboard

    Basics • T o scroll up, down, left or right, swipe with two fingers on the Double-tapping touch screen. To zoom in a part or double-click an item, double-tap on the touch screen. Tapping Tapping and holding To open an application, select a menu item, press an on-screen To perform the right-clicking function, tap and hold an item on button, or enter a character using the on-screen keyboard, tap it the touch screen.

  • Page 40: Touch Screen

    Basics Dragging Pinching To move an icon, app tile, or preview to a new location, touch and To zoom in, spread two fingers apart on a website, map, or image. hold it, and then drag it to the target position on the touch screen. Pinch to zoom out.

  • Page 41: Touch Screen

    Basics • D o not apply a severe impact to the touch screen or • L eaving the touch screen idle for extended periods press it with a sharp object. Doing so may damage the may result in afterimages (screen burn-in) or ghosting. touch screen.

  • Page 42: Calibrating The Screen

    Basics Calibrating the screen On the desktop, open the Charms and then select the Settings charm → Control Panel → Hardware and Sound → Calibrate the touch settings to make the screen sense accurately Tablet PC Settings → Calibrate..when using a finger. This feature may differ or may not be available depending on the operating system.

  • Page 43: Keyboard

    Basics Entering text Select Yes when a pop-up appears. Use the virtual keyboard to enter text. Touch on the calibration screen. • T ext entry is not supported in some languages. To enter text, change the input language to one of the supported languages.

  • Page 44: Keyboard

    Basics Changing the keyboard layout Number Description • D elete a preceding character. To change the keyboard layout, touch and select one of the following: • B reak to the next line. • : Simplified Qwerty keyboard. • E nter uppercase. For all caps, press and hold it. •...

  • Page 45: Keyboard

    Basics Entering uppercase Copying and pasting Touch before entering a character. For all caps, touch it twice. Touch and drag your finger across the text to select it. Changing language keyboards Touch and hold the text to open the options pop-up. Add keyboards to enter text in other languages.

  • Page 46: Keyboard

    Basics Keyboard Enter text or access computer functions with the keyboard. • I mages and available features may differ depending on the model and operating system. • T he keyboard layout may differ depending on the country. Using hot keys •...

  • Page 47: Touchpad

    Basics Hot key functions Key/Icon Description Key/Icon Description • V olume Control: Adjust the volume level. • S ettings: Launch the Settings application. • K eyboard backlight control: Adjust the • S creen brightness control: Adjust the keyboard backlight brightness.

  • Page 48: Windows Hot Keys

    Basics Windows hot keys Use hot keys to access functions conveniently in Windows. Press the Windows key ( ) or the Alt key, and a hot key simultaneously. Description • S witch to the Start screen or the Windows key ( ) most recent application.

  • Page 49: Touchpad

    Basics Touchpad Clicking function Tap the touchpad or press the left touchpad button. Use the touchpad to move the cursor or select an item. The left and right buttons of the touchpad act the same as the left and right buttons of a mouse. •...

  • Page 50: Touchpad

    Basics Gesture functions Right-clicking function To right-click an item, press the right touchpad button. Swiping • T o open the Charms, swipe from the right edge of the touchpad to the middle. Click Dragging function To move an icon or an app tile to a desired location, press and hold •...

  • Page 51: Touchpad

    Basics • T o scroll up, down, left or right, swipe with two fingers on the Pinching touchpad. To zoom in, spread two fingers apart on a website, map, or image. Pinch to zoom out.

  • Page 52: Touchpad

    Basics Configuring touchpad gestures Touchpad lock Hold down the Fn key and press the F5 key. You can lock the Configure touchpad gestures to use the touchpad more efficiently. touchpad. On the desktop, open the Charms and then select the Settings charm →...

  • Page 53: Lcd Brightness

    Basics LCD brightness Controlling with Charms Open the Charms, select the Settings charm → , and drag the Adjust the LCD brightness to reduce eye strain and save power. slider. Controlling with keyboard • T o dim the LCD screen, hold down the Fn key and press the F2 key.
  • Page 54 Basics Changing display mode Set the optimal conditions for the screen, based on the activity. On the Start screen, select Select Settings. Select Display → Display Color → an option. • S tandard: Appropriate for normal environments and convenient for most situations. •...

