Insignia NS-32DD310NA15 Quick Setup Manual

QUICK
SETUP GUIDE
32" LED TV/DVD Combo
NS-32DD310NA15
Thank you
for purchasing this state-of-the-art
Insignia television. We hope you enjoy
the quality and reliability of this
television for years to come.
Included accessories
FIND YOUR
USER GUIDE ONLINE!
We are going green so a copy of your
User Guide is not provided in the box
but is available online.
Go to www.insigniaproducts.com,
then click Support & Service. Enter your
model number in the box under Manual,
Firmware, Drivers & Product Information,
then click .
START HERE
How do I attach the stand to my TV?
(not for wall mounting)
You'll need: A Phillips screwdriver and a soft surface to lay the TV on.
A Carefully place your TV face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
B Secure the stand column to your TV with the ve provided M4 x 8 mm screws.
(the shorter screws).
C Secure the TV stand to the stand column with the four provided B4 x 18 mm screws.
(the longer screws).
- OR -
How do I prepare my TV for wall mounting?
(not for use with a TV stand)
You'll need: A soft surface to lay the TV on.
A Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages and scratches.
B See the instructions that came with your wall mount for more information about how to correctly mount your TV.
Which cables do you have?
Your TV has several di erent jacks for connecting devices.
STOP!
For the best video quality, use the best available
connection. Use the cables that came with your devices.
Do not plug your
VIDEO QUALITY
power adapter in until
all other devices have
been connected.
BEST
BETTER
Component video and analog audio
GOOD
Composite video and analog audio (AV)
GOOD
Note: You can also connect a DVI device to your TV. See your online User Guide for connection
instructions.
Power adapter Features
Front view
Remote control
and two AAA
batteries
Power indicator
Remote control sensor
Stand column
Back view
T V stand
M4 screws (8 mm length)
(5 pcs.)
Power adapter
B4 screws (18 mm length)
(4 pcs. )
Images do not necessarily represent the exact design of your television.
Before using your new product, please read these instructions to prevent any damage.
A
A
MAKING CONNECTIONS
How do I watch TV (cable or satellite receiver) or connect a device such as a DVD or
Blu-ray Disc player, game console, or camcorder?
JACK TYPE CABLE CONNECTOR
Using an HDMI cable
(BEST)
HDMI video/audio
Coaxial video/audio
Using component cables (BETTER)
- OR -
Using an AV cable (GOOD)
DVD
EJECT MENU INPUT VOL - VOL+ CH CH
Note: The control buttons are on the
bottom edge of the screen.
How do I connect my TV to an antenna or cable wall jack?
DC IN
DC IN PC /DVI
AUDIO IN VGA ANT/CABLE
B
M4 type 8 mm screws
Front
Component cable option
AUDIO/VIDEO OUT
Note: Connect the yellow video cable connector to the
green VIDEO/Y jack on the back of your TV.
DC IN
C
B4 type 18 mm screws
Multi-purpose jacks: You can plug any
device that uses HDMI into either
HDMI jack. However, certain devices
must be connected to the DVI or ARC
jack. See the instructions that came
with your DVI or ARC device for more
information.
Note: The component video
and AV jacks are shared. This
means you can connect only
one component video or AV
device at a time. We suggest
using HDMI if your device
supports it.
AUDIO/ VIDEO
OUT
AV cable
option
CABLE
OVER
