Heating or Cooling and Heating/Cooling
Check thermostat and subbase (if used) suitability for the
heating, cooling, or heating/cooling system. Refer to Table 1.
Assemble tools required: flat bladed screwdriver, hand or
power drill with 3/16-in. drill bit, wire cutter/stripper or
sharp knife, bubble level or plumb bob and line.
Assure power is off to the heating, cooling, or heating/
cooling system at the main fuse panel. Most buildings have
a separate switch box or circuit breaker for disconnecting
power to the heating and cooling (if applicable) equipment.
This thermostat is compatible with most heating, cooling,
or heating/cooling systems. Refer to Table 1 for thermostat
and system compatibility information.
Type of Heating System
to be Controlled
Electric (Line Voltage)—typical
baseboard and radiant
Fan Coil Unit
Gas—Direct Spark Ignition
(DSI), Intermittent Pilot (IP), and
Standing Pilot (SP)
Heat Pump
Hot Water Zone
Oil
Vent Damper
Warm Air Zone
a
If thermostat is not compatible with the system being controlled, the system will not operate. No hazard exists. The thermo-
stat will not be damaged unless it is used to directly control a line voltage system. For proper system operation, a Honeywell
R841 or R8239D1015 Isolating Relay must be added to the thermostat control circuit.
b
Consult manufacturer for installation requirements.
T8195B/Q682B,C, Y8224A
New Construction Thermostat,
Installation Instructions for the Trained Service Technician.
Preparation
TABLE 1—THERMOSTAT AND SYSTEM COMPATIBILITY.
• The R8239D1015 Isolating Relay or R841 Silent Switching Center must be
installed in the thermostat control circuit.
• Compatible. Assure correct subbase identity is selected for fan control.
• Compatible. Assure that 24V control transformer common is accessible for
connection to thermostat cable conductor and power to the transformer is not
regularly interrupted by high temperature or limit operation.
• Compatible. Assure correct subbase identity is selected for fan control and
changeover control (O terminal for cool and B terminal for heat). Jumper Y
to W for heat pump compressor control.
• Honeywell 2-wire valves are compatible.
• Some non-Honeywell 2-wire valves require an R8239D1015 Isolating Relay
in the thermostat control circuit.
• Some 3-wire valves require an R8239A1052 Isolating Relay in the
thermostat control circuit.
• Assure that the 24V control transformer common is accessible for connection
to thermostat cable conductor and power to the transformer is not regularly
interrupted by high temperature, purge cycle, or limit operation.
• Honeywell damper motors are compatible.
• Some non-Honeywell damper motors require an R8239D1015 Isolating
Relay in the thermostat control circuit.
requirement.
• Most are compatible.
D.F. • Rev. 11-94 •
Wallplate and Subbase
This control contains mercury in a sealed tube. Do not
place control in the trash at the end of its useful life.
If this control is replacing a control that contains mercury
in a sealed tube, do not place your old control in the trash.
Contact your local waste management authority for in-
structions regarding recycling and the proper disposal of this
control, or of an old control containing mercury in a sealed
tube.
If you have questions, call Honeywell Inc. at 1-800-
468-1502.
Conditions/Compatibility
a
a, b
1
• ©Honeywell Inc. 1994 • Form Number 69-0564—3
M3375
Recycling Notice
M3375
a
a
Check control amperage
69-0564—3