  • Page 55: Volume

    Basics Volume • T o mute or unmute the volume, hold down the Fn key and press the F6 key. Adjust the system volume or sound volume when playing music or video. Controlling with keyboard • T o turn down the volume, hold down the Fn key and press the F7 key.

  • Page 56: Setup Utility (Bios)

    Sound. Turn on the computer. Right-click Speakers and select Properties → SoundAlive. Before the Samsung logo appears, press the F2 key several Select Enable SoundAlive → an option → OK → OK. times. • I f the computer is password-protected, press the F2 key several times before the password screen appears.

  • Page 57: Keyboard

    Basics Learning the BIOS screen Number Name • S etup menu The BIOS setup screen appears as shown below. – SysInfo: View the basic specifications of the computer. – Advanced: Configure the chipsets and System Time > System Date > additional functions.

  • Page 58: Boot Password

    Basics BIOS setup keys Boot password Setting a password with the BIOS enhances protection against Description viruses and hacking attacks. • C hange values. • D o not forget your password or expose it to others. • M ove to another menu. •...

  • Page 59: Setting Passwords

    Turn on the computer. User Password, and HDD Password. • S upervisor Password (low security level): This password is Before the Samsung logo appears, press the F2 key several required when turning on the computer or attempt to enter times.

  • Page 60: Removing A Password

    Select Save → Yes to save and restart. Turn on the computer. • T o enable the Password on boot option, set a Before the Samsung logo appears, press the F2 key several Supervisor Password and enter the password when times.

  • Page 61: Boot Priority

    Basics Boot priority Change the boot priority from the BIOS setup. Turn on the computer. Before the Samsung logo appears, press the F2 key several times. Access the Boot menu. Select Boot Device Priority. Click an option menu to open the list.

  • Page 62: Network & Internet

    Network & Internet Wired LAN Connect a LAN adapter to the wired LAN port of the computer. Wired LAN To access the Internet at home, set up an account with an Internet service provider (ISP). To purchase Internet service and a modem, contact a local ISP.
  • Page 63 Network & Internet On the desktop, open the Charms and select the Settings Select Internet Protocol Version 4 (TCP/IPv4) from the list of charm → Control Panel → Network and Internet → network settings → Properties. Network and Sharing Center → Change adapter settings. •...
  • Page 64 Network & Internet Wake on LAN (WOL) feature Configure the IP settings. • W hen using DHCP, select Obtain an IP address Activate the system remotely from sleep mode when a signal, automatically. such as a ping or magic packet command, is received via a wired •...

  • Page 65: Wireless Lan

    Network & Internet • W hen connected to a 100Mbps/1Gbps wired LAN , a Wireless LAN message appears informing the user of connection to a 10Mbps/100Mbps wired LAN when the computer Connect the computer to a wireless network to use the Internet. wakes from sleep mode.
  • Page 66 Network & Internet Wi-Fi networks Select a network from the list of detected wireless networks → Connect automatically → Connect. Open the Charms and then select Settings charm → Networks Networks Airplane mode Airplane mode Wi-Fi Wi-Fi Connect automatically Connect AP List Enter a password, if necessary, and select Next.

  • Page 67: Mobile Broadband (Wireless Wan, Optional)

    EU without restriction indoors, but cannot be operated outdoors. • C ontact the Samsung Service Center to receive service for computer models with mobile broadband devices. • T urn off the WLAN feature when not in use to save battery power.
  • Page 68 Network & Internet • Y ou must subscribe first to use mobile broadband Open the Charms and then select Settings charm → services. To learn more, open the Charms and select the Settings charm → Change PC settings → View mobile broadband hardware information under Networks Wireless.

  • Page 69: Applications

    • A pplications that are provided by Samsung can be installed from SW Update. • S ome applications may not be supported depending on the model.

  • Page 70: Settings

    Applications Settings Menu Description General • S et general settings. Settings, a Samsung integrated settings application, offers various • S et power related settings. Power Management settings functions. Network • S et network functions and settings. Images and features may differ depending on the model •...

