SERVICE MANUAL
Ver 1.1 2001.11
• HCD-BX3/DX3 are the tuner, deck,
CD and amplifier section in MHC-
BX3/DX3.
AUDIO POWER SPECIFICATIONS:
(HCD-BX3 US model only)
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
with 6 ohm loads both channels driven, from 120-10,000 Hz; rates
75 watts per channel minimum RMS power, with no more than 10%
total harmonic distortion from 250 milliwatts to rated output.
Amplifier section
US, Canadian model:
HCD-BX3:
Continuous RMS power output (reference)
60 + 60 watts
(6 ohms at 1 kHz, 10% THD)
Total harmonic distortion less than 0.07%
(6 ohms at 1 kHz, 35 W)
AEP, UK model:
HCD-BX3:
DIN power output (rated) 45 + 45 watts
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
60 + 60 watts
(6 ohms at 1 kHz, 10% THD)
Music power output (reference)
150 + 150 watts
(6 ohms at 1 kHz, 10% THD)
Other model:
HCD-DX3:
The following measured at AC 120, 220, 240 V 50/60 Hz
Sony Corporation
9-929-055-12
2001K1600-1
Home Audio Company
© 2001.11
Published by Sony Engineering Corporation
HCD-BX3/DX3
Photo: HCD-BX3
Model Name Using Similar Mechanism
CD
CD Mechanism Type
Section
Base Unit Name
Optical Pick-up Name
Tape deck
Model Name Using Similar Mechanism
Section
Tape Transport Mechanism Type
SPECIFICATIONS
DIN power output (rated) 75 + 75 watts
Continuous RMS power output (reference)
Inputs
MD/VIDEO IN:
(phono jacks)
MIC:
(mini jack)
Outputs
PHONES:
(stereo mini jack)
SPEAKER:
CD player section
System
Laser
Laser output
COMPACT DISC DECK RECEIVER
US Model
Canadian Model
AEP Model
UK Model
HCD-BX3
E Model
Australian Model
HCD-DX3
NEW
CDM58-K2BD38
BU-K2BD38
KSM-213DAP
NEW
TCM-230MWR11
(6 ohms at 1 kHz, DIN)
100 + 100 watts
(6 ohms at 1 kHz, 10% THD)
voltage 450/250 mV,
impedance 47 kilohms
sensitivity 1 mV,
impedance 10 kilohms
accepts headphones of
8 ohms or more
accepts impedance of 6 to 16 ohms
Compact disc and digital audio system
Semiconductor laser (λ=780 nm)
Emission duration: continuous
Max. 44.6 µ W*
*This output is the value measured at a
distance of 200 mm from the objective
lens surface on the Optical Pick-up Block
with 7 mm aperture.
— Continued on next page —
