SERVICE MANUAL
Ver 1.1 2002.01
Sony Corporation
9-873-880-12
Home Audio Company
2002A1600-1
Published by Sony Engineering Corporation
© 2002.1
SS-MF500H
SPECIFICATION
Speaker system
3-way, magnetically shielded
Loud speaker units
in.), cone type × 2
1
Woofer: 16 cm (6
/
2
1
Mid range: 8 cm (3
/
in.), cone type
4
Tweeter: 2.5 cm (1 in.), balance dome type
Enclosure type
Bass reflex
Rated impedance
8 ohms
Power handling capacity
Maximum input power 180 watts
Sensitivity level
89 dB (1 W, 1 m)
Frequency range
40 Hz - 50,000 Hz
Cross over frequency
5,000 Hz, 7,000 Hz
Dimensions (w/h/d)
Approx. 220 × 950 × 230 mm (8
not including front grille
Finish
Black foil laminated
Mass
5
Approx. 12.5 kg (27
/
lb)
8
Supplied accessory
Speaker cord 2.5 m (8 ft.) (2)
Design and specifications are subject to change without notice.
Canadian Model
× 37
× 9
3
1
1
/
/
/
in.),
4
2
8
SPEAKER SYSTEM
US Model
E Model
1