  • Page 71: Software Update

    Software Update Read and agree to the User Agreement. This step appears only when the application runs for the first Install and update Samsung applications and drivers on the time. computer easily and conveniently. This application enables the user to search for or download the BIOS, drivers, and applications Select Install &...

  • Page 72: Support Center

    Applications Support Center On the Start screen, click at the lower-left edge, and select Support Center. Diagnose the performance, security, and status of the computer and fix any problems it may have. Additionally, access the FAQ and search features to find solutions for the problems. •...

  • Page 73: S Player

    Play videos and music in various file formats. Search for and view Samsung Kies is an application to transfer music, contacts, and videos online. photos, or sync files between a Samsung mobile device and a Samsung computer. This application also enables the user to On the Start screen, select S Player+.

  • Page 74: Homesync Lite

    HomeSync Lite enables the user to use the computer as cloud SideSync allows the user to control a Samsung mobile device storage and access it via a Samsung mobile device. Set folders from a Samsung computer or share files between them.

  • Page 75: Tpm Security Solution (Optional)

    Failure to do so may lead to inaccessibility to the folder and files after initialization. Turn on the computer. Before the Samsung logo appears, press the F2 key several times. Access the Security menu.
  • Page 76 Applications Select TPM Configuration. Before the Samsung logo appears, press the F2 key several times. Set TPM Device to Enabled. On the BIOS setup screen, access the Security menu. Select TPM Configuration. Set TPM State to Enable and Activate. Set TPM State to Clear.
  • Page 77 Applications Step 2: Installing the TPM solution Step 3: Registering a user Install the TPM solution according to the procedures below. Register a user according to the procedures below. This solution is provided only for models with Recovery On the Start screen, click at the lower-left edge.
  • Page 78 Applications When the security platform screen appears, select Next. Select a security platform feature and set a user password. Follow the on-screen instructions to complete the registration. To use the virtual drive feature, select Security Platform Features and then select Personal Secure Drive (PSD).
  • Page 79 Applications Encrypting folders and files Select a security type → OK. Encrypt folders and files with the Encrypt Files System (EFS). EFS is available for the following operating systems: • W indows 7 Professional / Windows 7 Enterprise / Windows 7 Ultimate •...
  • Page 80 Applications Opening encrypted folders and files The color of the encrypted folder or name of the encrypted file changes to green. Double-click an encrypted folder or a file. Enter the basic user password on the user account control window and select OK.
  • Page 81 Applications Using the virtual drive (Personal Secure Decrypting folders and files Drive) Right-click an encrypted folder or file and then select Decrypt. The virtual drive is a space to save and manage confidential data. When the User Account Control window appears, select In the created virtual drive (PSD), it is possible to create files and Continue.
  • Page 82 Applications Enter a password and click OK. When the virtual drive (PSD) does not appear • T he virtual drive (Personal Secure Drive) is created. The virtual drive (PSD) is available only when the Personal Secure Drive (PSD) option is selected during the program registration. •...
  • Page 83 Applications Registering a new user to the security Step 1: Deleting a virtual drive solution If a virtual drive has been created, delete the virtual drive before deleting the existing authentication information saved on the TPM To register an existing user, delete the existing authentication chip.
  • Page 84 Applications Step 2: Deleting authentication information Select View → Options → View → Hidden files and folders. To delete the existing authentication information, uninstall the Select the Show hidden files, folders, and drives option and TPM security solution and delete the solution data. select OK.

  • Page 85: External Devices

    External devices Inserting and ejecting a CD or DVD Press the Eject button to open the tray. External CD/DVD drive This computer supports external CD/DVD drives with USB interfaces (optional). Check if the interface type of the external CD-ROM drive is a USB type. Connecting the drive Number Description...
  • Page 86 External devices • D o not insert warped, cracked, or heavily scratched disks. Doing so can damage the drive. • D o not eject disks while the status indicator light is on. • Y our external drive may differ from the images used in this manual.

  • Page 87: Memory Card

    External devices • S ome memory cards may not be fully compatible with Memory card the computer. Using an incompatible card may damage the computer or the memory card, or corrupt the data Use a memory card to transfer data to other devices, such as stored in it.

