SERVICE MANUAL
Ver 1.1 2004. 08
• HCD-RV22/RV55 are the tuner,
deck, CD and amplifier
section in MHC-RV22/RV55.
Amplifier section
HCD-RV55
Front speaker
The following measured at AC 120, 127, 220, 240 V, 50/60 Hz
DIN power output (rated):
120 + 120 watts
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
150 + 150 watts
(6 ohms at 1 kHz, 10% THD)
HCD-RV22
The following measured at AC 120, 127, 220, 240 V, 50/60 Hz
DIN power output (rated):
100 + 100 watts
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
120 + 120 watts
(6 ohms at 1 kHz, 10% THD)
Sony Corporation
9-879-126-02
2004H04-1
Audio Group
© 2004. 08
Published by Sony Engineering Corporation
HCD-RV22/RV55
(Photo: HCD-RV55)
SPECIFICATIONS
Model Name Using Similar Mechanism
CD
CD Mechanism Type
Section
Base Unit Name
Optical Pick-up Name
Model Name Using Similar Machanism
TAPE
Section
Tape Mechanism Type
Inputs
VIDEO/SAT IN (phono jacks) (HCD-RV55 only):
voltage 450/250 mV,
impedance 47 kilohms
GAME INPUT AUDIO L/R (phono jacks):
voltage 250 mV,
impedance 47 kilohms
GAME INPUT VIDEO (phono jack):
1 Vp-p, 75ohms
MIC (phone jack):
sensitivity 1 mV,
impedance 10 kilohms
Outputs
PHONES (stereo phone jack):
accepts headphones of
8 ohms or more
VIDEO/SAT OUT (phono jacks) (HCD-RV55 only):
impedance 1 kilohm
MINI Hi-Fi COMPONENT SYSTEM
E Model
NEW
CDM74-K4BD49
BU-K4BD49
KSM-213DHAP
HCD-GN700
HCD-RG330
CWM43RR35
CWM43FF13
– Continued on next page –
