SERVICE MANUAL
Ver 1.0 2004. 04
• SS-RS880 is surround speaker system
in MHC-GN770/GN880/GX9000.
Sony Corporation
9-877-804-01
Home Audio Company
2004D02-1
Published by Sony Engineering Corporation
© 2004.04
SPECIFICATIONS
Speaker system
2-way, 2-unit, bass-reflex type
Speaker units
Woofer
13 cm, cone type
Tweeter
2.5 cm, horn type
Nominal impedance
24 ohms
Dimensions (w/h/d) (Approx.)
201 x 430 x 229 mm
Mass (Approx.)
4.2 kg net per speaker
Design and specifications are subject to change without notice.
SS-RS880
Australian Model
SPEAKER SYSTEM
US Model
E Model
Advertisement
Related Manuals for Sony SS-RS880
Summary of Contents for Sony SS-RS880
- Page 1 SS-RS880 SERVICE MANUAL US Model E Model Ver 1.0 2004. 04 Australian Model • SS-RS880 is surround speaker system in MHC-GN770/GN880/GX9000. SPECIFICATIONS Speaker system 2-way, 2-unit, bass-reflex type Speaker units Woofer 13 cm, cone type Tweeter 2.5 cm, horn type...
-
Page 2: Exploded Views
SS-RS880 EXPLODED VIEWS NOTE: • -XX, -X mean standardized parts, so they may • The mechanical parts with no reference number in have some difference from the original one. the exploded views are not supplied. • Items marked “ * ”are not stocked since they are seldom required for routine service. - Page 3 SS-RS880 MEMO...
-
Page 4: Revision History
SS-RS880 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision...