  • Page 88: Inserting A Memory Card

    External devices Inserting a memory card Select the pop-up message to open the memory card folder. If a pop-up message appears, click the corresponding window If a dummy card is inserted in the memory card slot, remove it. → Continue without scanning. Insert a memory card into the memory card slot in the Select Open folder to view files.

  • Page 89: Formatting A Memory Card

    External devices • T o use a memory card to exchange data with a digital Formatting a memory card device, such as a digital camera, formatting the data Format the memory card to remove all data or before using it for with the digital device is recommended.

  • Page 90: External Display

    External devices External display Connecting to a display Connecting the computer to an external display device can be Connect the VGA cable or micro HDMI cable to the useful for presentations or when watching a movie. The cables corresponding port of the computer. required to connect an external display are sold separately.
  • Page 91 External devices Connect the other end of the cable to the D-SUB port or HDMI Connect the power cord to the external display. port of the external display. Turn on the display and change its display mode to one that If the display has several HDMI ports, connect the cable to the supports an external input.

  • Page 92: Slim Security Slot

    Secure the computer to an object by connecting the security lock (optional) to the security slot. The security slot is designed for Samsung Security Locks only, which are sold separately. Other security locks will not fit in the slot. Loop the Samsung Security Lock around a secure object and...

  • Page 93: Troubleshooting

    Troubleshooting • T he Recovery application may not be provided in models with less than 64 GB of memory. For models with less than 64 GB of memory, recover the computer to the factory default settings by reinstalling Windows. •...
  • Page 94 When the computer starts Windows: On the Start screen, click at the lower-left edge, and select Recovery. When the computer does not start Windows: Turn on the computer and press the F4 key several times before the Samsung logo appears.
  • Page 95 Troubleshooting Backing up the current system Select the first point → Recover. Back up important data to an alternate internal drive or an external storage device regularly to prevent data loss. When backing up to an external storage device, connect the device to the computer.
  • Page 96 Troubleshooting Recovering after a backup Select a drive under Stored drive → Backup. • W hen backing up to an external storage device, connect Select a backup point saved on an alternate internal drive or an the device to the computer and then select the external external storage device to recover the computer to the point.
  • Page 97 Troubleshooting Copying the hard drive Select a point to recover → Recover. (making a disk image) • S elect one of your backup points. • I f a backup data is stored on an internal drive, select To replace the hard drive, move the data to the new drive by →...
  • Page 98 After the data is saved to another drive, open the cover at the bottom of the computer and replace the existing drive with the new one. If the cover is difficult to open, contact the Samsung Service Center to request assistance. You will be charged for this service.
  • Page 99 Troubleshooting Making a disk image of factory default Follow the on-screen instructions to complete creating the disk image. settings Disconnect the external storage device and store it in a safe Create a factory disk image to simplify the restoring process. place.

  • Page 100: Windows Recovery

    • R ight-click the Start button, and then click Shut down or sign reinstallation. out → Shut down. After a recovery, on the Start screen, click at the lower- left edge, and select SW Update to install the necessary Samsung applications.
  • Page 101 Troubleshooting My application disappeared from the Start screen. Can I use the Windows 7 desktop? How can I correct this? To set the desktop to appear by default, as in Windows 7, do the following: Touch screen: Right-click the desktop taskbar, and then select Properties → Navigation tab →...
  • Page 102 Charms and selecting the Settings charm → Change PC settings → PC and devices. To configure any other features, Before the Samsung logo appears, press the F2 key several on the desktop, open the Charms and select the Settings charm times.

  • Page 103: Specifications

    Troubleshooting Touch screen resolution Why is the capacity representation of the hard disk drive (HDD) in Windows different from the product specifications? Text on the screen overlaps or looks small. The capacity of the storage device (HDD or SSD) of the If the font size is set too large or small, text may not fit or may not manufacturer is calculated assuming that 1KB=1,000 Bytes.
  • Page 104 Troubleshooting What is a recovery image? This refers to specifications about the operating system, drivers, and software that are converted to a data image. It is required to recover the computer and is embedded in the computer’s HDD. However, this is not provided for storage devices where the capacity is less than 64 GB, due to their small capacities.

  • Page 105: Appendix

    Appendix • O ptional components may not be provided or different components may be provided depending on the model. • T he system specifications are subject to change without notice. Product specifications • T he Storage device capacity of a computer in which Recovery is installed, is represented as smaller than the The system specifications may differ depending on the derived product specification.

  • Page 106: Ergonomic Tips

    Appendix Ergonomic tips • U se an adjustable chair with firm, comfortable support. • A djust the height of your chair so that thighs are horizontal to Maintaining a proper posture during computer use is very the floor and feet are flat on the floor. important to prevent physical injury.
  • Page 107 Appendix Arms and hands • W hen using the keyboard and touchpad, the shoulders should be relaxed. The upper arm and forearm should form an angle that is slightly greater than a right angle, with the wrist and hand in almost a straight line. •...
  • Page 108 Appendix Eye position and display illumination Hearing and volume control VOLUME Check your volume! • E nsure that volume is not too loud before using headphones. • A void using headphones for long periods of time. • P osition the screen at least 50 cm away from your eyes. •...

  • Page 109: Operating Conditions

    Appendix Operating conditions • T ake at least a 10 minute break every hour. • A void using the computer in dark locations. Use the computer with as much ambient light as you would when reading a book. •...

  • Page 110: Battery

    Appendix Battery Power Indicator Light (LED) Center Holes Charging the battery on an airplane Power outlets may vary by airplane. Choose the connection 220V Power Plug 110V Power Plug method that fits your circumstances. Good Example O The power plug and auto adapter figures may differ from the actual products.
  • Page 111 Appendix Using an auto adapter Using an airplane charging converter When a 12VDC power supply is available a cigarette lighter socket Depending on the type of airplane you are travelling on, use the will be provided. Use the optional auto adapter to use the 12VDC auto adapter and charging converter.

  • Page 112: Safety Precautions

    To avoid danger of suffocation, keep the plastic using it. bag away from infants and children. • S ince this is commonly applied to Samsung Computers, Putting a plastic bag over the head may result in some pictures may differ from actual products.
  • Page 113 Samsung Service Center. For Failure to do so may result in electric shock notebook computers that are provided with or fire. an external removable battery, separate the battery also. Damage to the device within the computer may...
  • Page 114 Batteries or AC adapters that are not approved turned on. by Samsung may malfunction from a defective safety device, resulting in an explosion or fire. The computer may overheat and there is a danger of fire.
  • Page 115 Do not put or use the product in a the cables that are connected to the computer. hot location such as a sauna, inside a vehicle For notebook computers that are provided exposed to heat, and so on. with an external removable battery, separate the battery also.
  • Page 116 If Do not disassemble any other parts by yourself. the notebook is an external and removable Failure to do so may result in computer battery type, remove the external battery. malfunction, electric shock, or fire.
  • Page 117 For example, airlines and notebook computer. hospitals have strict requirements. If a heavy object is pressed against the notebook Avoid exposing a drive to magnetic fields. computer, a white spot or stain may appear on Security devices with magnetic fields include the LCD.
  • Page 118 Appendix Do not place a heavy object over the product. Caution This may cause a problem with the computer. In addition, the object may fall and cause injury, or damage the computer. Failure to follow instructions marked with this symbol may cause slight injury or damage to the product.
  • Page 119 Failure to do so, may cause an explosion or fire from damage to Authorized Samsung Repair Centers will carry out safety checks the product. after a repair. Using a repaired product without testing it for safety may cause an electric shock or fire.
  • Page 120 When handling computer parts, follow the instructions on the Failure to do so, may cause electric shock and fire. manual supplied with the parts. Close the LCD panel only after checking if the notebook Failure to do so, may cause damage to the product. computer is turned off.
  • Page 121 Appendix Do not insert the fingers into the PC Card Slot. Keep the product away from magnetic fields. There is a danger of injury or electric shock. • M agnetic materials may cause the product malfunction or cause the battery to discharge. Use recommended computer cleansing solution when cleaning •...
  • Page 122 Failure to do so, may cause fire or damage the product. For long periods of not using the notebook computer, discharge Never disassemble or repair the product by yourself. the battery and preserve as it is detached. (For external and...
  • Page 123 Appendix Cautions on preventing data loss (Hard disk Causes that may damage the data of a hard disk drive and the hard disk drive itself. management) • T he data may be lost when an external impact is applied to Take care not to damage the data on a hard disk drive.
  • Page 124 Samsung’s quality standards for bad pixels are as follows: • B right dot: 2 or fewer • B lack dot: 4 or fewer •...

  • Page 125: Important Safety Information

    Appendix Important safety information Setting up the system • R ead and follow all instructions marked on the product and in the documentation before operating the system. Retain all Safety instructions safety and operating instructions for future use. The system is designed and tested to meet the latest standards for •...
  • Page 126 • F or Notebooks with glossy display bezels the user should same or equivalent type recommended by the manufacturer. consider the placement of the Notebook as the bezel may Dispose of batteries according to the manufacturers cause disturbing reflections from surrounding light and bright instructions.
  • Page 127 Appendix • U nplug the system from the wall outlet and refer servicing to The instruction on safety operation of the computer qualified personnel if: When installing and operating devices please refer to safety – The power cord or plug is damaged. requirements in the user manual.

  • Page 128: Replacement Parts And Accessories

    Do not put rechargeable batteries or products powered by non-removable rechargeable batteries in the garbage. Use only replacement parts and accessories recommended by Contact the Samsung Service Center for information on how to manufacturer. dispose of batteries that you cannot use or recharge any longer.

  • Page 129: Laser Safety

    Appendix Laser safety Connect and disconnect the AC adapter All systems equipped with CD or DVD drives comply with the The socket-outlet shall be installed near the equipment and shall appropriate safety standards, including IEC 60825-1. The laser be easily accessible. devices in these components are classified as “Class 1 Laser Do not unplug the power cord by pulling the cable only.

  • Page 130: Regulatory Compliance Statements

    2.4GHz/5GHz • T he appliance coupler must meet the mechanical Band, may be present (embedded) in the notebook system. The configuration of an EN 60 320/IEC 320 Standard Sheet C7 following section is a general overview of considerations while (or C5) connector, for mating with appliance inlet on the operating a wireless device.
  • Page 131 The RF field strength of the wireless device or devices that may with equipment on commercial aircraft. Current be embedded in the notebook are well below all international aviation regulations require wireless devices to be RF exposure limits as known at this time. Because the wireless turned off while traveling in an airplane.

  • Page 132: United States Of America

    Appendix • I f the system came equipped with an internal United States of America embedded wireless device, do not operate the wireless device unless all covers and shields are in place and the USA and Canada Safety Requirements and Notices system is fully assembled.
  • Page 133 Appendix Explosive Device Proximity Warning The Part 15 radio device operates on a non-interference basis with other devices operating at this frequency. Any Do not operate a portable transmitter (such as a wireless changes or modification to said product not expressly network device) near unshielded blasting caps or in approved by Intel could void the user’s authority to an explosive environment unless the device has been...
  • Page 134 Appendix This equipment has been tested and found to comply If necessary, the user should consult the dealer or an experienced with the limits for a Class B digital device pursuant to Part radio/television technician for additional suggestions. The user 15 of the FCC Rules.
  • Page 135 2.4 GHz/5 GHz Band, Wireless devices are not user serviceable. Do not modify may be present (embedded) in the notebook system. This section them in any way. is only applicable if these devices are present. Refer to the system label to verify the presence of wireless devices.
  • Page 136 Appendix Health and safety information The exposure limit set by the FCC for wireless devices employs a unit of measurement known as the Specific Absorption Rate (SAR). The SAR is a measure of the rate of absorption of RF energy by the Exposure to Radio Frequency (RF) Signals human body expressed in unites of watts per kilogram (W/kg).
  • Page 137 For body worn operation, this model has been tested and meets interference regulations of Industry Canada. the FCC RF exposure guidelines when used with a Samsung accessory designated for this product. Non-compliance with Intentional emitter per RSS 210 the above restrictions may result in violation of FCC RF exposure guidelines.
  • Page 138 2.4GHz/5GHz Band, antenna type and its gain should be so chosen that the equivalent may be present (embedded) in your notebook system. This isotropically radiated power (EIRP) is not more than that required section is only applicable if these devices are present. Refer to the for successful communication.
  • Page 139 The power output of the wireless device (or devices), which may indoor use due to its operation in the 5.15 to 5.25 GHz frequency be embedded in your notebook, is well below the RF exposure range. Industry Canada requires this product to be used indoors limits as set by Industry Canada.

  • Page 140: European Union

    Appendix Brazil European Union Este produto esta homologado pela ANATEL, de acordo com European Union CE marking and compliance notices os procedimentos regulamentados pela Resolucao 242/2000, e atende aos requisitos tecnicos aplicados. Products intended for sale within the European Union are Este equipamento opera em caráter secundário, isto é, não marked with the Conformité...

  • Page 141: Statements

    že tento Notebook PC je ve operating in the 2.4GHz/5GHz band, may be present (embedded) shodě se základními požadavky in your notebook system which is intended for home or office use. Česky[Czech] a dalšími příslušnými This section is only applicable if these devices are present. Refer to ustanoveními směrnice 1999/5/...
  • Page 142 ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ asjakohastele sätetele. ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ. Hereby, Samsung, declares Par la présente Samsung that this Notebook PC is in déclare que l’appareil compliance with the essential Notebook PC est conforme aux English Français[French] requirements and other...
  • Page 143 Appendix Nation Description Nation Description Ar šo Samsung deklarē, ka Alulírott, Samsung nyilatkozom, Notebook PC atbilst Direktīvas hogy a Notebook PC megfelel Latviski[Latvian] 1999/5/EK būtiskajām prasībām a vonatkozó alapvetõ Magyar[Hungarian] un citiem ar to saistītajiem követelményeknek és az noteikumiem. 1999/5/EC irányelv egyéb elõírásainak.
  • Page 144 Description Nation Description Samsung izjavlja, da je ta Hér með lýsir Samsung yfir því Notebook PC v skladu z að Notebook PC er í samræmi Slovensko[Slovenian] bistvenimi zahtevami in Íslenska[Icelandic] við grunnkröfur og aðrar kröfur, ostalimi relevantnimi določili sem gerðar eru í tilskipun direktive 1999/5/ES.

  • Page 145: Statements

    Samsung Electronics Vietnam Co., Ltd. Yen Phong 1, I.P Yen Trung Commune, Yen Phong Dist., Bac Ninh Province, Vietnam For the web or the phone number of the Samsung Service Center, see the Warranty or contact the retailer where you purchased your product.
  • Page 146 Appendix Belgium The European variant is intended for use throughout the European Economic Area. However, authorization for use is further restricted For private use outdoors in public spaces, no registration is in particular countries or regions within countries, as follows: necessary for distances less than 300 m.

  • Page 147: Weee Symbol Information

    Appendix RTC caution WEEE symbol information CAUTION : Danger of explosion if battery is incorrectly replaced. Correct disposal of this product (Waste Electrical & Replace only with the same or equivalent type recommended Electronical Equipment) by the manufacturer. Discard used batteries according to the (Applicable in countries with separate collection Manufacturer’s instruction.
  • Page 148 (Applicable in countries with separate collection For more information on safe disposal and recycling visit our systems) website www.samsung.com/in or contact our Helpline numbers - 18002668282, 180030008282. This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life.

  • Page 149: Samsung Package Take-Back Program

    Appendix USA only Samsung package Take-Back program In partnering with select recyclers, Samsung offers packaging take-back at no cost to you. Simply call the following number for the locations nearest you. This Perchlorate warning applies only to primary CR (Maganese...

  • Page 150: Tco Certified (For Corresponding Models Only)

    • D esigned with the option to connect an external display, keyboard and mouse (recommended when working with a notebook or netbook for longer periods) • E rgonomic keyboard design – for ease of use and good readability •...
  • Page 151 Appendix Environment– Designed for the Planet • B rand demonstrates corporate social responsibility and has a certified environmental management system (EMAS or ISO 14001) • V ery low energy consumption both in idle- and standby mode, reducing climate impact •...
  • Page 152 Some content may differ from the computer depending on the region, service provider, software version, or computer model, and is subject to change without prior notice. www.samsung.com English. 08/2013. Rev. 1.0...

This manual is also suitable for:

Np940x3g-k01

Table of Contents
